FIG. 111. MID P.T.O. KIT 59A40014727 CONTROLS (OPTIONAL)
REF
NO.
PART NUMBER
1
N/A
2
CY-194191-13350
3
CY-198230-26600
4
CY-198230-26630
5
CY-198230-26650
6
CY-198230-26710
7
CY-198230-26720
8
CY-198230-26730
9
CY-198220-26990
10
CY-198220-27230
11
CY-1A8160-27250
12
CY-198220-27390
13
CY-198220-27400
14
CY-194065-23140
15
CY-198220-27240
16
CY-198220-27460
17
CY-194180-05270
18
CY-198220-27790
19
CY-22157-080000
20
CY-22272-000070
21
CY-198220-27470
22
CY-194180-05270
23
CY-198220-27580
24
CY-198220-27620
25
CY-194150-01270
26
CY-198220-27610
27
CY-198220-27770
28
CY-198220-27880
29
CY-194130-37750
30
CY-22117-100000
31
CY-22252-000200
32
CY-26716-100002
33
CY-26716-100002
34
CY-198220-27710
35
CY-24550-020250
36
CY-1A8160-27760
37
CY-24550-020250
38
CY-1A8160-27800
39
CY-24550-020250
40
CY-1A8160-27840
DESCRIPTION
MID PTO, EXTERIOR KIT
SPACER 20X30X1.6
COVER (A), MID PTO
COVER (C), MID PTO
COVER (B), MID PTO
RUBBER (A)
RUBBER (B)
RUBBER (C)
HOSE, PROTECTION
SPRING, MID PTO
COVER, SWITCH
KNOB, MID PTO LEVER
SPRING SUPPORT ASSY
SEAT, SPRING
ROD, SPRING
SPRING PIVOT
BUSH 8X12X20
BOLT
WASHER 8
CIRCLIP E- 7
SPRING END ASSY
BUSH 8X12X20
SHAFT
SPRING CAPSULE ASSY
SPACER 20
HOLDER, SPRING
ROD,MID PTO BRAKE
SPRING
JOINT (RH SCREW)
WASHER 10
CIRCLIP 20
NUT 10
NUT 10
BELL-CRANK ASSY
BEARING 20X25
LEVER, MID PTO CMP
BEARING 20X25
ARM,MID KIT
BEARING 20X25
ARM, MID PTO ASSY
Copyright 2007 Cub Cadet Yanmar LLC
175
REF
NO.
QTY
PART NUMBER
1
41
CY-1E4440-24050
1
42
CY-1A8160-27900
1
43
CY-198220-27940
1
44
CY-198234-27980
1
45
CY-194990-20170
1
46
CY-194820-27370
1
47
CY-198220-27750
1
48
CY-198220-28260
1
49
CY-172112-41980
1
50
CY-26716-080002
1
51
CY-198220-28250
1
52
CY-198220-37900
1
53
CY-198220-37900
1
54
CY-198220-75120
1
55
CY-198220-75810
1
56
CY-1E4132-99600
1
57
CY-22137-080000
1
58
CY-22137-100000
2
59
CY-22137-200000
1
60
CY-22157-080000
1
61
CY-22157-080000
1
62
CY-22272-000070
1
63
CY-22272-000150
1
64
CY-22272-000150
1
65
CY-22272-000190
1
66
CY-22417-250300
1
67
CY-22417-250300
1
68
CY-22417-250300
1
69
CY-26023-060122
1
70
CY-26106-060122
1
71
CY-26106-080162
1
72
CY-26106-080202
2
73
CY-26106-080202
1
74
CY-26106-100252
1
75
CY-26716-100002
1
76
CY-26986-080002
1
77
CY-198220-27910
1
78
CY-22217-050000
2
79
CY-26116-050162
1
80
CY-26346-050002
Ex3200
DESCRIPTION
BUSH 17X19X10
ROD, MID PTO BRAKE
ROD, MID PTO BRAKE
END ASSY, ROD
NUT W/WASHER 8
END (L), ROD
ROD,MID
BELLOWS (B)
BEARING, ROD-END
NUT M 8
BELLOWS (A)
PIN 8X24
PIN 8X24
COLLAR 17*25*22
BOLT M16X 55 PLATED
LINER 17.2X30X1
WASHER 8, POLISHED
WASHER 10, POLISHED
WASHER 20, POLISHED
WASHER 8
WASHER 8
CIRCLIP E- 7
CIRCLIP E-15
CIRCLIP E-15
CIRCLIP E-19
COTTER PIN 2.5X30
COTTER PIN 2.5X30
COTTER PIN 2.5X30
SCREW M 6X 12
BOLT M 6X 12 PLATED
BOLT M 8X 16 PLATED
BOLT M 8X 20 PLATED
BOLT M 8X 20 PLATED
BOLT M10X 25 PLATED
NUT 10
NUT 8, LOCK
LEVER
SPRING WASHER 5
BOLT M 5X 16 PLATED
U-NUT, 5
QTY
2
2
1
1
1
1
1
1
1
1
1
2
4
2
2
1
1
2
1
3
4
1
1
1
1
2
2
4
1
3
1
3
1
2
1
2
1
2
2
2
