- Page 1 Kit Instructions Innovative Pole Solutions 7702-K309, K310, K311, K314, K315, K316, K317 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Table Of Contents
Table of Contents Introduction 7702-K309 Dual Yoke Adapter Kit Contents Installation Procedure 7702-K310 NCR Cash Drawer Integration Platform Adapter Kit Contents Installation Procedure 7702-K311 HD Tilter and Quick-Release Adapter Kit Contents Installation Procedure 7702-K314/K317 Thru Mount Pole with HD Tilter and Quick- Release Adapter Kit Contents Installation Procedure... - Page 4 Revision Record Issue Date Remarks Mar 2019 First Issue...
-
Page 5: Introduction
Introduction This document is for the Innovative Pole Solutions kits. -
Page 7: 7702-K309 Dual Yoke Adapter
7702-K309 Dual Yoke Adapter Kit Contents Installation Procedure 1. Install the Dual Yoke Adapter on the Pole. - Page 8 7702-K309 Dual Yoke Adapter 2. Adjust the height of the Dual Yoke Adapter and use a 3/32” Allen Wrench to fix it at the desired height.
-
Page 9: 7702-K310 Ncr Cash Drawer Integration Platform Adapter
7702-K310 NCR Cash Drawer Integration Platform Adapter Kit Contents Installation Procedure 1. Install the Pole on the Adapter Plate using the Flat Head Socket Cap Screw. - Page 10 7702-K310 NCR Cash Drawer Integration Platform Adapter 2. Install the Adapter Plate and Pole Assembly on the Tray Support Bracket using four (4) Phillips Pan Head Machine Screws. Note: The Integration Tray is not shown in the illustration for clarity. 3. Install the Left Swing Arm Skirt.
- Page 11 7702-K310 NCR Cash Drawer Integration Platform Adapter 5. Install the Base Cover on the Pole as shown.
-
Page 13: 7702-K311 Hd Tilter And Quick-Release Adapter
7702-K311 HD Tilter and Quick-Release Adapter Kit Contents Not Shown: • 10–32x3/8” Pan Head Phillips Screw (Qty. 4) – To mount the Adapter Plate on the Spring-Loaded Tilter • M4–0.7x12mm Flat Head Phillips Machine Screw (Qty. 2) – To secure the Adapter Plate on the terminal •... -
Page 14: Installation Procedure
4-10 7702-K311 HD Tilter and Quick-Release Adapter Installation Procedure 1. Install the Adapter Plate on the Spring-Loaded Tilter using four (4) 10–32x3/8” Pan Head Phillips Screws. 2. Insert the Adapter Plate studs (2) into the openings in the Rear Cover of the Terminal at a slight angle as shown. - Page 15 7702-K311 HD Tilter and Quick-Release Adapter 4-11 4. Install the Mount Yoke on the Pole. Adjust the height of the Yoke and use a 3/32” Allen Wrench to fix it at the desired height. 5. Install the Terminal and Adapter Plate Assembly on the Yoke using the Dog Washer, and 10-32x3/8”...
- Page 16 4-12 7702-K311 HD Tilter and Quick-Release Adapter 6. Adjust the tilt angle of the terminal and use a 7/32” Allen Wrench to fix it in the desired angle.
-
Page 17: Kit Contents
7702-K314/K317 Thru Mount Pole with HD Tilter and Quick-Release Adapter Kit Contents Not Shown: • 10–32x3/8” Pan Head Phillips Screw (Qty. 4) – To mount the Adapter Plate on the Spring-Loaded Tilter • M4–0.7x12mm Flat Head Phillips Machine Screw (Qty. 2) – To secure the Adapter Plate on the terminal •... -
Page 18: Installation Procedure
7702-K314/K317 Thru Mount Pole with HD Tilter and Quick- 5-14 Release Adapter Installation Procedure 1. Install the Pole on the tabletop. a. Drill a 3/8” hole through the tabletop. b. Secure the Pole on the tabletop using the Washer (2), Split Washer, and Hex Bolt. - Page 19 7702-K314/K317 Thru Mount Pole with HD Tilter and Quick- 5-15 Release Adapter 3. Install the Grommets on the cable openings of the Pole.
- Page 20 7702-K314/K317 Thru Mount Pole with HD Tilter and Quick- 5-16 Release Adapter 4. Route the cable(s) through the Pole.
-
Page 21: 7702-K315 Freestanding Base
7702-K315 Freestanding Base Kit Contents Installation Procedure Install the Pole on the Freestanding Base using the Flat Head Socket Cap Screw. - Page 22 6-18...
-
Page 23: 7702-K316 4" Extension Arm
7702-K316 4” Extension Arm Kit Contents Installation Procedure Install the Extension Arm on the Mount Yoke using the Dog Washer and 10-32x3/8” Phillips Flat Head Machine Screw. - Page 24 7-20...
