Required Tools And Materials; Decommissioning And Disposal - Siemens SIMATIC NET RUGGEDCOM RX1510 Equipment Manual

Alarm Indicator LED
Compact Flash Card Port
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RX1510:
AC/DC power cord (16 AWG)
Lightning protector
Shielded coaxial cables
SIM Card(s) provided by the network carrier
Flathead screwdriver
Phillips screwdriver
4 x #6-32 screws
Braided or equivalent ground wire
1.4

Decommissioning and disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated "RUGGEDCOM ROX Configuration
Manual".
RUGGEDCOM RX1510
Equipment Manual, 10/2023, C79000-G8976-1055-25
• Orange = Warning alert
• Red = Configuration error
Indicates when an alarm condition exists.
• Green = Alarms cleared/acknowledged
• Red = Alarm
Houses the CompactFlash (CF) card that contains active and
backup installations of RUGGEDCOM RUGGEDCOM RX1510,
along with the configuration database and other system data.
For more information, refer to "Accessing the CompactFlash
Card" (Page 23).
Tools/Materials
1.3 Required Tools and Materials
Purpose
For connecting power to the device.
For protecting the device from harmful electrical
strikes.
For connecting the device to antennas and an
Ethernet network.
For accessing a network carrier's cellular network.
Required only if a cellular modem module is
equipped.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
For grounding the device to safety Earth.
Introduction
3
