Quad Monitor Desk Stand
Instruction Manual
SKU: STAND-V104F
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v104f
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V104F
Summary of Contents for Vivo STAND-V104F
- Page 1 Quad Monitor Desk Stand Instruction Manual SKU: STAND-V104F Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v104f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22lbs Failure to do so may result in serious injury. (9.98kg) PER MONITOR Phillips Screwdriver ASSEMBLY STEPS STEP 1 Connect Pole (A) to Base (B) using M6x29mm Screws (S-B) and a Phillips screwdriver. Slide Decorative Cover (C) over Pole (A) to install. - Page 4 STEP 2 Lay Monitor Arm (E) on flat surface with holes for cable clips facing down. Add Plastic Spacers (G) to holes at ends of Monitor Arm (E). Cable Clip Hole Cable Clip Hole NOTE: Transparent monitor arm image used to show cable clip holes. Holes are on the underside of arms and are not visable when arm is facing upright.
- Page 5 STEP 2 - Continued Press Monitor Arm Covers (G) onto the top and bottom of arm joints. Place Cable Clips (I) into cable clip holes. STEP 3 Carefully slide assembled monitor arm and Mount (F) onto Pole (A), making sure holes for wire clips are facing down.
- Page 6 STEP 3 Option A - Flat Back Monitors Attach the Center VESA Plates (K) to the monitors you intend to mount in the center of the mount. Attach Side VESA Plates (J) to remaining monitors. Secure using M4x12mm Screws (M-A). Center VESA Plate (K) Installation Side VESA Plate (J) Installation NOTE: Hand tighten screws to avoid stripping the plastic screw heads.
- Page 7 STEP 4 Slide the center monitors onto the heads of assembled monitor arm and mount. Secure with M4x6mm Screws (S-E) and tighten with a Phillips screwdriver.
- Page 8 STEP 5 Slide the outer monitors onto Outer VESA Heads (E1). Secure with Nut (S-D). Adjust Monitor Tilt Pry off Plastic Covers (E2) from the Outer VESA Heads (E1). The exposed nut on the side is used to adjust the tilt. Tighten the nut using Wrench (T-D) to adjust.
- Page 9 Adjust Monitor Height To adjust center monitor height, turn the screw behind Center Head (D1) using the 5mm Allen Wrench (T-B). To level the side monitors, remove the Security Nut (S-F) and turn the inner bolt with the 3mm Allen Wrench (T-A) to raise or lower the monitor. Replace Nut after the adjustment.
-
Page 10: Cable Management
Cable Management Manage cables using Cable Clips (I). Remove the split cap from the Pole (A) and feed cables through, pulling ends out from the opening in back. Replace the split cap when finished. - Page 11 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
