- Page 1 Kit Instructions E-Money Terminal Mount (Ingenico) 7707-K906 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Sep 2019 First Issue... -
Page 4: Kit Contents
E-Money Terminal Mount (Ingenico) This publication provides procedures for installing an E-Money Terminal Mount for an Ingenico E-Money Terminal on an NCR SelfServ™ Checkout (7707) unit. Note: The Ingenico E-Money Terminal is supplied by the customer and the 7360-K426 Ingenico PIN pad Mount is ordered separately. -
Page 5: Installation Procedures
E-Money Terminal Mount (Ingenico) Installation Procedures To install an Ingenico E-Money Terminal Mount on an NCR SelfServ™ Checkout (7707) unit, follow these steps: 1. Do either of the following: • Remove the existing E-Money Terminal, if necessary. For more information, refer to NCR SelfServ™... - Page 6 E-Money Terminal Mount (Ingenico) 5. Mount the studs of the base pole to the hooks of the lower bracket and then secure using two (2) screws, as shown in the image below. 6. Route the cables into the pole of the PIN pad mount, as shown in the image below. Note: The 7360-K426 Ingenico PIN pad Mount is ordered separately.
- Page 7 E-Money Terminal Mount (Ingenico) 7. Mount the Ingenico E-Money Terminal into the Device Slot of the PIN pad mount, as shown in the image below. 8. Connect the data and power cables to corresponding E-Money Terminal ports. 9. Mount and secure the Ingenico E-Money Terminal Assembly to the base pole using a screw, as shown in the image below.
- Page 8 E-Money Terminal Mount (Ingenico) Removing E-Money Terminal Blanking Plate To remove the E-Money Terminal Blanking Plate, follow these steps: 1. Using a metal pry tool or a flat screwdriver, slowly remove the Blanking Plate by starting from the sides until the plate is completely detached. Note: Use the pry tool with caution to avoid scratches on the paint.
- Page 9 To route the E-Money Terminal cables in the R6-Japan unit, follow these steps: 1. Do the following: a. Route the power cable from the Lower Cabinet up to the Upper Enclosure through P-loops. b. Route the data cable from the NCR Terminal Display down the Upper Enclosure through the P- loops.
- Page 10 E-Money Terminal Mount (Ingenico) 2. Route the cables through the hole of the lower bracket, as shown on the image below. Note: Ensure that there is enough cable slack to avoid cables from being stretched during installation or removal procedures.
