2. GETTING STARTED

2.1. STARTING THE DEVICE

The mains power switch of the product must be
accessible at any time, to allow disconnection of
the device.
1. Use the mains power switch located on the left side
panel to switch on the console.

2.2. INTERFACES

2.2.1. Console Screen
REF
1 Pressure (from 1 to 4 bar), increment of 0.1 bar
2 Frequency (from 1 to 25 Hz), increment of 1 Hz
3 Pulses remaining in treatment
4 Selected preset protocol
This is not a touchscreen. Use the buttons on the console to navigate the menus.
10
2.0
1
bar
15
2
Hz
3
2500
Impulses
4
SMART PROTOCOL
Figure 14
DESIGNATION
Figure 13
