Cub Cadet Yanmar Ex32002 Part List Manual page 151

Ex Series
REF
NO. PART NUMBER
1 CY-1A7510-60980
2 CY-1A6150-61870
3 CY-198220-62150
4 CY-1A8160-62290
5 CY-1A8160-62300
6 CY-198240-62451
7 CY-198230625101
8 CY-1A8160-62530
8-1 CY-198230625201
9 CY-194330-62530
10 CY-1A7335-62560
11 CY-1A8160-62760
12 CY-198220-62890
13 CY-22372-080000
14 CY-26106-080102
15 CY-26106-080122
16 CY-26106-080202
17 CY-26106-080202
18 CY-1A7335-62550
19 CY-26106-080202
19-1 CY-26106-080162
151
FIG. 98. STEP
DESCRIPTION
STOPPER
SEAL 3X10X345
WASHER
SUPPORT, FOOTREST F L
SUPPORT, FOOTREST F R
RUBBER ISOLATOR, STEP
FOOTREST, L.H
FOOTREST, R.H.
FOOTREST, R.H. - S/N F000155 &
BELOW
STOPPER, PEDAL
STAY, STEP RR
STOPPER, STEP
STOPPER
SNAP PIN (JASO 8)
BOLT M 8X 10 PLATED
BOLT M 8X 12 PLATED
BOLT M 8X 20 PLATED
BOLT M 8X 20 PLATED - S/N F000155 &
BELOW (REPLACE WITH CY-26106-
080162 IN THIS APPLICATION)
STAY, STEP RL
BOLT M 8X 20 PLATED - S/N F000155 &
BELOW
BOLT M 8X 16 PLATED - S/N F000156 &
ABOVE
Copyright 2007 Cub Cadet Yanmar LLC
Ex3200
QTY
1
2
5
1
1
6
1
1
1
2
1
1
5
5
1
2
8
2
1
2
4
