Manual No. 577014-072 • Rev. D
Operator's Quick Help
T 2: DELIVERY NEEDED
1 Warning(s)
12/20/2012 06:01 PM
0 Alarms(s)
Overview
Tank Overview
Print (0)
TANK 1: reg
!
TANK 2: diesel
Home
Fuel Volume
3655
Fuel Volume
1600
Fuel Height
38.6
Fuel Height
20.6
Ullage 100%
6345
Ullage 100%
8345
Temperature
60.8
Temperature
61.9
Favorites
Water Height
3.0
Water Height
0.0
Menu
Actions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Veeder-Root TLS-450 PLUS
Summary of Contents for Veeder-Root TLS-450 PLUS
- Page 1 Manual No. 577014-072 • Rev. D Operator's Quick Help T 2: DELIVERY NEEDED 1 Warning(s) 12/20/2012 06:01 PM 0 Alarms(s) Overview Tank Overview Print (0) TANK 1: reg TANK 2: diesel Home Fuel Volume 3655 Fuel Volume 1600 Fuel Height 38.6 Fuel Height 20.6...
- Page 2 Notice Console Serial and Form Numbers Veeder-Root makes no warranty of any kind with regard to this publica- Write in Form and Serial Numbers from the label on the bottom of the tion, including, but not limited to, the implied warranties of merchantabili- console housing for future reference: ty and fitness for a particular purpose.
-
Page 3: Table Of Contents
Table of Contents Example TLS-450PLUS Home Screen-1 Tank Monitored, 1 Warning ................1 TLS-450PLUS Front Panel Status Lights ........................1 Example Status Bar Notifications ..........................2 System Icons ................................2 Security Login ................................4 Workflow Wizard................................4 TLS-450PLUS Comm Ports ............................5 Table 1 - Configurable (C) / Non-Configurable (NC) Ports For Comm Modules In Comm Slots 1-3 ...... -
Page 4: Example Tls-450Plus Home Screen-1 Tank Monitored, 1 Warning
Page 1 Example TLS-450PLUS Home Screen- System Date and Time 12/20/2012 06:01 PM 1 Tank Monitored, 1 Warning Bread Crumbs - Menu path to the Setup Communication Ethernet Port Date & Time current screen - touch a previous tab to return to that screen. T 1: DELIVERY NEEDED 1 Warning(s) 1 Warning(s) -
Page 5: Example Status Bar Notifications
Page 2 Example Status Bar Notifications System Icons Power On to console and no Home Screen Icon - Touch to navigate to the home screen. SYSTEM STATUS 0 Warning(s) 0 Alarms(s) Default is the Tank Overview screen (shown at left). warnings or alarms from system. - Page 6 Page 3 System Icons (Continued) Screen Dependent Icons - The number in the circle under the Actions icon indicates the device you are viewing or setting up. Touching Menu Icon - Touch to access System Setup Menu, Reports, the circled number displays all of the similar devices in a row along the Diagnostics and other screens (Administrator assigned access).
-
Page 7: Security Login
You will need to log back in to access your user account. Workflow Wizard Username: Workflow Wizard is an application in the TLS-450PLUS that guides the user through the Veeder-Root recommended setup screens during the Password: console’s initial commissioning. From the console’s touch screen you access Workflow Wizard Setup by touching Menu>Setup>Workflow Wizard>Setup Workflow. -
Page 8: Tls-450Plus Comm Ports
Page 5 TLS-450PLUS Comm Ports - Menu>Setup>Communication Front of console Figure 1 illustrates the console’s plug-in module locations. Input/output cables to the console’s Comm Modules attach to connectors on each module’s end plate, and are accessible through an opening in the base of the console. - Page 9 Page 6 Table 1 - Configurable (C) / Non-Configurable (NC) Ports For Selectable Comm Modules (Comm Bay Slots 1 - 3 Only) Slot 1 Slot 2 Slot 3 Port Port Port Comm Comm Module Type RS-232 Single Port (also EDIM, Satellite S-SAT and Satellite H-JBox apps.) RS-232 Dual Port (also EDIM, Satellite S-SAT and Satellite H-JBox apps.)* RS-485 Single Port Serial...
-
Page 10: Port Assignments For Fixed Comm Modules In Comm Slots 4 & 5
Page 7 Port Assignments For Fixed Comm Modules In Comm Bay Slots 4 & 5 Ethernet port 1 (upper ) USB ports: 1 (upper), 2 (lower) Front of Console Future expansion port Ethernet port 2 (middle) Switch port (lower) Comm Bay Slots... -
Page 11: Using On-Board Help
• Understanding ATG -This help section explains the fundamentals of arrows to scroll through a topic. You can also drag and pan through automatic tank gauges (ATG) as implemented by Veeder-Root. a topic. Touch the ‘X’ in the right corner of the Help screen title bar to •... -
Page 12: Alarm Limit Settings
Page 9 Alarm Limit Settings - Menu>Setup>Tank>Limits Configure An Ethernet Port - Menu>Setup>Communication>Ethernet Port The diagram below shows the relative position of tank alarm (Limit) settings. System Status 0 Warning(s) 07/20/2023 08:01 AM 0 Alarms(s) Share Setup Communication Ethernet Port Home IP Address Type DYNAMIC... -
Page 13: Backup Data
Page 10 Software Version - Menu>Overview>About Backup Data - Menu>Software Maintenance>DB Backup System Status 0 Warning(s) 07/20/2022 09:30 AM System Status 0 Warning(s) 07/20/2022 09:10 AM 0 Alarms(s) 0 Alarms(s) Share Overview About Software Maintenance DB Backup Share Home Console Series # 8600 Created Jul 10 2022 17:43:52... -
Page 14: Software Download
Page 11 Paths To Frequently Used Screens Software Download - Menu>Software Maintenance> Download Alarm Definitions - Actions>Help>Show TOC>Home>Troubleshooting> System Status 0 Warning(s) 07/20/2022 09:15 AM Alarms and Warnings 0 Alarms(s) Share Software Maintenance Download Viewing Custom Alarm Labels - Home Current Version int_ISD_main-a2a58b68c999.99 Menu>Setup>Custom Alarms>View... -
Page 15: Changing Printer Paper
Page 12 Paths To Frequently Used Screens - Continued Changing Printer Paper Swing down the printer cover (1) and Ticketed Delivery - push the paper feed release lever (2) Menu>Reports>Delivery>Ticketed Delivery down. Remove the roll of paper. Insert Upgrade Features - the roll into the paper tray with the end Menu>Software Maintenance>Upgrade Features of the paper tail facing you from the...
