Quad Monitor Desk Stand
Instruction Manual
SKU: STAND-V104F
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v104f
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V104F
Summary of Contents for Vivo STAND-V104F
- Page 1 Quad Monitor Desk Stand Instruction Manual SKU: STAND-V104F Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v104f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22lbs Failure to do so may result in serious injury. (9.98kg) PER MONITOR Phillips Screwdriver ASSEMBLY STEPS STEP 1 Install the pole (a) to the base (b) using M6x29 bolts (h). Tighten with a Phillips screwdriver and install decorative cover (c). - Page 4 STEP 3 Carefully slide assembled monitor arm (d1) and mount (d3) down onto the pole, making sure holes for wire clips are facing down, and secure with M8x10 bolts (i) using the medium Allen wrench (n). Attach the wire clips (r) to the monitor arm. STEP 4 OPTION A: Flat Back Monitor Attach the VESA plates (p1, p2) to the monitors using M4x12 thumb bolts (j).
- Page 5 STEP 5 Slide the center monitors onto the heads of monitor arm and mount. Secure with the M4x6 bolts (q2) and tighten with a Phillips screwdriver. è O Ç N I Ç O d1, d2 Slide the side monitors onto the heads of monitor arm and install the security nuts (q1). Make sure the security nuts are installed before you rotate the monitors.
- Page 6 STEP 7 To adjust center monitor height, turn the screw behind center monitor joint using the medium Allen wrench (n). To level the side monitors, remove the security nut and turn the bolt with the small Allen wrench (n) to raise or lower the monitor. Replace nut after the adjustment. STEP 8 Pry off the plastic cover and use the large Allen wrench (n) to adjust swivel joints if needed.
- Page 7 STEP 9 Manage cables using the wire clips (r). Remove the split cap from the pole and feed cables through, pulling ends out from the opening in back. Replace the split cap when finished.
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
