Pneumatic Arm Single Monitor Desk Mount with USB
Instruction Manual
SKU: STAND-V101G1U
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v101g1U
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V101G1U and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V101G1U

  • Page 1 Pneumatic Arm Single Monitor Desk Mount with USB Instruction Manual SKU: STAND-V101G1U Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v101g1U GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 (Option A) Clamp Installation Attach Clamp Brace (I) to Base (A) using M6x12mm Screws (S-A) and 4mm Allen Wrench (T-B). Apply Soft Pad (G) to underside of Base (A). Loosen screws on the back of Clamp (J), leaving 6mm of thread exposed. Assemble Clamp (J) to Clamp Brace (I) and retighten screws using 4mm Allen Wrench (T-B).
  • Page 4 STEP 1 (Option B) Grommet Base Installation Attach Grommet Plate (F) to Base (A) using M6x12mm Screws (S-A) and tighten with 4mm Allen Wrench (T-B). Apply Soft Pad (G) to underside of Base (A). Position Base (A) over grommet hole in desktop, or drill a 3/8”...
  • Page 5 STEP 4 Install VESA Plate (D) to monitor using M4x12mm Screws (M-A) or M5x12mm Screws (M-B) with M5 Washers (M-C), making sure the arrow on VESA Plate (D) is pointing up. STEP 5 Pull back the release lever on the support bracket, then place the monitor with VESA Plate (D) into the support.
  • Page 6 STEP 7 Remove cable cover on Gas Spring Arm (C) using a Phillips screwdriver. Slide cable cover on Lower Arm (B) forward to remove. STEP 8 Organize cables, then reinstall cable covers to Gas Spring Arm (C) and Lower Arm (B).
  • Page 7 STEP 9 For safety, please do not extend the monitor behind the desk. This may cause instability and tip the desk over. STEP 10 Adjust as desired. Store Allen Wrenches (T-A, T-B, T-C) in Cover (H) for future adjustments.
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
