Brake - Cub Cadet Yanmar Ex32002 Part List Manual

Ex Series
REF
NO. PART NUMBER
1 CY-194274-13580
2 CY-198200-36310
3 CY-198200-36341
4 CY-198200-36350
5 CY-198200-36380
6 CY-198200-36390
7 CY-198200-36410
8 CY-198200-36421
9 CY-22242-000260
10 CY-24190-170001
11 CY-26106-080252
12 CY-26376-120002
105
FIG. 67. BRAKE
DESCRIPTION
SPRING WASHER 12
ACTUATOR, L.H.
SHAFT, CAM
ARM, BRAKE
PLATE, FRICTION
PLATE
ACTUATOR, R.H.
HOLDER, BEARING
CIRCLIP 26
BALL 17/32
BOLT M 8X 25 PLATED
U-NUT M12
Copyright 2007 Cub Cadet Yanmar LLC
Ex3200
QTY
2
1
2
2
6
6
1
2
2
6
12
2
