- Page 1 FULL DC INVERTER SYSTEMS INSTALLATION MANUAL KNX PROTOCOL KNX-01 C O M M E R C I A L A I R C O N D I T I O N E R S S D V 4 AIR CONDITIONING...
- Page 3 ● This manual gives detailed description of the precautions that should be brought to your attention during operation. ● In order to ensure correct service of KNX-01 please read this manual carefully before using the unit. ● For convenience of future reference, keep this manual...
- Page 4 Table of Contents I. Safety precautions..................1 II. Other precautions ..................3 III. Installation procedure................. 5 IV. ETS database group objects introduction ..........8...
-
Page 5: Safety Precautions
I. Safety precautions The following contents are stated on the product and the operation manual, including usage, precautions against personal harm and property loss, and the methods of using the product correctly and safely. After fully understanding the following contents (identifiers and icons), read the text body and observe the following rules. - Page 6 WARNING Please entrust the distributor or professionals to install the unit. Installation by other persons may lead to imperfect installation, electric shock or fire. Strictly follow this manual. Imporper installation may lead to electric shock or fire. Reinstallation must be performed by professionals. improper installation may lead to electric shock or fire.
-
Page 7: Other Precautions
M4X25 GB823-88 mounting screw (For Mounting on the Electrical Switch Box) Installation Manual For Mounting on the Wall Plastic expansion pipe For fixing on the 86 electrician box Plastic screw bar 3-core shielded cable For connecting the AC unit and KNX-01... - Page 8 1. One KNX module can only connect with one indoor unit;The KNX module should connect to indoor XYE ports, can’t connect to outdoor XYE ports. 2. Circuit of KNX-01 is low voltage circuit. Never connect it with a standard 220V/380V circuit or put it into a same Wiring Tube with the circuit.
-
Page 9: Installation Procedure
III. Installation procedure 1.The product parameters Remarks Name Dimensions 85*51*16mm Power supply 29VDC 10mA,Supplied through KNX bus KNX programming LED indicator KNX programming button Push button Configuration with ETS software. Configuration 2.The product parameters... - Page 10 For detailed information of ETS software, please contact knx association: www.knx.org. ● ETS database *.vd* of KNX-01 can be provide by install company. 3. Wiring installation instruction The Wiring diagram follows,the KNX-01 connect to the AC Unit and KNX Power. KNX-01 Fig.3-2...
- Page 11 The Introduction KNX-01 ● KNX-01 allows monitoring and control, fully bi-directionally, of all the functioning parameters of Sinclair SDV4 Air Conditioners from KNX installations. ● Simple installation. Can be installed inside the own AC indoor unit, it connects directly in one side to the electronic circuit of the AC indoor unit (cable supplied) and in the other side to the KNX TP-1 (EIB) bus.
-
Page 12: Ets Database Group Objects Introduction
IV.ETS database group objects introduction Fig.4-1... - Page 13 The instruction as follow: 0: set mode; database type: DPT_20.102 HVAC mode; set value:0-Auto ; 1-Cool; 2-Heat; 3-Fan only ; 4-OFF 1: set temp; database type: DPT_9.001 temperature(°C). The AC unit temperature value corresponding to ETS temperature value: Temp. value( ) ETS value Temp.
- Page 14 5: Set Auxiliary Heater ON/OFF; Data type: DPT_1.002 boolean. Set value: 0-Auxiliary Heater ON; 1-Auxiliary Heater OFF. This function is only available for heat mode. 6: Mode status read; data type: DPT_20.102 HVAC mode Read value: 1-Cool mode; 2-Heat mode; 3-Fan mode; 4-OFF. 7: Set temperature read;...
- Page 15 18:Set Dry mode; data type: DPT_1.002 boolean Set value: 1-set as Dry mode 19:Set Fan mode; data type: DPT_1.002 boolean Set value: 1-set as Fan mode 20:Set mode circulation; data type: DPT_1.007 step Set value: 0-Decrease Reverse cycle 1-Increase Positive cycle Cool Heat FAN only...
- Page 16 NOTE CONCERNING PROTECTION OF ENVIRONMENT This product must not be disposed of via normal household waste after its service life, but must be taken to a collection station for the recycling of electrical and electronic devices. The symbol on the product, the operating instructions or the packaging indicate such disposal procedures.
