- Page 1 KIT INSTRUCTIONS Wall Mount 7702-K320 Issue D...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Kit Contents
Wall Mount This kit provides components to secure any of the following to a vertical surface: • RealPOS XR5 POS (7701) • RealPOS XR7 POS (7702) • RealPOS XR7 Plus POS (7703) • X-Series Displays (5968/5985) • XL10 Display (5910) • XL15 Display (5915) Kit Contents... -
Page 4: Installation Procedures
Wall Mount Installation Procedures 1. Secure the VESA Mount (with UP arrow pointing up) to the vertical surface using lag screws (4). Make sure you install the screws into the studs or that you use hardware of similar strength. Use the bracket as a template to mark the location of the holes or use the dimensions shown below. - Page 5 Wall Mount 2. Install the Wall Mount Bracket (with the thumb screw facing up) onto the back of the terminal with the supplied screws (4). Use the appropriate screws for the terminal. Terminal Screw RealPOS XR5 (7701) 006-8615964 RealPOS XR7 (7702) M4 x 8, Machine, Phillips, Pan Head Real POS XR7 Plus POS (7703) X-Series Displays (5968/5985)
- Page 6 Wall Mount 3. Hang the terminal on the VESA Mount. a. Insert the mushroom studs on the Wall Mount into the elongated slots on the VESA Mount. b. Slide the terminal down to lock the brackets together. c. Secure the brackets with the thumbscrew.
