Cub Cadet Yanmar Ex32002 Part List Manual page 143

Ex Series
REF
NO.
PART NUMBER
1 CY-194990-22140
2 CY-194990-22140
3 CY-194170-51210
4 CY-198071-58810
5 CY-198448-60080
6 CY-198448-60080
7 CY-1A7260-60911
8 CY-1A7260-60580
9 CY-1A7260-60590
10 CY-1A7260-61080
11 CY-1A7260-61190
12 CY-22272-000080
13 CY-1A7260-60950
14 CY-1A7260-60960
15 CY-1A7890-60980
16 CY-1A7340-61560
17 CY-194440-61580
18 CY-194167-61650
19 CY-194167-61650
20 CY-1A8160-61700
21 CY-1A8160-61730
22 CY-1A8160-61740
23 CY-1A8160-61810
24 CY-194555-61970
25 CY-1A8160-62030
26 CY-1A8160-62040
27 CY-1A8160-62050
28 CY-194330-62530
29 CY-1A8160-62540
30 CY-174570-63620
31 CY-198146-63660
32 CY-22137-080000
33 CY-22137-080000
34 CY-22372-080000
35 CY-22372-080000
36 CY-22487-080300
37 CY-22487-080300
38 CY-26106-080162
38 CY-26106-080162
39 CY-26106-060122
40 CY-198245-51210
41 CY-26106-080122
143
FIG. 94. HOOD FRAME
DESCRIPTION
NUT W/WASHER 8
NUT W/WASHER 8
GROMMET, 25
GROMMET 8
TRIM 40
TRIM 40
HINGE ASSY, HOOD
SPRING, L.H.
SPRING, R.H.
PLATE, LOWER
PIN,
CIRCLIP E- 8
STAND, A HOOD
STAND, B HOOD
CUSHION
WEATHER STRIP, 180
GROMMET, 21X46
NUT, M5
NUT, M5
PLATE CMP, AIR SHIELD
SUPPORT L.H., CMP
SUPPORT R.H., CMP
STAY,DB SIDE
STRIP
BRACKET L CMP, TANK
BRACKET R CMP, TANK
SUPPORT CMP, HOOD
STOPPER, PEDAL
STAND CMP, HOOD
WEATHER-STRIP, 195
STRIP 250, WEATHER
WASHER 8, POLISHED
WASHER 8, POLISHED
SNAP PIN (JASO 8)
SNAP PIN (JASO 8)
PIN 8X 30
PIN 8X 30
BOLT M 8X 16 PLATED - S/N
F000155 & BELOW
BOLT M 8X 16 PLATED - S/N
F000156 & ABOVE
BOLT M 6X 12 PLATED
GROMMET 25
BOLT M 8X 12 PLATED - S/N
F000156 & ABOVE
Copyright 2007 Cub Cadet Yanmar LLC
QTY
2
3
4
1
1
2
1
1
1
1
1
2
1
1
1
2
2
2
4
1
1
1
2
2
1
1
1
2
1
1
1
1
2
1
2
1
2
21
19
4
1
2
