- Page 1 HBT3000 series Internal resistance tester User Manual 2023.12...
- Page 2 The copyright of this document belongs to Qingdao Hantek Electronic Co., LTD. Statement Qingdao Hantek Electronic Co., Ltd. reserves the right to amend this document without prior notice. Qingdao Hantek Electronic Co., Ltd. promises that the information provided is correct and reliable but does not guarantee that this document is free from errors.
-
Page 3: Table Of Contents
Care and Cleaning ......................7 Environmental precautions ...................8 Product features ......................... 9 Overview ..........................10 Quick Start .......................... 13 General inspection ......................13 Appearance dimensions ....................14 Preparation before use ....................14 Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... - Page 4 Setting the Resistance Range ....................22 5.1.4 Setting the sampling rate ......................22 Zeroing ..........................23 Test abnormal output ....................23 Application measurement ..................... 25 Measurement Configuration ..................25 HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
- Page 5 Normal distribution diagram ....................35 6.3.4 SAVE/LOAD ............................. 35 6.3.5 Data Temp ............................36 6.3.6 Data Clearing ..........................36 System Settings ......................36 Calibration ........................37 IO ............................38 Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual...
- Page 6 Load Path ............................42 6.9.2 Inter/Exter Save ..........................42 6.9.3 Boot Set ............................43 6.10 0 ADJ ..........................43 6.11 Local key ........................... 43 6.12 TRIG key ..........................44 HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
- Page 7 Appendix A: Models and Accessories ..............62 11.2 Appendix B: AC Four Terminal Test Method............64 11.3 Appendix C: Performing Zero Adjustment ............65 11.3.1 Zero adjustment wiring principle .................... 65 Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual...
- Page 8 11.3.2 Zero adjustment using clamp type test line ............... 66 11.3.3 Zero adjustment using needle shaped test lines .............. 66 11.4 Appendix D: Warranty Summary ................67 HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
-
Page 9: Figures
Figure 6-2 Set sampling rate..................26 Figure 6-3 Set average value ..................26 Figure 6-4 Set trigger source ..................27 Figure 6-5 Setting Delay ....................27 Figure 6-6 Set absolute value function ..............28 Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... - Page 10 Figure 9-3 Manually adding devices ................57 Figure 9-4 Network interface icon display ............... 58 Figure 9-5 RS232/485 connector ................58 Figure 11-1 Principle diagram of measurement method ........64 HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD VIII...
- Page 11 Figure 11-2 Zero adjustment schematic diagram ..........65 Figure 11-3 Zero adjustment of clamp type test line .......... 66 Figure 11-4 Zero adjustment of needle shaped test line ........66 Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual...
-
Page 12: Tables
Table 8-1 Analog output specifications ..............55 Table 9-1 RS232/485 connector pin number ............59 Table 11-1 Internal resistance tester model ............62 Table 11-2 Standard accessories .................. 63 HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 13: Safety Requirement
Please consult the product manual for details of the rating values before connecting the product. Do not operate with the cover open. ⚫ Do not run the product with the cover or panel open. ⚫ Avoid circuit exposure. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 14: Security Terms And Signs
Indicates that if you perform this operation, it may not immediately cause damage to you. Note: Indicates that the operation may cause damage to the product or other property. Safety terms on products:： HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 15: Measurement Category
(internal) main power supply. In the latter case, the instantaneous stress will change. Therefore, the user should understand the instantaneous capacity of the instrument. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 16: Ventilation Requirement
Note: Poor ventilation can cause an increase in instrument temperature, leading to instrument damage. Good ventilation should be maintained during use, and ventilation openings should be regularly checked. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 17: Work Environment
Installation (overvoltage) category I refers to the signal level, which is suitable for measuring terminals connected to equipment in the source circuit, where measures have been taken to limit instantaneous voltage to the corresponding Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... - Page 18 ⚫ Pollution Degree 4: The pollution generates persistent conductivity caused by conductive dust, rain, or snow. For example, outdoor areas. Security level Class 1 - Grounded products HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
-
Page 19: Care And Cleaning
Warning： Before re powering on, please confirm that the instrument has dried thoroughly to avoid electrical short circuits or even personal injury caused by moisture. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 20: Environmental Precautions
To avoid the release of harmful substances into the environment and reduce the use of natural resources, it is recommended to use appropriate methods to recycle this product to ensure that most materials can be correctly reused. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 21: Product Features
⚫ voltage or gain drift in the internal circuit of the instrument The HBT3000 series internal resistance tester is a battery internal resistance tester with high accuracy, high resolution, and fast measurement characteristics.Using the AC four terminal testing method to test the internal resistance and voltage of the battery more accurately;... -
Page 22: Overview
Overview Overview This document is used to guide users to quickly understand the front and rear panels, user interface, and basic operating methods of the HBT3000 series internal resistance tester. Tip： The latest version of this manual can be downloaded at (https://www.hantek.com). -
Page 23: Table 3-1 Button
Confirm key Menu softkeys Table 3-1 Button Document content agreement： The HBT3000 series internal resistance tester includes the following models. Unless otherwise specified, this manual uses HBT3563H as an example to explain the HBT3000 series and its basic operations. Model... -
Page 24: Table 3-2 Model Table
Overview Model Resistance Voltage Measuring Interface resolution resolution range HBT3565A 0.1μΩ 10μV 0~3.6kΩ/ RS232/485,USB,LAN,I 0~1600V O,ANALOG OUTPUT HBT3566A 0.1μΩ 10μV 0~3.6kΩ/ RS232/485,USB,LAN,I 0~2000V O,ANALOG OUTPUT Table 3-2 Model Table HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 25: Quick Start
If you find that the appearance of the instrument is damaged, the instrument is not working properly, or it fails the performance test, please contact the dealer responsible for this business. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 26: Appearance Dimensions
Connecting the power supply This series of internal resistance testers can input AC power with specifications of 90-240 VAC, 47/63Hz, and 30VA. Please connect the internal resistance tester to HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 27: Adjusting The Handle
Adjusting the handle To adjust the handle of the instrument, hold the handles on both sides of the instrument and pull them outward, then rotate the handles. Figure 4-3 Handheld position Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 28: Setting System Language
Plus keys, range keys, and minus keys Input ports Function keys [COMP]: Comparator function menu. ⚫ [STAT]: Statistics function menu. ⚫ [Local]: Lock/unlock the keyboard; Local remote control key. ⚫ [MEA]: Measurement function menu. ⚫ HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 29: Introduction To Rear Panel
4.4.2 Introduction to Rear Panel Figure 4-5 Rear Panel AC power socket Shell grounding terminal Fuse holder Safety lock holes USB DEVICE interface LAN interface EXT I/O interface Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 30: User Interface Introduction
Move the cursor position by clicking the left and right buttons, and click the confirm button [OK] to input. Move the cursor to the enter key , then click [OK] to save and exit. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 31: Using The Built-In Help System
[?] button on the front panel, and then press the button you need help with to obtain the operation prompt for that button. Press the [?] button again to exit the help system. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 32: Start Using
V&R, Voltage, and Resistance. V&R: Simultaneously measure and display voltage and resistance, as shown in Figure 5-1. Voltage: Measure and display the voltage value, as shown in the following figure. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 33: Set Voltage Range
Use the menu soft key to select the range and complete the voltage range setting. In addition, the range can be switched using the plus minus keys, and automatic Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 34: Setting The Resistance Range
Click on the Sample again, and the selectable gears are: Slow, Horotelic and Fast.Use the menu soft key to select the desired rate gear to complete the sampling rate setting. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 35: Zeroing
When the test line is not connected to the test object, [------] is displayed on ⚫ the screen, as shown in the following figure. In addition, an abnormal test signal (ERR) will be output from the EXTI/O terminal. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 36: Figure 5-6 Test Exception
When the contact resistance is high or the wiring resistance is high due to ⚫ probe wear, dirt, etc Note: If the contact resistance or wiring resistance is large, the measurement error will increase. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 37: Application Measurement
Click on the [MEA] button, and the display will be as follows: Figure 6-1 Measurement display interface Click on the Sample and it will display as follows. Press the corresponding soft key again to complete setting the sampling rate. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 38: Setting The Average Value
Press the corresponding soft key again to complete the setting of the trigger source. The default setting is Int. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 39: Delay Function
The absolute value determination includes [Open] and [Close], and the absolute value determination defaults to Open. After enabling this function, even if the battery polarity is reversed, it can still be displayed as a positive value; If this Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 40: Comparator Function
Note: When the comparator is turned on, automatic range cannot be used. 6.2.1 Comparator function settings Click the [Comp] button to jump to the comparator settings page, as shown in the figure. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 41: Figure 6-7 Set Comparator Function
Press this soft key to set the Limits and Percent of the resistance. Select the Limits, set the Max(mΩ) and Min(mΩ). Select the Percent, set the Datum(mΩ) and Percent (%). Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 42: Setting The Limits And Percent
Datum as an example for explanation. On the resistance ratio interface, click on the Datum (mΩ) and a numeric keypad will pop up, as shown in the following figure. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 43: Page Display Of Comparator
Hi, In, and Lo on the page. As shown in the figure. Figure 6-10 page display Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 44: Statistical Operation Function
Statistical Results The viewing methods for statistical results are divided into [Index] and [List]. Click on [STAT] ->StatResult ->Index in sequence, and the statistical indicators will be displayed as follows: HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 45: Figure 6-13 Statistical Indicators
Generally, the values of Cp and Cpk can be used to evaluate process capability (as shown below): Cp, CpK>1.33..Sufficient process capability 1.33 ≥ Cp, CpK>1.00... Appropriate process capability 1.00 ZCp, CpK, etc. Insufficient process capability Note: Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 46: Figure 6-14 Statistical List
PASS; On the contrary, display UNPASS. The judgment results PASS and UNPASS (Hi, In, Lo of resistance and voltage respectively) can be output to EXT I/O. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 47: Normal Distribution Diagram
Application measurement 6.3.3 Normal distribution diagram The HBT3000 series internal resistance tester can generate a normal distribution map of statistical resistance and voltage measurement data. In the statistics main interface, click on the Nor Distribut to enter the normal distribution map interface. -
Page 48: Data Temp
6.3.5 Data Temp The HBT3000 series internal resistance tester can record up to 1000 sets of statistical data. Through the data caching function, the size of the data cache area can be set, that is, the number of recorded values for each statistical test. For example, if the data cache is set to 10, the instrument will automatically stop recording when the recorded value reaches 10. -
Page 49: Calibration
Calibration (P). Use the left/right keys to move the cursor, click [OK] to enter the actual voltage value, position the cursor to the key , and then click [OK] to save the value. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 50: Figure 6-20 Voltage Calibration
Before calibration, please confirm the rated values of the instrument and test lines, otherwise it may cause damage to the instrument or personal injury accidents. Communication settings include: LAN, Serial. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 51: Lan
Set the checksum, which can be selected from no checksum, odd checksum, and even checksum. Set the stop position and click the corresponding soft key to select the desired stop position. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 52: Other Settings
Click the left/right button to decrease or increase screen brightness in steps of 5. The adjustable range is 10-100. The default value is 50. 6.7.3 Keytone Click on [Utility] ->Other ->Keytone to turn on or off button sounds. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 53: Language
Internal save setting steps: After setting the required storage options, click on Inter Save. In the pop-up menu, there are a total of 6 states from 0 to 5 to choose Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 54: Boot Set
6.9.2 Inter/Exter Save When selecting internal loading path, the menu bar displays Intern; When the loading path is selected as external, the menu bar displays Extern. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 55: Boot Set
Click the button again, and the lock screen icon on the screen will turn gray. In remote control mode, click [Local] to switch remote control to local control. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 56: Trig Key
[ESC] button include canceling input/canceling pop-up boxes/canceling submenus. 6.16 P key Used to restore the instrument status to the factory default values. Function Default value Range Measurement type V&R Voltage range Auto Resistance range Auto HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... - Page 57 Open Delay(ms) SAVE/LOAD Boot Set Default STAT Switch Data Temp 1000 COMP Switch Close Comp Mode Auto Buzzer Close Resistance Limit Voltage Limit Utility Brightness Key tone Language Chinese Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual...
-
Page 58: Table 6-1 Factory Default
Application measurement Function Default value 192.168.1.127 MASK 255.255.255.0 IP MODE Manual Serial-Baud 9600 Serial-Data Serial-Check None Serial-Stop Table 6-1 Factory Default HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 59: Ext I/O
Do not use ISO_ 5V and ISO_ COM forms a short circuit. ⚫ Figure 7-1 EXT I/O connector Needle Signal Function Logic number name �������� external negative edge trigger （Reserved） － － － (Reserved) － － － Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... - Page 60 ISO_5V － Insulated － － power supply 5V output ISO_COM － Insulated － － power supply common terminal ������ Test exception negative edge ��_���� Resistance negative edge determination HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
- Page 61 (Reserved) － － － �������� Judgment negative level result PASS (Reserved) － － － �������� Zero negative edge ������ Perform self negative edge calibration ���������� Read the negative level Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual...
- Page 62 ISO_COM － Insulated － － power supply common terminal ������ End Of negative edge Measurement ���������� Measurement negative level reference signal ��_���� Resistance negative level HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
-
Page 63: Table 7-1 Ext I/O Output Terminal
Table 7-1 EXT I/O output terminal Note：The outer shell of the connector is connected to the metal part of the instrument, and also connected (conductive) to the protective grounding terminal of the power socket. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 64: Input Terminal Function
In the internal triggering mode, after the measurement is completed, the HOLD mode outputs a fixed width of low-level pulses according to the HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... - Page 65 When there is no need to switch measurement conditions, please fix all ⚫ ����������~���������� as Hi or Lo. To avoid erroneous judgments, please confirm the comparator's judgment ⚫ through both �������� and ������������ signals. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual...
-
Page 66: Analog Output
0 count value~31000 count values 0V~3.1V Output accuracy Resistance testing accuracy is 0.2% f. s. (temperature coefficient is 0.02% f. s./℃) Response time Resistance measurement response time+sampling time+1 ms HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 67: Figure 8-1Connection Diagram
1/10 (or 10 times). It is recommended to use in manual range. When changing settings (range switching, etc.) and when the power is turned ⚫ off, the output is set to 0 V. Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 68: Remote Control
LAN cable. Click on [Utility] ->IO ->LAN in order to set the LAN parameters of the internal resistance tester. Figure 9-1 Set LAN parameters HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 69: Figure 9-2 Set Computer Ethernet Properties
LAN list. If the device does not appear, you can manually add the device, enter the IP address and protocol of the device, test the VISA address, and click OK to add a new device. Figure 9-3 Manually adding devices Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 70: Serial Port Control
Use an RS232/485 cable to connect the computer's RS232/485 port to the RS232/485 interface on the rear panel of the internal resistance tester. Figure 9-5 RS232/485 connector Needle Signal name Signal Notes customary number Not used HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 71: Table 9-1 Rs232/485 Connector Pin Number
Send Connected request internal+5V Not used connected Not used connected Table 9-1 RS232/485 connector pin number Open the IO software, select Add Device, set the corresponding baud rate, data Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... - Page 72 VISA address, and click OK to add a new device. Like USB remote control, after obtaining normal communication, the SCPI command can be used to remotely control the internal resistance tester. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
-
Page 73: Fault Handling
Check if the fuse is blown. If you need to replace the fuse, please use a fuse that meets the specifications of this product. d. After completing the above checks, restart the instrument. e. If you still cannot use this product normally, please contact Hantek. Invalid key input a. Check if the buttons are locked. -
Page 74: Appendix
110V，RS232/485,USB,LAN,IO,ANALOG HBT3561A OUTPUT 210V，RS232/485,USB,LAN,IO, ANALOG HBT3562A OUTPUT 360V，RS232/485,USB,LAN,IO,ANALOG HBT3563A OUTPUT 1100V，RS232/485,USB,LAN,IO, ANALOG HBT3564A OUTPUT 1600V，RS232/485,USB,LAN,IO,ANALOG HBT3565A OUTPUT 2000V，RS232/485,USB,LAN,IO,ANALOG HBT3563H OUTPUT 1300V，RS232/485,USB,LAN,IO,ANALOG HBT3566A OUTPUT Table 11-1 Internal resistance tester model HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 75: Table 11-2 Standard Accessories
Power cord that meets the standards of the — — host country Square USB cable — — Clamp type testing line HT2107 Needle shaped testing line HT2100 Packing list — — Table 11-2 Standard accessories Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... -
Page 76: Appendix B: Ac Four Terminal Test Method
R2 and R3 of the wire resistance and contact resistance, eliminating the voltage drop on R2 and R3, making the measurement results more accurate. HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD... -
Page 77: Appendix C: Performing Zero Adjustment
RSOH and RSOL are the wiring resistors for Source-H and Source-L RShort is the short-circuit resistance I0 is the current flowing from SENSE-H to SENSE-L I is the current flowing from Source-H to Source-L Then: E=(I ×R )+(I ×R Copyright © Qingdao Hantek Electronic Co., LTD HBT3000 series user manual... - Page 78 To use a needle type test wire to zero, short the internal pin wiring of the red and black probe. Please connect the test wire as follows: Figure 11-4 Zero adjustment of needle shaped test line HBT3000 series user manual Copyright © Qingdao Hantek Electronic Co., LTD...
