Front Axle Case - Cub Cadet Yanmar Ex32002 Part List Manual

Ex Series
REF
NO. PART NUMBER
1 CY-194447-13490
2 CY-194274-13570
3 CY-1A8160-13600
4 CY-194850-13660
5 CY-1A8160-13650
6 CY-1A8160-13660
7 CY-194850-13690
8 CY-22190-080000
9 CY-22252-000621
10 CY-22252-000680
11 CY-22312-080160
12 CY-24311-000180
13 CY-24321-000800
14 CY-24421-254208
15 CY-26108-100302
16 CY-26108-100302
17 CY-26116-080122
47
FIG. 16. FRONT AXLE CASE
DESCRIPTION
CAP W/DIPSTICK
SPRING WASHER 10
FRONT AXLE CASE CMP
BUSHING
CARRIER, DIFFERENTIAL
GASKET, CARRIER
NIPPLE M6F, GREASE
SEAL WASHER 8(BOLT)
CIRCRIP 62
CIRCLIP 68
PARALLEL PIN 8X 16
O-RING 1A P-18.0
O-RING 1A G-80.0
SEAL TC25 42 08, OIL
BOLT M10X 30 PLATED
BOLT M10X 30 PLATED
BOLT M 8X 12 PLATED
Copyright 2007 Cub Cadet Yanmar LLC
Ex3200
QTY
1
12
1
2
1
1
1
1
1
2
2
1
2
1
12
8
1
