Compak i3 PRO User Manual page 17

Fig. 6
12.4. REPLACING THE METAL GRID
The metal grid ensures consistency in the
dosage and minimizes static electricity
12.4.1 Located between the coffee exit chute
and the grinder's body, can be replaced after
removing the regulator from the grinder,
following the instructions up to step 12.3.3.
To remove it, use a Hex Allen key #3 to
loosen the two top screws (Fig. 8). And the
screw located beneath the coffee exit chute
(Fig. 9).
Fig. 8
K09639H01 | PROC-CAL/002/03 USER MANUAL | V. 27/09/2023
12.4.2 Partially move the display plastic
cover forward (Fig. 10). And then downward
along the coffee exit chute until it can be
completely freed (Fig. 11).
Fig. 7
12.4.3. Using a Hex Allen key #3, loosen
the two screws of the coffee exit chute and
remove it from the grinder body to gain
access to the metal grid (Fig. 12).
Fig. 9
12. MAINTENANCE
Fig. 10
Fig. 12
Fig. 11
17
