Modules
4.4 Installing/Removing Power Modules
4.
5.
4.4

Installing/Removing Power Modules

The RUGGEDCOM RX1510 supports dual redundant power supply modules.
1
2
Figure 4.4
Contamination hazard – risk of equipment damage
Prevent the ingress of water, dirt, and other debris that may lead to premature
equipment failure. Always make sure slots are not left empty.
Note
Power modules are hot swappable. When installing/removing a power module, it is
not necessary to turn off power to the redundant power module.
30
Chassis
2
Screw
3
Figure 4.3 Installing a Module
Tighten the screws to secure the module.
[Optional] If necessary, install the device in the rack.
Slot PS1
Slot PS2
Power Modules
NOTICE
1 2
Equipment Manual, 10/2023, C79000-G8976-1055-25
RUGGEDCOM RX1510
