Gear Housing - Cub Cadet Yanmar Ex32002 Part List Manual

Ex Series
REF
PART NUMBER
NO.
CY-729008-01500
1
CY-119934-01800
3
CY-129008-01520
4
CY-119802-01561
5
CY-129150-01580
6
CY-124160-01751
7
CY-124240-01871
8
CY-129795-01950
9
10 CY-119609-32040
CY-121850-51960
11
CY-129001-91841
12
13 CY-22190-080002
CY-22190-080002
14
CY-24311-000320
15
16 CY-26106-080162
CY-26106-080162
17
CY-26106-080302
18
19 CY-26106-080552
CY-26306-080002
20
CY-129150-91400
21
23 CY-24341-000240
CY-26106-060162
24
6
FIG. 2. GEAR HOUSING
DESCRIPTION
GEAR CASE ASSY W/SEAL
SEAL, OIL
FLANGE, GEAR CASE
STUD, M8X25
STUD 8 X 30
COVER, FILLER
COVER, HO-P
PIPE, KNOCK L=18
O-RING P16
O-RING, F.I.PUMP
BOLT, M8X85
SEAL WASHER 8S
SEAL WASHER 8S
O-RING 1A P-32.0
BOLT M 8X 16 PLATED
BOLT M 8X 16 PLATED
BOLT M 8X 30 PLATED
BOLT M 8X 55 PLATED
NUT
GEAR UNIT, TACHOMETER
O-RING 1A S-24.0
BOLT M 6X 16 PLATED
Copyright 2007 Cub Cadet Yanmar LLC
Ex3200
QTY
1
1
1
3
1
1
1
2
2
1
3
4
1
1
4
3
1
10
3
1
1
2
