Cub Cadet Yanmar Ex32002 Part List Manual page 9

Ex Series
REF
NO. PART NUMBER
1 CY-129004-11241
2 CY-129004-11251
4 CY-119802-11260
5 CY-119802-11270
6 CY-119802-11280
7 CY-129150-11280
8 CY-129004-11650
9 CY-129150-11230
11 CY-129150-11750
12 CY-129150-11370
13 CY-129008-11700
16 CY-120130-11860
18 CY-129150-11810
20 CY-27241-400000
21 CY-129005-11100
22 CY-129100-11112
23 CY-129795-11120
24 CY-129795-11180
25 CY-121400-11340
26 CY-124460-11340
27 CY-27310-080001
29 CY-119802-11870
30 CY-119625-11880
31 CY-129004-11900
32 CY-120270-54410
33 CY-22351-060012
34 CY-26106-080252
35 CY-26106-080352
36 CY-26106-080502
37 CY-129055-11350
38 CY-129004-03010
39 CY-129150-03070
40 CY-119802-03110
41 CY-119802-03121
42 CY-119802-03130
43 CY-119802-03141
45 CY-129004-11310
46 CY-22857-500100
47 CY-22857-500100
48 CY-124160-11360
49 CY-24311-000120
50 CY-129900-07900
51 CY-26106-080162
52 CY-119803-77830
53 CY-129008-77800
54 CY-129008-77820
9
FIG 4. CYLINDER HEAD & VALVE COVER
DESCRIPTION
SHAFT ASSY, ROCKER
SHAFT, ROCKER ARM
SUPPORT, ROCKER ARM
SUPPORT, ROCKER ARM
STUD, 8X18
SPRING
ARM ASSY, ROCKER
SCREW, VALVE
NUT M8XP1.0
CAP, VALVE
HEAD ASSY, CYLINDER
GUIDE, VALVE
GUIDE, VALVE
PLUG 40
VALVE, INTAKE
VALVE, EXHAUST
SPRING, VALVE
RETAINER, SPRING
SEAL, VALVE STEM
SEAL, VALVE STEM
COTTER 8
PROTECTOR, NOZZLE
SEAT, NOZZLE
RETAINER, NOZZLE
WASHER
SPRING PIN 6X12
BOLT M 8X 25 PLATED
BOLT M 8X 35 PLATED
BOLT M 8X 50 PLATED
COVER ASSY, VALVE
PLATE, BAFFLE
BAFFLE, BREATHER
PLATE, DIAPHRAGM
COVER, DIAPHRAGM
DIAPHRAGM
SPRING, DIAPHRAGM
GASKET, VALVE COVER
SCREW 5X10,TAPPING
SCREW 5X10,TAPPING
KNOB
O-RING 1A P 12.0
LIFTER, ENGINE
BOLT M 8X 16 PLATED
HARNESS, GLOW PLUG
PLUG, GLOW
CONNECTOR, GLOW PLUG
Copyright 2007 Cub Cadet Yanmar LLC
Ex3200
QTY
1
1
2
2
3
3
6
6
6
6
1
3
3
2
3
3
6
6
3
3
6
3
3
3
3
2
2
3
6
1
1
1
1
1
1
1
1
4
4
3
3
1
2
1
3
1
