AirLive GPON OLT-121 Setup Manual

Olt and onu in default configuration
Hide thumbs Also See for GPON OLT-121:

Advertisement

Quick Links

Setup guide for OLT and ONU in default
configuration
AirLive GPON OLT-121 and XPON ONU

Advertisement

loading
Need help?

Need help?

Do you have a question about the GPON OLT-121 and is the answer not in the manual?

Questions and answers

Summary of Contents for AirLive GPON OLT-121

  • Page 1 Setup guide for OLT and ONU in default configuration AirLive GPON OLT-121 and XPON ONU...
  • Page 2 How to setup the OLT and ONU in combination with a Router. For the setup an AirLive GPON OLT-121 and Airlive 2.5GE XPON ONU was used. The setup is following the below diagram, please do not use VLAN: 0, 1, 2, 9, 8, 10, 4000, 4005, 4012-4017, 4095.
  • Page 3 1: In the OLT Configuration select “VLAN” and make a VLAN ID in this example we make VLAN 100. 2: Bind the Uplink GE port go the “VLAN” >> “VLAN Port”, in this example all ports were binded to the VLAN100. Make sure the Uplink is in “Untag” mode. 3: When the Uplink port is in “Untag"...
  • Page 4 4: Adding the ONU to the OLT. Make sure the ONU has been connected to the OLT via its PON ports and a Splitter. Click on “ONU Configuration” and select “ONU Autofind” when your ONU has been connected correctly. It will show up here. Select the ONU you want to add (when there are several) and click on “Add”.
  • Page 5 5: Configure the ONU, Click on the “ONU List” in the top right corner of the OLT menu bar. The active ONU’s will now be shown, select the ONU you want to configure (make sure the status is “Online”) and click on the “Config” button. 6: Setup the ''tcont'', ''gemport'', ''Service'', ''Service Port'' and other parameters.
  • Page 6 Setup the “Service”, make sure to select Gemport ID 1 (the one just made) and for VLAN mode select “Tag” for “VLAN List” enter the value 100, this is the VLAN id made in the OLT previously. Setup the “PortVlan” On the ''PortVlan'' page, for HGU the mode needs to be configured for ''transparent'', the Port Type needs to be configured for ''veip'' and Port Id needs to be configured for ''1''.
  • Page 7 7: Setting up the WAN port information, click on the ''WAN'' page. Mode is Route, enable NAT, you can also choose three modes for Internet WAN connection. Here we use the DHCP mode. Then select the VLAN mode “Tag” in this example and fill in the VLAN information in this example 100.
  • Page 8 Important after pressing “Submit” your configuration is made but not yet sent to the ONU. After pressing “Submit” the configuration will be shown as in the below example. Click “Submit” again on the second “Submit” button and the configuration will be sent to the ONU.
  • Page 9 To see the settings of the ONU (which the OLT sent to the ONU), please connect to the ONU with a PC, and enter the default IP address of the ONU in a browser. The default IP address is 192.168.1.1 Note: to see and change the WAN port setup please login as Administrator and not as User.
