Cub Cadet Yanmar Ex32002 Part List Manual page 103

Ex Series
REF
NO.
PART NUMBER
1 CY-198129-27281
2 CY-1A8160-29040
3 CY-1A8160-35080
4 CY-1A8160-35100
5 CY-1A8160-35110
6 CY-1A8160-35210
7 CY-1A8160-35240
8 CY-1A8160-35310
9 CY-198167-35311
10 CY-1A8160-35360
11 CY-198167-35411
12 CY-22137-120000
13 CY-22242-000120
14 CY-22351-035036
15 CY-22351-060036
16 CY-24104-060024
17 CY-24104-062014
18 CY-26106-080122
19 CY-26106-080202
20 CY-26106-080252
21 CY-26716-080002
22 CY-1C6281-52320
23 CY-22417-200300
24 CY-22137-080000
25 CY-22137-100000
26 CY-22487-080160
27 CY-22487-100280
28 CY-26106-080202
103
FIG. 65. HYDRAULIC PEDAL
DESCRIPTION
CAM ROLLER
ROD, HYDRAULIC
HEAD, PEDAL
PEDAL, HST KIT INCLUDES REF. NO.
5 THROUGH 21.
HST PEDAL, F CMP
HST PEDAL, R CMP
BRACKET ASSY, HST PED
F PEDAL SHAFT CMP
PLATE, KEEP
R PEDAL SHAFT CMP
SPRING, REVERSE PEDAL
WASHER 12, POLISHED
CIRCLIP 12
SPRING PIN 3.5X36
SPRING PIN 6X36
BALL BEARING 6002UU
BALL BEARING 6201UU
BOLT M 8X 12 PLATED
BOLT M 8X 20 PLATED
BOLT M 8X 25 PLATED
NUT M 8
PIN 8, SNAP
COTTER PIN 2.0X30
WASHER 8, POLISHED
WASHER 10, POLISHED
PIN 8X 16
PIN, 10 X 28
BOLT M 8X 20 PLATED
