IOWA-MARK Half-size CPU Card
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IOWA-MARK-533-128MB-R10 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology IOWA-MARK-533-128MB-R10

Summary of Contents for IEI Technology IOWA-MARK-533-128MB-R10

  • Page 1 IOWA-MARK Half-size CPU Card Page i...
  • Page 2 IOWA-MARK Half-size CPU Card Revision MODEL IOWA-MARK VIA MARK Motherboard Revision Number Description Date of Issue Initial release December 2006 Page ii...
  • Page 3 IOWA-MARK Half-size CPU Card Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Packing List

    IOWA-MARK Half-size CPU Card Packing List NOTE: If any of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the IOWA-MARK from or contact an IEI sales representative directly.

  • Page 5: Table Of Contents

    IOWA-MARK Half-size CPU Card Table of Contents INTRODUCTION..................... 1 1.1 IOWA-MARK O ..................2 VERVIEW 1.1.1 IOWA-MARK Models..................2 1.1.2 IOWA-MARK Benefits..................2 1.1.3 IOWA-MARK Features..................3 1.2 IOWA-MARK O ..................4 VERVIEW 1.2.1 IOWA-MARK Connectors .................. 5 1.2.2 Technical Specifications..................6 DETAILED SPECIFICATIONS ................
  • Page 6 IOWA-MARK Half-size CPU Card 2.5.10 BIOS....................... 17 2.6 PCI B ........................18 2.6.1 Overview ......................18 2.6.2 10/100M Ethernet .................... 18 2.6.3 SATA Drive Controller ..................19 2.7 E ............19 NVIRONMENTAL AND OWER PECIFICATIONS 2.7.1 System Monitoring ................... 19 2.7.2 Operating Temperature and Temperature Control...........
  • Page 7 IOWA-MARK Half-size CPU Card 4.2.13 Keyboard/Mouse Connector ................45 4.2.14 LVDS LCD Connector ................... 46 4.2.15 Parallel Port Connector ................47 4.2.16 Power Button Connector................48 4.2.17 Reset Button Connector ................. 49 4.2.18 SATA Drive Connectors ................. 51 4.2.19 Serial Port Connector (COM 2) ..............52 4.2.20 TFT LCD Connector ..................
  • Page 8 IOWA-MARK Half-size CPU Card 5.7.1 Peripheral Device Cables ................76 5.7.2 ATA Flat Cable Connection ................76 5.7.3 Audio Kit Installation..................77 5.7.4 Single RS-232 Cable Connection..............79 5.7.5 SATA Drive Connection ................... 79 5.8 E ........... 81 XTERNAL ERIPHERAL NTERFACE ONNECTION 5.8.1 VGA Monitor Connection ................
  • Page 9 IOWA-MARK Half-size CPU Card B.1 DIO I ................166 NTERFACE NTRODUCTION B.2 DIO C ................... 166 ONNECTOR INOUTS B.3 A ................167 SSEMBLY ANGUAGE AMPLES B.3.1 Enable the DIO Input Function..............167 B.3.2 Enable the DIO Output Function ..............167 WATCHDOG TIMER ..................
  • Page 10 IOWA-MARK Half-size CPU Card List of Figures Figure 1-1: IOWA-MARK Overview ................4 Figure 1-2: IOWA-MARK Solder Side Overview ............5 Figure 2-1: IOWA-MARK Dimensions (mm)..............10 Figure 2-2: External Interface Panel Dimensions (mm)...........11 Figure 2-3: Data Flow Block Diagram................12 Figure 4-1: Connector and Jumper Locations ............28 Figure 4-2: Connector and Jumper Locations (Solder Side) ........29 Figure 4-3: AT Power Connector Location ...............31 Figure 4-4: Audio Connector Pinouts (10-pin) ............32...
  • Page 11 IOWA-MARK Half-size CPU Card Figure 4-24: -VCC Power Connector Pinout Locations...........56 Figure 4-25: IOWA-MARK On-board External Interface Connectors .....57 Figure 4-26: PS/2 Pinouts ...................58 Figure 4-27: J7 Connector ..................59 Figure 4-28: COM1 Pinout Locations ................60 Figure 4-29: VGA Connector ..................61 Figure 5-1: Installing a DIMM..................68 Figure 5-2: CF Card Installation .................70 Figure 5-3: Clear CMOS Jumper ................73...
  • Page 12 IOWA-MARK Half-size CPU Card Figure 7-16: Audio Driver Digital Signal ..............153 Figure 7-17: Audio Driver Installation Begins ............154 Figure 7-18: Audio Driver Installation Complete........... 155 Figure 7-19: Access the LAN Driver Folder ............156 Figure 7-20: Setup Utility Icon ................156 Figure 7-21: LAN Driver Welcome Screen .............
  • Page 13 IOWA-MARK Half-size CPU Card List of Tables Table 1-1: IOWA-MARK Model Specifications............2 Table 1-2: Technical Specifications ................7 Table 2-1: Supported HDD Specifications ..............14 Table 2-2: Power Consumption..................20 Table 3-1: Package List Contents................25 Table 4-1: Peripheral Interface Connectors..............30 Table 4-2: Rear Panel Connectors................31 Table 4-3: AT Power Connector Pinouts..............32 Table 4-4: Audio Connector Pinouts (10-pin) ............33 Table 4-5: Audio CD In Connector Pinouts...............34...
  • Page 14 IOWA-MARK Half-size CPU Card Table 4-24: -VCC Power Connector Pinouts.............56 Table 4-25: PS/2 Connector Pinouts .................58 Table 4-26: RJ-45 Ethernet Connector Pinouts............59 Table 4-27: J7 Connector LEDs .................59 Table 4-28: RS-232 Serial Port (COM 1) Pinouts ............60 Table 4-29: VGA Connector Pinouts .................61 Table 5-1: Jumpers......................71 Table 5-2: Clear CMOS Jumper Settings ..............72 Table 5-3: LVDS Voltage Selection Jumper Settings ..........74...
  • Page 15 IOWA-MARK Half-size CPU Card BIOS Menus Menu 1: Award BIOS CMOS Setup Utility ..............88 BIOS Menu 2: Standard CMOS Features ..............90 BIOS Menu 3: IDE Channel Master ................93 BIOS Menu 4: Advanced BIOS Features..............96 BIOS Menu 5: Advanced Chipset Features ............104 BIOS Menu 6: Integrated Peripherals..............
  • Page 16 IOWA-MARK Half-size CPU Card Glossary Input/Output AC ’97 Audio Codec 97 ACPI Advanced Configuration and L1 Cache Level 1 Cache Power Interface L2 Cache Level 2 Cache Advanced Power Management Liquid Crystal Display ARMD ATAPI Removable Media Device Parallel Port Connector ASKIR Shift Keyed Infrared LVDS...

  • Page 17: Introduction

    IOWA-MARK Half-size CPU Card Chapter Introduction Page 1...

  • Page 18: Iowa-Mark Overview

    VARs that want performance, reliability, and quality at a reasonable price. 1.1.1 IOWA-MARK Models The IOWA-MARK series has four models: IOWA-MARK-533-128MB-R10 IOWA-MARK-533S-128MB-R10 IOWA-MARK-800-128MB-R10 IOWA-MARK-800S-128MB-R10 The specifications for the four models are show in Table 1-1.

  • Page 19: Iowa-Mark Features

    IOWA-MARK Half-size CPU Card DMA (direct memory access) mode Multiple display output devices including VGA, TTL and LVDS are supported and dual-display configuration also supported Supported RAID function provides increased data safety Onboard CPU has long-term support until December 2010 1.1.3 IOWA-MARK Features Some of the IOWA-MARK features are listed below: Half-size form factor...

  • Page 20: Iowa-Mark Overview

    IOWA-MARK Half-size CPU Card 1.2 IOWA-MARK Overview Figure 1-1: IOWA-MARK Overview Page 4...

  • Page 21: Iowa-Mark Connectors

    IOWA-MARK Half-size CPU Card Figure 1-2: IOWA-MARK Solder Side Overview 1.2.1 IOWA-MARK Connectors The IOWA-MARK has the following connectors on-board: 1 x AT power connector 1 x Audio connector 1 x Backlight inverter connector 1 x Backplane to mainboarrd connector 1 x Battery connector 1 x CompactFlash socket 1 x Digital input/output (DIO) connector...

  • Page 22: Technical Specifications

    IOWA-MARK Half-size CPU Card 1 x Parallel port connector 1 x Power button connector 1 x Reset button connector 2 x Serial ATA (SATA) drive connectors (only for IOWA-MARK-533S and IOWA-MARK-800S) 1 x Serial port connector (internal COM 2) 1 x DIMM slot 1 x TFT LCD connector 2 x USB connectors The IOWA-MARK has the following external peripheral interface connectors on the board...

  • Page 23: Table 1-2: Technical Specifications

    IOWA-MARK Half-size CPU Card 24-bits TTL or dual channel 36-bits LVDS TTL/LVDS Supports one 512MB PC100MHz or PC133MHz SDRAM Memory DIMM module Award BIOS BIOS CompactFlash (CF) Type II Audio AC'97 Codec Realtek ALC655 10/100 Base-T RTL8100C Two RS-232 serial ports (one internal, one external) USB2.0 Four USB 1.1 devices supported One 40-pin IDE connects to two Ultra ATA33/66/100 devices...
  • Page 24 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 8...

  • Page 25: Detailed Specifications

    IOWA-MARK Half-size CPU Card Chapter Detailed Specifications Page 9...

  • Page 26: Overview

    IOWA-MARK Half-size CPU Card 2.1 Overview This chapter describes the specifications and on-board features of the IOWA-MARK in detail. 2.2 Dimensions 2.2.1 Board Dimensions The dimensions of the board are listed below: Length: 185mm Width: 122mm Figure 2-1: IOWA-MARK Dimensions (mm) 2.2.2 External Interface Panel Dimensions External peripheral interface connector panel dimensions are shown in Figure 2-2.

  • Page 27: Data Flow

    IOWA-MARK Half-size CPU Card Figure 2-2: External Interface Panel Dimensions (mm) 2.3 Data Flow The IOWA-MARK motherboard comes with a VIA MARK CPU and a VIA VT82C686B system chipset. Figure 2-3 shows the data flow between the system chipset, the CPU and other components installed on the motherboard.

  • Page 28: Cpu Support

    IOWA-MARK Half-size CPU Card Figure 2-3: Data Flow Block Diagram 2.4 CPU Support The IOWA-MARK series motherboards all come with a preinstalled 500MHz or 800MHz VIA MARK CPU. 2.4.1 VIA MARK Overview The specifications for the VIA MARK are listed below 533MHz or 800MHz CPU frequency 133MHz processor front side frequency 6W or 8W maximum thermal design power...

  • Page 29: Via Mark Memory Support

    IOWA-MARK Half-size CPU Card 133MHz SDR memory support S3 Graphics ProSavage4 integrated graphics Integrated LVDS transmitter Dual independent display supported ISA support 2.4.2 VIA MARK Memory Support The VIA Mark CoreFusion processor supports a single PC100MHz or PC133MHz SDRAM DIMM module with a maximum memory of 512MB. All the models are shipped with a 128MB DIMM module.

  • Page 30: System Chipset

    IOWA-MARK Half-size CPU Card 2.5 System Chipset The IOWA-MARK series motherboards all have a preinstalled VIA VT82C686B chipset. The system chipset features are listed below. Integrated AC'97 audio Integrated MC'97 modem Integrated Super I/O Hardware monitoring capabilities USB 1.1 controller 2.5.1 VIA VT82C686B ATA-6 Controller The single IOWA-MARK IDE connector supports two ATA-6 HDDs.

  • Page 31: Via Vt82C686B Flash Interface

    IOWA-MARK Half-size CPU Card 2.5.2 VIA VT82C686B Flash Interface The IOWA-MARK CompactFlash socket supports standard CF Type I and CF Type II cards. The chipset flash interface is multiplexed with an IDE interface and can be connected to an array of industry standard NAND Flash or NOR Flash devices. 2.5.3 VIA VT82C686B Audio Codec 97 (AC’97) Controller The AC’97 specification v2.3 compliant controller on the chipset is interfaced to a 16-bit full-duplex AC'97 2.3 RealTek ALC655 codec.

  • Page 32: Via Vt82C686B Usb Controller

    IOWA-MARK Half-size CPU Card Adjustable VREFOUT control Supports 48KHz S/PDIF output, complying with AC'97 Rev 2.3 specifications Supports 32K/44.1K/48KHz S/PDIF input Power support: Digital: 3.3V; Analog: 3.3V/5V Standard 48-pin LQFP package EAX™ 1.0 & 2.0 compatible Direct Sound 3D™ compatible A3D™...

  • Page 33: Via Vt82C686B Parallel Port Communications

    IOWA-MARK Half-size CPU Card Shift Keyed Infrared (ASKIR) 2.5.7 VIA VT82C686B Parallel Port Communications One internal parallel port connector on the IOWA-MARK board is connected to the VIA VT82C686B through the integrated Super I/O. The parallel port is bi-directional and supports the following parallel port modes: 2.5.8 VIA VT82C686B Keyboard and Mouse An internal keyboard/mouse connector and an external PS/2 keyboard connector are both...

  • Page 34: Pci Bus

    IOWA-MARK Half-size CPU Card 2.6 PCI Bus 2.6.1 Overview The PCI bus provides a PCI interface between the VIA MARK and the VIA VT82C686B. The PCI bus provides also provides a communication interface between the USB connectors and the USB 1.1 controller on the VIA VT82C686B. The SATA drives and the single RJ-45 Ethernet connector are also interfaced to the VIA MARK and VIA VT82C686B through the PCI bus.

  • Page 35: Sata Drive Controller

    IOWA-MARK Half-size CPU Card Half/Full duplex capability Supports Full Duplex Flow Control (IEEE 802.3x) Provides interface to 93C46 EEPROM to store resource configuration and ID parameters Provides PCI clock run pin Provides LED pins for network operation status indication 2.5/3.3V power supply with 5V tolerant I/Os 2.6.3 SATA Drive Controller An ALi M5283 SATA drive controller is connected to two SATA drive connectors and interfaced to the system through the PCI bus.

  • Page 36: Power Consumption

    IOWA-MARK Half-size CPU Card Minimum Operating Temperature: 0ºC (32°F) Maximum Operating Temperature: 60°C (140°F) The system is shipped with a preinstalled heat sink. When running the system do not remove the heat sink. If the heat sink is changed, make sure thermal paste is placed on the bottom of the heat sink to facilitate improved heat convection from the CPU surface to the heat sink.

  • Page 37: Unpacking

    IOWA-MARK Half-size CPU Card Chapter Unpacking Page 21...

  • Page 38: Anti-Static Precautions

    IOWA-MARK Half-size CPU Card 3.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the IOWA-MARK may result in permanent damage to the IOWA-MARK and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IOWA-MARK.

  • Page 39: Unpacking Checklist

    IOWA-MARK Half-size CPU Card 3.3 Unpacking Checklist NOTE: If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the IOWA-MARK from or contact an IEI sales representative directly.
  • Page 40 IOWA-MARK Half-size CPU Card ATA 66/100 flat cable (P/N: 32200-000052-RS) KB/MS PS/2 Y-cable (P/N: 32000-072101-RS) Single RS-232 cable (P/N: 19800-000047-RS) SATA cables (P/N: 32000-062800-RS) SATA power cable (P/N: 32100-088600-RS) Mini jumper Pack Page 24...

  • Page 41: Table 3-1: Package List Contents

    IOWA-MARK Half-size CPU Card Quick Installation Guide Utility CD Table 3-1: Package List Contents Page 25...
  • Page 42 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 26...

  • Page 43: Connector Pinouts

    IOWA-MARK Half-size CPU Card Chapter Connector Pinouts Page 27...

  • Page 44: Peripheral Interface Connectors

    IOWA-MARK Half-size CPU Card 4.1 Peripheral Interface Connectors Section 4.1.2 shows peripheral interface connector locations. Section 4.1.2 lists all the peripheral interface connectors seen in Section 4.1.2. 4.1.1 IOWA-MARK Layout Figure 4-1 shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers.

  • Page 45: Peripheral Interface Connectors

    IOWA-MARK Half-size CPU Card Figure 4-2: Connector and Jumper Locations (Solder Side) 4.1.2 Peripheral Interface Connectors Table 4-1 shows a list of the peripheral interface connectors on the IOWA-MARK. Detailed descriptions of these connectors can be found below. Connector Type Label AT power connector 4-pin header...

  • Page 46: External Interface Panel Connectors

    IOWA-MARK Half-size CPU Card IDE Interface connector 40-pin header Infrared interface connector 5-pin header CN19 Inverter power connector 5-pin wafer CN21 Keyboard/mouse connector 6-pin wafer CN22 LED connector 6-pin wafer CN25 LVDS LCD connector 30-pin crimp CN16 Parallel port connector 26-pin header Power button connector 2-pin wafer...

  • Page 47: Internal Peripheral Connectors

    IOWA-MARK Half-size CPU Card Keyboard/mouse port PS/2 CN12 VGA port connector 15-pin female Table 4-2: Rear Panel Connectors 4.2 Internal Peripheral Connectors Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the IOWA-MARK.

  • Page 48: Audio Connector (10-Pin)

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION +12V Table 4-3: AT Power Connector Pinouts 4.2.2 Audio Connector (10-pin) CN Label: CN Type: 10-pin header CN Location: See Figure 4-4 See Table 4-4 CN Pinouts: The 10-pin audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system.

  • Page 49: Audio Cd In Connector (4-Pin)

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION PIN NO. DESCRIPTION Line out R Line in R Line out L Line in L MIC in Table 4-4: Audio Connector Pinouts (10-pin) 4.2.3 Audio CD In Connector (4-pin) CN Label: CN Type: 4-pin header CN Location: See Figure 4-5...

  • Page 50: Backlight Inverter Connector

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION CD Signal (Left) Ground Ground CD Signal (Right) Table 4-5: Audio CD In Connector Pinouts 4.2.4 Backlight Inverter Connector CN Label: CN21 CN Type: 5-pin wafer (1x5) CN Location: See Figure 4-6 See Table 4-6 CN Pinouts: The backlight inverter connector provides the backlight on the LCD display connected to the IOWA-MARK with +12V of power.

  • Page 51: Backplane To Mainboard Connector

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION Ground Ground +12V Ground LCD Enable Table 4-6: Panel Backlight Connector Pinouts 4.2.5 Backplane to Mainboard Connector CN Label: CN29 CN Type: 3-pin wafer (1x3) CN Location: See Figure 4-7 CN Pinouts: See Table 4-7 The backplane to mainboard connector closes the circuit between the mainboard and the backplane in which it is installed.

  • Page 52: Battery Connector

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION PS_ON# 5VSB Table 4-7: Backplane to Mainboard Connector Pinouts 4.2.6 Battery Connector CN Label: CN15 CN Type: 2-pin wafer (1x2) CN Location: See Figure 4-8 See Table 4-8 CN Pinouts: The battery connector is connected to a backup battery. The battery connector is also used to reset the CMOS memory if the incorrect BIOS settings have been made and the system cannot boot up.

  • Page 53: Compact Flash Socket

    IOWA-MARK Half-size CPU Card Ground Table 4-8: Battery Connector Pinouts 4.2.7 Compact Flash Socket CN Label: CN30 (solder side) CN Type: 50-pin header (2x25) CN Location: See Figure 4-9 CN Pinouts: See Table 4-9 A CF Type I or Type II memory card is inserted to the CF socket on the solder side of the IOWA-MARK.

  • Page 54: Digital Input/Output (Dio) Connector

    IOWA-MARK Half-size CPU Card DATA 3 DATA 11 DATA 4 DATA 12 DATA 5 DATA 13 DATA 6 DATA 14 DATA 7 DATA 15 HDC_CS0# HDC_CS1 GROUND IOR# IOW# VCC_COM IRQ15 VCC_COM VCC_COM CSEL HDD_RESET IORDY SDREQ SDACK# HDD_ACTIVE# DATA 0 66DET DATA 1 DATA 8...

  • Page 55: Fan Connector (+5V)

    IOWA-MARK Half-size CPU Card The digital input/output connector is managed through a Super I/O chip. The DIO connector pins are user programmable. Figure 4-10: DIO Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION Ground Output 0 Output 1 Output 2 Output 3 Input 0 Input 1...

  • Page 56: Floppy Disk Connector

    IOWA-MARK Half-size CPU Card The cooling fan connector provides a 5V, 500mA current to a system cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed. Please note that only specified fans can issue the rotation signals.

  • Page 57: Figure 4-12: 34-Pin Fdd Connector Location

    IOWA-MARK Half-size CPU Card The floppy disk connector is connected to a floppy disk drive. Figure 4-12: 34-pin FDD Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION REDUCE WRITE INDEX# MOTOR ENABLE A# DRIVE SELECT B# DRIVE SELECT A# MOTOR ENABLE B# DIRECTION# STEP# WRITE DATA#...

  • Page 58: Ide Connector (40-Pin)

    IOWA-MARK Half-size CPU Card SIDE 1 SELECT# DISK CHANGE# Table 4-12: 34-pin FDD Connector Pinouts 4.2.11 IDE Connector (40-pin) CN Label: 40-pin header (2x20) CN Type: CN Location: See Figure 4-13 CN Pinouts: See Table 4-13 One 40-pin IDE device connector on the IOWA-MARK supports connectivity to two hard disk drives.

  • Page 59: Figure 4-13: Ide Device Connector Locations

    IOWA-MARK Half-size CPU Card Figure 4-13: IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14...

  • Page 60: Infrared Interface Connector (5-Pin)

    IOWA-MARK Half-size CPU Card HDC CS0# HDC CS1# HDD ACTIVE# GROUND Table 4-13: IDE Connector Pinouts 4.2.12 Infrared Interface Connector (5-pin) CN Label: CN19 CN Type: 5-pin header (1x5) CN Location: See Figure 4-14 CN Pinouts: See Table 4-14 The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift Key Infrared (ASKIR) interfaces.

  • Page 61: Keyboard/Mouse Connector

    IOWA-MARK Half-size CPU Card IR-TX Table 4-14: Infrared Connector Pinouts 4.2.13 Keyboard/Mouse Connector CN Label: CN22 CN Type: 6-pin header (1x6) CN Location: See Figure 4-15 CN Pinouts: See Table 4-15 The keyboard and mouse connector can be connected to a standard PS/2 cable or PS/2 Y-cable to add keyboard and mouse functionality to the system.

  • Page 62: Lvds Lcd Connector

    IOWA-MARK Half-size CPU Card KB CLK GROUND Table 4-15: Keyboard/Mouse Connector Pinouts 4.2.14 LVDS LCD Connector CN Label: CN16 30-pin crimp (2x15) CN Type: CN Location: See Figure 4-16 CN Pinouts: See Table 4-16 The 30-pin LVDS LCD connector can be connected to single channel or dual channel, 18-bit or 36-bit LVDS panel.

  • Page 63: Parallel Port Connector

    IOWA-MARK Half-size CPU Card LVDSA_Y2+ LVDSA_Y2- LVDSA_CLK+ LVDSA_CLK- GROUND GROUND LVDSB_Y0+ LVDSB_Y0- LVDSB_Y1+ LVDSB_Y1- LVDSB_Y2+ LVDSB_Y2- LVDSB_CLK+ LVDSB_CLK- GROUND GROUND VCC_LVDS VCC_LVDS VCC_LVDS VCC_LVDS Table 4-16: LVDS LCD Port Connector Pinouts 4.2.15 Parallel Port Connector CN Label: 26-pin box header CN Type: CN Location: See Figure 4-17...

  • Page 64: Power Button Connector

    IOWA-MARK Half-size CPU Card Figure 4-17: Parallel Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# AUTO FORM FEED # DATA 0 ERROR# DATA 1 INITIALIZE DATA 2 PRINTER SELECT LN# DATA 3 GROUND DATA 4 GROUND DATA 5 GROUND DATA 6 GROUND...

  • Page 65: Reset Button Connector

    IOWA-MARK Half-size CPU Card 2-pin wafer (1x2) CN Type: CN Location: See Figure 4-18 CN Pinouts: See Table 4-18 The power button connector is connected to a power switch on the system chassis to enable users to turn the system on and off. Figure 4-18: Power Button Connector Location PIN NO.

  • Page 66: Figure 4-19: Reset Button Connector Locations

    IOWA-MARK Half-size CPU Card See Table 4-19 CN Pinouts: The reset button connector is connected to a reset switch on the system chassis to enable users to reboot the system when the system is turned on. Figure 4-19: Reset Button Connector Locations Page 50...

  • Page 67: Sata Drive Connectors

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION Reset Switch Table 4-19: Reset Button Connector Pinouts 4.2.18 SATA Drive Connectors CN Label: CN13 and CN14 7-pin SATA drive connectors CN Type: CN Location: See Figure 4-20 CN Pinouts: See Table 4-20 The two SATA drive connectors are each connected to a first generation SATA drive.

  • Page 68: Serial Port Connector (Com 2)

    IOWA-MARK Half-size CPU Card Table 4-20: SATA Drive Connector Pinouts 4.2.19 Serial Port Connector (COM 2) CN Label: CN17 10-pin header (2x5) CN Type: CN Location: See Figure 4-21 CN Pinouts: See Table 4-21 The 10-pin serial port connector provides a second RS-232 serial communications channel.

  • Page 69: Tft Lcd Connector

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data Carrier Direct (DCD) Data Set Ready (DSR) Receive Data (RXD) Request To Send (RTS) Transmit Data (TXD) Clear To Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) Ground (GND) Table 4-21: COM 2 Connector Pinouts 4.2.20 TFT LCD Connector...

  • Page 70: Internal Usb Connectors (Internal)

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC_FP VCC_FP GROUND GROUND VCC_FP VCC_FP GROUND GROUND GROUND FPCLK FPVS FPDEN FPHS ENVEE Table 4-22: TFT LCD Port Connector Pinouts NOTE: For 18-bits RGB mapping: (R2 ~ R7 , G2 ~ G7 , B2 ~ B7). For 24-bits RGB mapping: (R0 ~ R7 , G0 ~ G7 , B0 ~ B7) 4.2.21 Internal USB Connectors (Internal) CN Label:...

  • Page 71: Figure 4-23: Usb Connector Pinout Locations

    IOWA-MARK Half-size CPU Card 8-pin header (2x4) CN Type: CN Location: See Figure 4-23 CN Pinouts: See Table 4-23 The 2x4 USB pin connectors each provide connectivity to two USB 1.1 ports. Each USB connector can support two USB devices. Additional external USB ports are found on the rear panel.

  • Page 72: Vcc Power Connectors

    IOWA-MARK Half-size CPU Card 4.2.22 -VCC Power Connectors CN Label: CN23 and CN1 3-pin header (1 x 3) CN Type: CN Location: See Figure 4-23 CN Pinouts: See Table 4-23 The –VCC power connector provides –5V and –12V power to legacy expansion ISA devices installed on the backplane.

  • Page 73: External Peripheral Interface Connectors

    IOWA-MARK Half-size CPU Card 4.3 External Peripheral Interface Connectors 4.3.1 External Peripheral Interface Connector Overview The IOWA-MARK external peripheral interface connectors are listed below and shown in Figure 4-25: 1 x PS/2 Keyboard/,ouse connector 1 x RJ-45 Ethernet connector 1 x Serial communications port 1 x VGA port Figure 4-25: IOWA-MARK On-board External Interface Connectors 4.3.2 PS/2 Keyboard/Mouse Connector...

  • Page 74: Ethernet Connector

    IOWA-MARK Half-size CPU Card Figure 4-26: PS/2 Pinouts DESCRIPTION DESCRIPTION KB_DATA MS_DATA KB_CLOCK MS_CLOCK Table 4-25: PS/2 Connector Pinouts 4.3.3 RJ-45 Ethernet Connector CN Label: CN10 CN Type: RJ-45 CN Location: See Figure 4-25 CN Pinouts: See Table 4-26 The RJ-45 Ethernet connector on the IOWA-MARK provides connectivity to a 10/100 megabit Ethernet connection between the IOWA-MARK and a Local Area Network (LAN) through a network hub.

  • Page 75: Serial Port Connector (Com 1)

    IOWA-MARK Half-size CPU Card PIN NO. DESCRIPTION Table 4-26: RJ-45 Ethernet Connector Pinouts Figure 4-27: J7 Connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. SPEED LED LINK LED Status...

  • Page 76: Vga Connector

    IOWA-MARK Half-size CPU Card See Figure 4-25 CN Location: CN Pinouts: See Table 4-28 and Figure 4-28 The 9-pin DB-9 COM 1 serial port connector is connected to RS-232 serial communications devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION DCD1 RXD1 TXD1 DTR1 DSR1...

  • Page 77: Figure 4-29: Vga Connector

    IOWA-MARK Half-size CPU Card The standard 15-pin female DB15 VGA connector connects to a CRT or LCD monitor directly. DESCRIPTION DESCRIPTION DESCRIPTION GROUND GREEN GROUND DDCDAT BLUE GROUND HSYNC VSYNC GROUND GROUND DDCCLK Table 4-29: VGA Connector Pinouts Figure 4-29: VGA Connector Page 61...
  • Page 78 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 62...

  • Page 79: Installation

    IOWA-MARK Half-size CPU Card Chapter Installation Page 63...

  • Page 80: Anti-Static Precautions

    IOWA-MARK Half-size CPU Card 5.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the IOWA-MARK may result in permanent damage to the IOWA-MARK and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IOWA-MARK.

  • Page 81: Installation Considerations

    IOWA-MARK Half-size CPU Card 5.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before the IOWA-MARK is installed. All installation notices pertaining to the installation of the IOWA-MARK should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the IOWA-MARK and injury to the person installing the motherboard.

  • Page 82: Installation Checklist

    IOWA-MARK Half-size CPU Card When working with the IOWA-MARK, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the IOWA-MARK DO NOT: Remove any of the stickers on the PCB board. These stickers are required for warranty validation.

  • Page 83: Unpacking

    IOWA-MARK Half-size CPU Card Keyboard Mouse RS-232 serial communications device Parallel port 5.3 Unpacking 5.3.1 Unpacking Precautions When the IOWA-MARK is unpacked, please do the following: Follow the anti-static precautions outlined in Section 5.1. Make sure the packing box is facing upwards so the IOWA-MARK does not fall out of the box.

  • Page 84: Figure 5-1: Installing A Dimm

    IOWA-MARK Half-size CPU Card Figure 5-1: Installing a DIMM Step 1: Open the DIMM socket handles. The DIMM socket has two handles that secure the DIMM into the socket. Before the DIMM can be inserted into the socket, the handles must be opened. See Figure 5-1. Step 2: Align the DIMM with the socket.

  • Page 85: Cf Card Installation

    IOWA-MARK Half-size CPU Card 5.4.2 CF Card Installation NOTE: The IOWA-MARK can support both CF Type I cards and CF Type II cards. For the complete specifications of the supported CF cards please refer to Chapter 2. To install the a CF card (Type 1 or Type 2) onto the IOWA-MARK, please follow the steps below: Step 1: Locate the CF card socket.

  • Page 86: Figure 5-2: Cf Card Installation

    IOWA-MARK Half-size CPU Card Figure 5-2: CF Card Installation Page 70...

  • Page 87: Jumper Settings

    IOWA-MARK Half-size CPU Card 5.5 Jumper Settings NOTE: A jumper is a metal bridge that is used to close an electrical circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 88: Table 5-2: Clear Cmos Jumper Settings

    IOWA-MARK Half-size CPU Card If the IOWA-MARK fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 89: Ttl And Lvds Voltage Selection

    IOWA-MARK Half-size CPU Card Figure 5-3: Clear CMOS Jumper 5.5.2 TTL and LVDS Voltage Selection WARNING: Permanent damage to the screen and IOWA-MARK may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that cam with the monitor to select the correct voltage. Jumper Label: Jumper Type: 3-pin header...

  • Page 90: Figure 5-4: Lvds Voltage Selection Jumper Pinout Locations

    IOWA-MARK Half-size CPU Card See Figure 5-4 Jumper Location: The LVDS Voltage Selection jumper allows the LVDS screen voltage to be set. The LVDS Voltage Selection jumper settings are shown in Table 5-3. AT Power Select Description Short 1-2 +3.3V LVDS Default Short 2-3 +5V LVDS...

  • Page 91: Chassis Installation

    IOWA-MARK Half-size CPU Card 5.6 Chassis Installation 5.6.1 Airflow WARNING: Airflow is critical to the cooling of the CPU and other onboard components. The chassis in which the IOWA-MARK must have air vents to allow cool air to move into the system and hot air to move out. The IOWA-MARK must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface.

  • Page 92: Cpu Card Installation

    IOWA-MARK Half-size CPU Card NOTE: IEI has a wide range of backplanes available. Please contact your IOWA-MARK vendor, reseller or an IEI sales representative at sales@iei.com.tw or visit the IEI website (http://www.ieiworld.com.tw) to find out more about the available chassis. 5.6.3 CPU Card Installation To install the IOWA-MARK CPU card onto the backplane, carefully align the CPU card interface connectors with the corresponding socket on the backplane.

  • Page 93: Audio Kit Installation

    IOWA-MARK Half-size CPU Card The ATA 66/100 flat cable connects to the IOWA-MARK to one or two IDE devices. To connect an IDE HDD to the IOWA-MARK please follow the instructions below. Step 1: Locate the IDE connector. The location/s of the IDE device connector/s is/are shown in Chapter 3.

  • Page 94: Figure 5-6: Ide Cable Connection

    IOWA-MARK Half-size CPU Card The Audio Kit that came with the IOWA-MARK connects to the 10-pin audio connector on the IOWA-MARK. The audio kit consists of three audio jacks. One audio jack, Mic In, connects to a microphone. The remaining two audio jacks, Line-In and Line-Out, connect to two speakers.

  • Page 95: Single Rs-232 Cable Connection

    IOWA-MARK Half-size CPU Card 5.7.4 Single RS-232 Cable Connection The single RS-232 cable consists of one serial port connectors attached to a serial communications cable that is then attached to a D-sub 9 male connector that is mounted onto a bracket. To install the single RS-232 cable, please follow the steps below. Step 1: Locate the connector.

  • Page 96: Figure 5-8: Sata Drive Cable Connection

    IOWA-MARK Half-size CPU Card The IOWA-MARK is shipped with two SATA drive cables and one SATA drive power cable. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors. The locations of the SATA drive connectors are shown in Chapter 3.

  • Page 97: External Peripheral Interface Connection

    IOWA-MARK Half-size CPU Card Figure 5-9: SATA Power Drive Connection 5.8 External Peripheral Interface Connection The following external peripheral devices can be connected to the external peripheral interface connectors. Serial port devices VGA monitors Parallel port devices RJ-45 Ethernet cable connectors Mouse and keyboard To install these devices, connect the corresponding cable connector from the actual device to the corresponding IOWA-MARK external peripheral interface connector making...

  • Page 98: Vga Monitor Connection

    IOWA-MARK Half-size CPU Card 5.8.1 VGA Monitor Connection The IOWA-MARK has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the IOWA-MARK, please follow the instructions below. Step 1: Locate the female DB-15 connector.

  • Page 99: Ps/2 Keyboard And Mouse Y-Cable Connection

    IOWA-MARK Half-size CPU Card side of the connector. Step 0: 5.8.2 PS/2 Keyboard and Mouse Y-Cable Connection The IOWA-MARK is shipped with a PS/2 keyboard/mouse Y-cable connector. The keyboard/mouse Y-cable connector connects to a PS/2 keyboard/mouse connector on the IOWA-MARK and branches into two cables that are each connected to a PS/2 connector, one for a mouse and one for a keyboard.

  • Page 100: Figure 5-11: Ps/2 Connector

    IOWA-MARK Half-size CPU Card Figure 5-11: PS/2 Connector Step 4: Connect the keyboard and mouse. Connect the keyboard and mouse to the respective PS/2 connector on the Y-cable. Each PS/2 has an embossed image showing the device the connector must be connected to. If the mouse is connected to the keyboard connector and vice/versa, both the keyboard and mouse do not work.

  • Page 101: Award Bios

    IOWA-MARK Half-size CPU Card Chapter AWARD BIOS Page 85...

  • Page 102: Introduction

    IOWA-MARK Half-size CPU Card 6.1 Introduction A licensed copy of Phoenix Award BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 103: Getting Help

    IOWA-MARK Half-size CPU Card General help, only for Status Page Setup Menu and Option Page Setup Menu Item help Previous values for the page menu items Fail-safe defaults for the current page menu items Optimized defaults for the current page menu items Menu in BIOS Save changes and Exit BIOS Table 6-1: BIOS Navigation Keys...

  • Page 104: Menu 1: Award Bios Cmos Setup Utility

    IOWA-MARK Half-size CPU Card BIOS Menu 1: Award BIOS CMOS Setup Utility NOTE: The following sections will completely describe the menus listed below and the configuration options available to users. The following menu options are seen in BIOS Menu 1. Standard CMOS Features: Changes the basic system configuration.
  • Page 105 IOWA-MARK Half-size CPU Card Load Fail-Safe Defaults Use the Load Fail-Safe Defaults option to load failsafe default values for each BIOS parameter in the setup menus. Press F6 for this operation on any page. Load Optimized Defaults Use the Load Optimized Defaults option to load optimal default values for each BIOS parameter in the setup menus.

  • Page 106: Standard Cmos Features

    IOWA-MARK Half-size CPU Card Use the Exit Without Saving option to exit the BIOS menus without saving any configuration changes. 6.2 Standard CMOS Features Use the Standard CMOS Features BIOS menu (BIOS Menu 2) to set basic BIOS configuration options. BIOS Menu 2: Standard CMOS Features Date [Day mm:dd:yyyy] Use the Date option to set the system date...
  • Page 107 IOWA-MARK Half-size CPU Card IDE Primary Master IDE Primary Slave IDE Secondary Master IDE Secondary Slave IDE device configurations are changed or set in the IDE Configuration menu (BIOS Menu 3). If an IDE device is detected, and one of the above listed two BIOS configuration options is selected, the IDE configuration options shown in Section 6.2.1 appear.

  • Page 108: Ide Primary Master/Slave

    IOWA-MARK Half-size CPU Card All Errors Whenever BIOS detects a non-fatal error the system is stopped and the user prompted. The system boot is not stopped for any errors No Errors that may be detected. All, But Keyboard (Default) The system boot does not stop for a keyboard error;...

  • Page 109: Bios Menu 3: Ide Channel Master

    IOWA-MARK Half-size CPU Card BIOS Menu 3: IDE Channel Master IDE HDD Auto-Detection [Press Enter] Use the IDE HDD Auto-Detection option to enable BIOS to automatically detect the IDE settings. Select IDE HDD Auto-Detection and press E . BIOS automatically detects NTER the HDD type.
  • Page 110 IOWA-MARK Half-size CPU Card inaccessible and any drives attached to it are undetected. Auto (Default) Setting this option allows the device to be automatically detected by the BIOS. Manual Selecting this option allows manual configuration of the device on the IDE channel in BIOS. Access Mode [Auto] The Access Mode option can only be configured if the BIOS configuration option is set to either Manual or Auto..

  • Page 111: Advanced Bios Features

    IOWA-MARK Half-size CPU Card The Cylinder specification indicates how many cylinders (tracks) are on the HDD installed in the system. Head The Head specification indicates how many logical heads are on the HDD installed in the system. Precomp The Precomp specification indicates on what track the write precompensation begins. Landing Zone The Landing Zone specification indicates where the disk head will park itself after the system powers off.

  • Page 112: Bios Menu 4: Advanced Bios Features

    IOWA-MARK Half-size CPU Card BIOS Menu 4: Advanced BIOS Features Virus Warning [Disabled] NOTE: Many disk diagnostic programs can cause the above warning message Page 96...
  • Page 113 IOWA-MARK Half-size CPU Card to appear when the program attempts to access the boot sector table. If you are running such a program, it is recommended that the virus protection function be disabled beforehand. Use the Virus Warning option to enable BIOS to monitor the boot sector and partition table of the HDD for any attempted modification.
  • Page 114 IOWA-MARK Half-size CPU Card Use the CPU L2 Cache ECC Checking option to enable memory checking when the external cache contains ECC SRAM (Static Random Access Memory). Disabled Memory checking disabled Enabled (Default) Memory checking enabled Quick Power On Self Test [Enabled] Use the Quick Power On Self Test option to speed up the POST after the computer is turned on.
  • Page 115 IOWA-MARK Half-size CPU Card Use the Boot Device options to select the order of the devices the system boots from. There are three boot device configuration options: First Boot Device [Default: Floppy] Second Boot Device [Default: HDD-0] Third Boot Device [Default: LS-120] Using the default values, the system first looks for a FDD to boot from.
  • Page 116 IOWA-MARK Half-size CPU Card devices if the first one is not found. Enabled (Default) The system looks for second and third boot devices if the first one is not found. Swap Floppy Drive Use the Swap Floppy Drive option to designate drive A as drive B and drive B as drive A. (Default) Cannot designate A or B to a floppy drive without Disabled...
  • Page 117 IOWA-MARK Half-size CPU Card (Default) Activates the keys on the keypad. Gate A20 Option [Fast] Use the Gate A20 Option option to set if the keyboard controller or the chipset controls the Gate A20 switching. The keyboard controller does the switching. Normal Fast (Default)
  • Page 118 IOWA-MARK Half-size CPU Card 20 characters per second 24 characters per second 30 characters per second Typematic Delay (Msec) [250] The Typematic Rate option can only be configured if the Typematic Rate Setting is enabled. Use the Typematic Delay option to specify the delay time between when a key is first pressed and when the acceleration begins.
  • Page 119 IOWA-MARK Half-size CPU Card and Setup can be accessed. OS Select For DRAM > 64MB [Non-OS2] Use the OS Select For DRAM > 64MB option to specify the operating system. Specifies the operating system used as OS/2. Non-OS2 (Default) Select this option when not using the OS/2 operating system.

  • Page 120: Advanced Chipset Features

    IOWA-MARK Half-size CPU Card Disabled (Default) EPA logo does not appear during boot up. Enabled EPA logo appears during boot up. 6.4 Advanced Chipset Features Use the Advanced Chipset Features menu (BIOS Menu 5) to change chipset configuration options. BIOS Menu 5: Advanced Chipset Features DRAM Timing by SPD [Enabled] Use the DRAM Timing by SPD option to enable the system to use the SPD (Serial Presence Detect) EEPROM to configure the DRAM timing.
  • Page 121 IOWA-MARK Half-size CPU Card and the manufacturer's code. The SPD enables the BIOS to read the spec sheet of the DIMM on boot-up and then adjust the memory timing parameters accordingly. Disabled DRAM timing parameters can be manually set using the DRAM sub-items DRAM timing parameter are set according to the Enabled...
  • Page 122 IOWA-MARK Half-size CPU Card Use the Bank Interleave option to specify how multiple modules communicate with each other. Interleaving enables access to a second memory bank when the first memory bank is being accessed. The following configuration options are available: Disabled (D EFAULT 2 Bank...
  • Page 123 IOWA-MARK Half-size CPU Card Disabled System BIOS not written to F0000h-FFFFFh EFAULT Enabled System BIOS is written to F0000h-FFFFFh Video RAM Cacheable [Disabled] Use the Video RAM Cacheable option to enable caching of the video BIOS ROM at C0000h-C7FFFh via the L2 cache. Disabled Video BIOS not written to C0000h-C7FFFh EFAULT...
  • Page 124 IOWA-MARK Half-size CPU Card AGP-4X Mode [Enabled] Use the AGP-4X Mode to enable AGP 4x support on the system. Disabled AGP only uses the AGP 1x or AGP 2x transfer protocol. Enabled AGP uses the AGP 4x EFAULT AGP Driving Control [Auto] Use the AGP Driving Control option to enable manual or automatic selection of the AGP bus signal strength.
  • Page 125 IOWA-MARK Half-size CPU Card An LCD display is connected to the system CRT + LCD A CRT display and an LCD display are connected to the system simultaneously. This option should be set for dual independent display mode. Panel Type [1024 x 768 TFT] Use the Panel Type option to specify the type of panel connected to the system.
  • Page 126 IOWA-MARK Half-size CPU Card USB Keyboard Support [Disabled] Use the USB Keyboard Support option to enable or disable the use of a USB keyboard. Disabled USB keyboard cannot be used EFAULT Enabled USB keyboard can be used OnChip Sound [Auto] Use the OnChip Sound option to enable or disable the chipset codec.
  • Page 127 IOWA-MARK Half-size CPU Card Disabled (Default) No buffering when writes from the CPU to the PCI bus occurs Buffering when writes from the CPU to the PCI bus Enabled occurs PCI Dynamic Bursting [Enabled] Use the PCI Dynamic Bursting option to enable every write transaction to go to the write buffer and then allow burstable transactions then burst on the PCI bus and nonburstable transactions do not.

  • Page 128: Integrated Peripherals

    IOWA-MARK Half-size CPU Card PCI #2 Access #1 Retry [Enabled] Use the PCI #2 Access #1 Retry option to enable the buffer to continue to attempt to write to the buffer until it is successful. Disabled (Default) If the buffer is unable to write to the PCI bus on the first attempt, the buffer is wiped clean and the transaction registered as failed.

  • Page 129: Bios Menu 6: Integrated Peripherals

    IOWA-MARK Half-size CPU Card BIOS Menu 6: Integrated Peripherals On-Chip IDE Channel 0/1 [Enabled] Use the On-Chip IDE Channel 0/1 option to specify if the system uses the integrated primary IDE channel or not. Disabled The primary IDE channel is not used. Page 113...
  • Page 130 IOWA-MARK Half-size CPU Card Enabled (Default) The primary IDE channel is used. IDE Prefetch Mode [Enabled] Use the IDE Prefetch Mode option enable IDE pre-fetching for faster drive access. Disabled Disable this option if the system IDE devices do not support IDE pre-fetching Enabled (Default)
  • Page 131 IOWA-MARK Half-size CPU Card Auto (Default) The computer selects the correct UDMA. Disabled The UDMA for the HDD device is disabled. Init Display First [PCI Slot] Use the Init Display First option to select the primary display device. (Default) The display connected to the PCI slot is the primary PCI Slot display The AGP display is the primary display...
  • Page 132 IOWA-MARK Half-size CPU Card Onboard Serial Port 1 [3F8/IRQ4] Use the Onboard Serial Port 1 option to select the I/O address and IRQ for the onboard serial port 1. The serial port can be disabled or the I/O address and the IRQ can be automatically selected by the BIOS.
  • Page 133 IOWA-MARK Half-size CPU Card Use the IR Function Duplex option to enable bi-directional communication between the system infrared port and the external device. Full Bi-directional communication between system infrared port and the external compliant devices occurs. (Default) Communication between the system infrared port and Half the external compliant devices occurs is a single direction at a time only.
  • Page 134 IOWA-MARK Half-size CPU Card The parallel port operates in the enhanced parallel port mode (EPP). The EPP mode supports bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster than the SPP mode. The parallel port operates in the extended capabilities port (ECP)
  • Page 135 IOWA-MARK Half-size CPU Card EPP1.7 (Default) EPP 1.7 is selected as the EPP standard. Onboard Legacy Audio [Enabled] Use the Onboard Legacy Audio option to enable any legacy audio devices in the system. Disabled Legacy audio devices disabled (Default) Legacy audio devices enabled Enabled Sound Blaster [Disabled] Use the Sound Blaster option to enable the onboard sound blaster.

  • Page 136: Power Management Setup

    IOWA-MARK Half-size CPU Card SB DMA Select [DMA 1] Use the SB DMA Select option to select the sound blaster DMA (direct memory access) address. DMA address options are listed below. DMA 0 DMA 1 (Default) DMA 2 DMA 3 MPU-401 [Disabled] Use the MPU-401 option to enable the MPU-401 (MIDI Processing Unit).

  • Page 137: Bios Menu 7: Power Management Setup

    IOWA-MARK Half-size CPU Card BIOS Menu 7: Power Management Setup ACPI Function [Enabled] Use the ACPI Function to enable the ACPI (Advanced Configuration and Power Interface) function. ACPI function disabled Disabled Enabled (Default) ACPI function enabled Power Management [Press Enter] Use the Power Management option to open new power management menu.
  • Page 138 IOWA-MARK Half-size CPU Card refreshed; the system is running in a low power mode. S3 (STR) System appears off. The CPU has no power; RAM is in slow refresh; the power supply is in a reduced power mode. PM Control by APM [Yes] Use the PM Control by APM option to specify whether or not the BIOS determines if an APM OS is being run on the system.
  • Page 139 IOWA-MARK Half-size CPU Card is disabled V/H SYNC + Blank The display screen goes blank and the V-SYNC and H-SYNC signals from VGA cards to the display are turned off when the video is disabled. DPMS Support If the system supports the VESA (Video Electronics Association) DPMS...

  • Page 140: Power Management

    IOWA-MARK Half-size CPU Card Instant-Off (Default) When the power button is pressed, the system is immediately shutdown. To shutdown the system the power button must be held Delay 4-sec down longer than four seconds otherwise the system enters a low power usage state. Wake Up Events [Press Enter] Use the Wake Up Events option to open a new Wake Up Event menu.
  • Page 141 IOWA-MARK Half-size CPU Card User Defined (Default) User must define when the system goes into a sleep state or a suspend state The longest period of time that can be specified Min. Saving before the system enters either the Doze mode or the suspend state.
  • Page 142 IOWA-MARK Half-size CPU Card 15 Min Doze Mode [Disabled] Use the Doze Mode option to enable the CPU to run at a slow speed if the system is unused for a specified period of time (see below). The Doze Mode is a power state when an APM/PM enabled OS is installed on the system.

  • Page 143: Wake Up Events

    IOWA-MARK Half-size CPU Card 20 Min 30 Min 40 Min 1 Hour 6.6.2 Wake Up Events Use the Wake Up Events menu (BIOS Menu 9) to specify what components can rouse the system from a suspend or doze state when there is activity on the components. BIOS Menu 9: Wake Up Events VGA [OFF] Use the VGA option to enable the system to monitor activity on the VGA display and rouse...
  • Page 144 IOWA-MARK Half-size CPU Card LPT & COM [LPT/COM] Use the LPT & COM option to enable the system to monitor activity on the LPT display and serial ports and rouse the system from a suspend or doze state when activity on the LPT display and serial ports is detected.
  • Page 145 IOWA-MARK Half-size CPU Card Use the PCI Master option to enable the system to monitor activity on the PCI master and rouse the system from a suspend or doze state when activity on the PCI master is detected. The system is not roused from a doze state or suspend state when activity is detected on the PCI master.
  • Page 146 IOWA-MARK Half-size CPU Card Use the Modem Ring Resume option to enable activity on the modem to rouse the system from a suspend or doze state. Disabled (Default) Wake event not generated by modem activity Enabled Wake event generated by modem activity RTC Alarm Resume [Disabled] Use the RTC Alarm Resume option to specify when the computer is roused from a suspended state.

  • Page 147: Pnp/Pci Configurations

    IOWA-MARK Half-size CPU Card To view the IRQs Monitoring Activity options press E . If the Primary INTR was NTER selected as ON, the IRQs can be monitored and used to generate wake events. The following IRQs are monitored: IRQ3 IRQ4 IRQ5 IRQ6...

  • Page 148: Bios Menu 11: Pnp/Pci Configurations

    IOWA-MARK Half-size CPU Card Use the PnP/PCI Configurations menu (BIOS Menu 11) to set the plug and play, and PCI options. BIOS Menu 11: PnP/PCI Configurations PNP OS Installed [No] The PNP OS Installed option determines whether the Plug and Play devices connected to the system are configured by the operating system or the BIOS.
  • Page 149 IOWA-MARK Half-size CPU Card Disabled (Default) ESCD will not be reconfigured Enabled ESCD will be reconfigured after you exit setup Resources Controlled By [Auto (ESCD)] Use the Resources Controlled By option to either manually configure all the boot and plug and play devices, or allow BIOS to configure these devices automatically. If BIOS is allowed to configure the devices automatically IRQs, DMA and memory base address fields cannot be set manually.

  • Page 150: Bios Menu 12: Irq Resources

    IOWA-MARK Half-size CPU Card BIOS Menu 12: IRQ Resources The IRQ Resources menu has the following options: IRQ-3 assigned to IRQ-4 assigned to IRQ-5 assigned to IRQ-6 assigned to IRQ-7 assigned to IRQ-8 assigned to IRQ-9 assigned to IRQ-10 assigned to IRQ-11 assigned to IRQ-12 assigned to IRQ-13 assigned to...

  • Page 151: Bios Menu 13: Memory Resources

    IOWA-MARK Half-size CPU Card BIOS Menu 13: Memory Resources The menu has two configurable options: PCI/ISA PnP (Default) Legacy ISA Reserved Memory Base [N/A] The Reserved Memory Base option specifies the base address for the peripheral device. The Reserved Memory Base options are: N/A (Default) C800 CC00...
  • Page 152 IOWA-MARK Half-size CPU Card PCI/VGA Palette Snoop [Disabled] Use the PCI/VGA Palette Snoop option enables the system to determine whether or not some special VGA cards, high-end hardware MPEG decoders and other similar devices are allowed to look at the VGA palette on the video card so these devices can determine what colors are in use.

  • Page 153: Pc Health Status

    IOWA-MARK Half-size CPU Card 6.8 PC Health Status The PC Health Status menu (BIOS Menu 14) has no user configurable options, but shows system operating parameters that are essential to the stable operation of the system. BIOS Menu 14: PC Health Status The following system parameters are monitored by the PC Health Status menu.

  • Page 154: Frequency/Voltage Control

    IOWA-MARK Half-size CPU Card Voltages The following voltages are monitored: Vcore +2.5 V +3.3 V +5 V +12 V 6.9 Frequency/Voltage Control Use the Frequency/Voltage Control menu (BIOS Menu 15) to set the frequency options for the DIMM, PCI and CPU host. BIOS Menu 15: Frequency/Voltage Control Auto Detect DIMM/PCI Clk [Enabled] Use the Auto Detect DIMM/PCI Clk option to actively reduce EMI (Electromagnetic...
  • Page 155 IOWA-MARK Half-size CPU Card Enabled (Default) AGP, PCI and memory slots are monitored and clock signals to all unoccupied and inactive slots are turned off. Spread Spectrum [Disabled] Use the Spread Spectrum option to reduce the EMI. Excess EMI is generated when the system clock generator pulses have extreme values.
  • Page 156 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 140...

  • Page 157: Software Drivers

    IOWA-MARK Half-size CPU Card Chapter Software Drivers Page 141...

  • Page 158: Available Software Drivers

    IOWA-MARK Half-size CPU Card 7.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates. The IOWA-MARK motherboard has four software drivers: VIA 4 in 1 Chipset Driver Installation (VIA Service Pack v4.3) RealTek Audio Driver...

  • Page 159: Figure 7-1: Access The 4In1_Extreme Folder

    IOWA-MARK Half-size CPU Card Figure 7-1: Access the 4in1_Extreme Folder Step 3: Click the Setup utility icon shown in Figure 7-2. Figure 7-2: Setup Utility Icon Step 4: The installation program begins to initialize. After the initialization process a welcome screen shown in Figure 7-3 appears. Click “N ”...

  • Page 160: Figure 7-3: Via Chipset Driver Installation Welcome Screen

    IOWA-MARK Half-size CPU Card Figure 7-3: VIA Chipset Driver Installation Welcome Screen Step 5: The “Readme” in Figure 7-4 appears. Click “N ” to continue. Figure 7-4: Readme Information Step 6: Select “Normal Installation” or “Quick Installation.” (See Figure 7-5) Click “N ”...

  • Page 161: Figure 7-5: Via Chipset Driver Installation Type

    IOWA-MARK Half-size CPU Card Figure 7-5: VIA Chipset Driver Installation Type Step 7: Select the setup components (see Figure 7-6) that must be installed in the system. There are setup components: VIA PCI IDE Bus Driver AGP Driver (AGP3.0 Supported) VIA INF Driver 1.70A Click “N ”...

  • Page 162: Figure 7-6: Driver Selection

    IOWA-MARK Half-size CPU Card Figure 7-6: Driver Selection Step 8: The setup then prompts the user (see Figure 7-7) if the VIA PCI IDE Bus Driver must be installed on the system. Select install or uninstall. Click “N ” to continue.

  • Page 163: Figure 7-7: Via Pci Ide Bus Driver Selection

    IOWA-MARK Half-size CPU Card Figure 7-7: VIA PCI IDE Bus Driver Selection Step 9: The setup then prompts the user (see Figure 7-8) if the AGP driver must be installed on the system. Select install or uninstall. Click “N ” to continue. Page 147...

  • Page 164: Figure 7-8: Agp Driver Selection

    IOWA-MARK Half-size CPU Card Figure 7-8: AGP Driver Selection Step 10: The drivers are then installed onto the system. After the installation is complete the user is prompted to restart the computer now or later. (See Figure 7-9) Select when the computer must be restarted. Click “OK” to exit the installation program.Step 0: Page 148...

  • Page 165: Realtek Audio Driver Installation

    IOWA-MARK Half-size CPU Card Figure 7-9: Restart the Computer 7.3 RealTek Audio Driver Installation To install the RealTek AC’97 Audio driver, please follow the steps below: Step 1: Insert the CD into the system that contains the IOWA-MARK board. Step 2: Open the “IOWA-MARK”...

  • Page 166: Figure 7-11: Setup Utility Icon

    IOWA-MARK Half-size CPU Card Figure 7-11: Setup Utility Icon Step 4: The install shield wizard for the audio driver starts. See Figure 7-12. Figure 7-12: Audio Driver Install Shield Wizard Starting Step 5: The RealTek Audio Setup prepares the install shield to guide you through the rest of the setup process.

  • Page 167: Figure 7-13: Audio Driver Setup Preparation

    IOWA-MARK Half-size CPU Card Figure 7-13: Audio Driver Setup Preparation Step 6: The welcome screen shown in Figure 7-14 appears. Click the “N ” button to continue the installation. The install shield starts to configure the new software as shown in Figure 7-15. Page 151...

  • Page 168: Figure 7-14: Audio Driver Welcome Screen

    IOWA-MARK Half-size CPU Card Figure 7-14: Audio Driver Welcome Screen Figure 7-15: Audio Driver Software Configuration Page 152...

  • Page 169: Figure 7-16: Audio Driver Digital Signal

    IOWA-MARK Half-size CPU Card Step 7: The “Digital Signal Not Found” screen shown in Figure 7-16 appears. Click “Y ” to continue the installation. Figure 7-16: Audio Driver Digital Signal Step 8: The installation of the driver begins. See Figure 7-17. Page 153...

  • Page 170: Figure 7-17: Audio Driver Installation Begins

    IOWA-MARK Half-size CPU Card Figure 7-17: Audio Driver Installation Begins Step 9: After the driver installation process is complete, a confirmation screen shown in Figure 7-18 appears. Page 154...

  • Page 171: Lan Driver Installation

    IOWA-MARK Half-size CPU Card Figure 7-18: Audio Driver Installation Complete Step 10: Select when the system should be restarted, now or later. (see Figure 7-18) Step 11: Click “F ” to complete the installation. Step 0: INISH 7.3.1 LAN Driver Installation To install the LAN driver, follow the steps below: Step 1: Insert the CD into the system that contains the IOWA-MARK board.

  • Page 172: Figure 7-19: Access The Lan Driver Folder

    IOWA-MARK Half-size CPU Card Figure 7-19: Access the LAN Driver Folder Step 3: Click the Setup utility icon shown in Figure 7-20. Figure 7-20: Setup Utility Icon Step 4: Once the Setup icon is double clicked, a Welcome screen shown in Figure 7-21 appears.

  • Page 173: Figure 7-22: Lan Driver Installation Complete

    IOWA-MARK Half-size CPU Card Figure 7-22: LAN Driver Installation Complete Step 6: Click “Finish” to complete the installation. Step 0: Page 157...
  • Page 174 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 158...

  • Page 175: Abios Options

    IOWA-MARK Half-size CPU Card Appendix BIOS Options Page 159...
  • Page 176 IOWA-MARK Half-size CPU Card Load Fail-Safe Defaults ..................89 Load Optimized Defaults..................89 Set Supervisor Password ..................89 Set User Password ....................89 Save & Exit Setup ....................89 Exit Without Saving ....................89 Date [Day mm:dd:yyyy] ..................90 Time [hh/mm/ss] ....................90 IDE Master and IDE Slave ..................90 Drive A [None] ......................91 Video ........................91 Halt On [All, But Keyboard] ..................91...
  • Page 177 IOWA-MARK Half-size CPU Card Boot Device ......................98 Boot Other Device [Enabled] ................99 Swap Floppy Drive....................100 Boot Up Floppy Seek [Enabled] ................ 100 Boot Up Numlock Status [On] ................100 Gate A20 Option [Fast]..................101 Typematic Rate Setting [Disabled]..............101 Typematic Rate (Chars/sec) [6] .................
  • Page 178 IOWA-MARK Half-size CPU Card OnChip Sound [Auto] ..................110 OnChip Modem [Auto]..................110 OnBoard Audio [Enabled].................. 110 CPU to PCI Write Buffer [Enabled]..............110 PCI Dynamic Bursting [Enabled]............... 111 PCI Master 0 WS Write [Enabled] ..............111 PCI Delay Transaction [Disabled] ..............111 PCI #2 Access #1 Retry [Enabled]..............
  • Page 179 IOWA-MARK Half-size CPU Card MPU-401 I/O Address [330 – 333H] ..............120 ACPI Function [Enabled]..................121 Power Management [Press Enter]..............121 ACPI Suspend Type [S1(POS)]................121 PM Control by APM [Yes]................... 122 Video Off Option [Suspend Off]..............122 Video Off Method [Blank Screen]..............122 Modem Use of IRQ ....................
  • Page 180 IOWA-MARK Half-size CPU Card PCI/VGA Palette Snoop [Disabled]..............136 Assign IRQ for VGA [Enabled] ................136 Assign IRQ for USB [Enabled]................136 System Temperature ..................137 Fan Speeds......................137 Voltages ....................... 138 Auto Detect DIMM/PCI Clk [Enabled] ..............138 Spread Spectrum [Disabled]................139 CPU Host/PCI Clock [Disabled] .................

  • Page 181: Bdio Connector

    IOWA-MARK Half-size CPU Card Chapter DIO Connector Page 165...

  • Page 182: Dio Interface

    IOWA-MARK Half-size CPU Card B.1 DIO Interface Introduction The DIO connector on the IOWA-MARK is interfaced to GIO ports on the Winbond W83627EHG Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 183: Assembly Language Samples

    IOWA-MARK Half-size CPU Card B.3 Assembly Language Samples B.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. Sets the digital port as input AX, 6F08H Initiates the INT 15H BIOS call B.3.2 Enable the DIO Output Function...
  • Page 184 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 168...

  • Page 185: Cwatchdog Timer

    IOWA-MARK Half-size CPU Card Appendix Watchdog Timer Page 169...
  • Page 186 IOWA-MARK Half-size CPU Card NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 187: Example Program

    IOWA-MARK Half-size CPU Card NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...
  • Page 188 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 172...

  • Page 189: Daddress Mapping

    IOWA-MARK Half-size CPU Card Appendix Address Mapping Page 173...

  • Page 190: Address Map

    IOWA-MARK Half-size CPU Card D.1 Address Map I/O address Range Description 000-01F DMA Controller 020-021 Interrupt Controller 040-043 System time 060-06F Keyboard Controller 070-07F System CMOS/Real time Clock 080-09F DMA Controller 0A0-0A1 Interrupt Controller 0C0-0DF DMA Controller 0F0-0FF Numeric data processor 1F0-1F7 Primary IDE Channel 2F8-2FF...

  • Page 191: Irq Mapping Table

    IOWA-MARK Half-size CPU Card D.3 IRQ Mapping Table IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 ACPI IRQ2 Available IRQ10 IRQ3 COM2 IRQ11 LAN/USB2.0/SATA IRQ4 COM1 IRQ12 PS/2 mouse IRQ5 SMBus Controller IRQ13 IRQ6 IRQ14 Primary IDE IRQ7 Available IRQ15 Secondary IDE Table D-3: IRQ Mapping Table...
  • Page 192 IOWA-MARK Half-size CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 176...

  • Page 193: Eexternal Ac'97 Audio Codec

    IOWA-MARK Half-size CPU Card Appendix External AC’97 Audio CODEC Page 177...

  • Page 194: Introduction

    IOWA-MARK Half-size CPU Card E.1 Introduction The motherboard comes with an on-board Realtek ALC655 CODEC. Realtek ALC655 is a 16-bit, full duplex AC’97 Rev. 2.3 compatible audio CODECwith a sampling rate of 48KHz. E.1.1 Accessing the AC’97 CODEC The CODEC is accessed through a connector on the IOWA-MARKG motherboard. Connect the audio kit to the connector.
  • Page 195 IOWA-MARK Half-size CPU Card To access the Sound Effects Manager, please do the following: Step 1: Install the audio CODEC driver. Step 2: Click either: The Sound Effect Manager icon in the Notification Area of the system task bar (see Figure E-2), or The Sound Effect Manager icon in the Control Panel (Figure E-3).

  • Page 196: Sound Effect Manager Configuration Options

    IOWA-MARK Half-size CPU Card NOTE: The Sound Effect Manager shown above is for the RealTek ALC655 audio CODEC. Different CODECs may have different sound manager appearances. The following section describes the different configuration options in the Sound Effect Manager. E.2.2 Sound Effect Manager Configuration Options The Sound Effects Manager enables configuration of the items listed below.
  • Page 197 IOWA-MARK Half-size CPU Card General NOTE: Not all RealTek Sound Effect Managers have all the above listed options. The Sound Effect Manager loaded onto the system may only have some of the options listed above. Below is a brief description of the available configuration options in the Sound Effects Manager.
  • Page 198 IOWA-MARK Half-size CPU Card Connector Sensing:- Realtek ALC655 detects if an audio device is plugged into the wrong connector. If an incorrect device is plugged in a warning message appears. HRTF Demo:- Adjust HRTF (Head Related Transfer Functions) 3D positional audio here before running 3D applications.

  • Page 199: Fraid Setup

    IOWA-MARK Half-size CPU Card Appendix RAID Setup Page 183...

  • Page 200: Introduction

    IOWA-MARK Half-size CPU Card F.1 Introduction The ALi M5283 SATA RAID chipset can control parallel ATA (PATA) and serial ATA (SATA) disks. The ALi controller supports PATA UDMA transfer mode up to mode 6 and SATA 1 disk drives. The ALi M5283 also has a cost-effective RAID functionality that can increase the data read/write speed and provide protection to data by distributing mirrored duplicates of data onto two disk drives (RAID 1).

  • Page 201: Features And Benefits

    IOWA-MARK Half-size CPU Card CAUTION: Do not accidentally disconnect the SATA drive cables. Carefully route the cables within the chassis to avoid system down time. F.2 Features and Benefits Supports RAID levels 0, 1, and JBOD Supports connectivity to two disk drives Supported Operating Systems include: Windows 98/Me, Windows 2000 and Windows XP Windows-based software for RAID management...
  • Page 202 IOWA-MARK Half-size CPU Card 6.3) Step 3: Save and Exit BIOS. After the SATA BOOT ROM Control BIOS option is enabled, save and exit the BIOS. Step 4: Reboot the system. Reboot the system after saving and exiting the BIOS. Step 5: Press Ctrl-A.

  • Page 203: Raid Options

    IOWA-MARK Half-size CPU Card Figure F-2: RAID BIOS Setup Utility Step 7: Configure the RAID settings. Use the RAID BIOS Setup Utility in Figure F-2 to configure the RAID array. Brief descriptions are given below. Step 8: Install the OS. After the RAID array has been configured (see below) install the OS.
  • Page 204 IOWA-MARK Half-size CPU Card drives. Step 1: Select “Create RAID 0 Striping for Performance”. Use the arrow keys to highlight Create RAID0 Striping for Performance and press E . A flashing NTER ‘S’ appears on the Drive Menu where the member drives to be included in the RAID 0 array can be chosen.

  • Page 205: Create Raid 1 Mirroring For Reliability

    IOWA-MARK Half-size CPU Card F.4.2 Create RAID 1 Mirroring for Reliability WARNING: All data previously stored on the member drives of a RAID configuration is destroyed during the RAID initialization process. If “used” drives are used to create a RAID array, make sure the data has been moved or backed up before creating a RAID array out of the disk drives.
  • Page 206 IOWA-MARK Half-size CPU Card Step 3: Confirm. The Create RAID0(Y/N) confirm box appears. Press Y. Step 4: Name the array. Enter a nickname for the created array. Upper and lower case alphabetic, numeric, space, and underscore characters are all applicable for naming an array Step 5: View the array.

  • Page 207: Create Jbod For Integrated Capacity

    IOWA-MARK Half-size CPU Card F.4.3 Create JBOD for Integrated Capacity JBOD is defined as “Just a Bunch of Drives.” JBOD provides neither performance gains nor data redundancy. WARNING: All data previously stored on the member drives of a RAID configuration is destroyed during the RAID initialization process. If “used”...

  • Page 208: Stripe Size

    IOWA-MARK Half-size CPU Card Create JBOD for Integrated Capacity and press E . A flashing ‘J’ appears NTER on the Drive Menu where the member drives to be included in the JBOD array can be chosen. Step 2: Select RAID array drive members. Use the space bar to select members of the RAID array.

  • Page 209: Delete Raid Setting & Partition

    IOWA-MARK Half-size CPU Card Select a small stripe size if the I/Os to the hard drives are small and occur randomly. Choose a larger stripe size if the I/Os are mostly large and come in sequential orders, e.g., A/V playback and editing applications. The default value should be appropriate for most applications.

  • Page 210: Rebuild Raid Array

    IOWA-MARK Half-size CPU Card F.4.7 Rebuild RAID Array The Rebuild RAID Array option can rebuild a RAID array if a member of a RAID configuration should fail. Neither RAID 0 nor JBOD provides data redundancy. The Rebuild RAID Array option only applies to RAID1 arrays and is applicable when a member of a RAID1 configuration has failed.

  • Page 211: Index

    IOWA-MARK Half-size CPU Card Index Page 195...
  • Page 212 IOWA-MARK Half-size CPU Card onboard ..........2 Audio 149, 150, 151, 152, 153, 154, 155 audio connector....... 5, 32 10/100 megabit........ 3, 58 location and pinouts ......32 10/100 megabits ........18 audio connector CD in ......33 10/100M Ethernet ....... 18 location and pinouts ......
  • Page 213 WSB-9452 CPU Card clear CMOS jumper ....6, 71, 72 TFT LCD (40-pin) ......53 location..........72 USB (internal)......... 54 settings ..........72 -VCC power ........56 CMOS ........... 36, 71 cooling ..........75 clear CMOS connector....36 airflow ..........75 clear CMOS jumper ......
  • Page 214 WSB-9452 CPU Card connectors ........81 ISA devices ......... 56 fan connector........5, 40 jumper ..........71 location and pinouts ......40 clear CMOS ........71 floppy disk connector...... 5, 41 jumper configuration....... 71 location and pinouts ......41 jumper settings ........ 71 floppy disk drive .........
  • Page 215 WSB-9452 CPU Card dual channel ........46 PS/2 keyboard and mouse Y-Cable..83 single channel........46 PS/2 keyboard/mouse LVDS voltage selection jumper ..6, 73 Y-cable ..........83 location..........74 PS/2 mouse ......... 83 settings ..........74 LVDS/DVI transmitter, integrated ..13 RAID..........
  • Page 216 WSB-9452 CPU Card location and pinouts ......51 unpacking........22, 67 SATA drives ........51 unpacking checklist......23 security engine ........13 unpacking precautions ....22, 67 Serial Infrared ........16 USB............. 55 serial port connector.... 6, 16, 52, 60 devices ..........

This manual is also suitable for:

Iowa-mark-800-128mb-r10Iowa-mark-800s-128mb-r10Iowa-mark-533s-128mb-r10

Table of Contents
