- Page 1 Manual No: 577013-608 Revision: N TLS-50 Site Prep Manual...
- Page 2 Notice Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this publication.
-
Page 3: Table Of Contents
Introduction Related Manuals .......................2 Safety Symbols .........................2 Site Considerations Control Drawing ........................3 National Electrical Code Compliance ................4 Probe-to-Console Wiring ..................4 Shielded Cable or Veeder-Root Direct Burial Cable Required ......4 Wire Length ....................4 Splices ......................4 Wire Gauges - Color coded ................4 Power Wiring ......................4... - Page 4 Table of Contents RS-232 Communications RS-232 Peripheral Equipment Requirements ..............22 RS-232 Connections .......................22 To a Device Less Than 50 Feet from the Console ..........22 To a Device More Than 50 Feet from the Console ..........22 Surge Protection for Communication Devices ..............23 System Serial Security ....................24 RS-232 Serial Communication Setup ................24 DB-9 Connector Pin-Outs ....................25...
- Page 5 Table of Contents Console Specifications Physical Specifications...................67 Environmental Specifications .................67 Electrical Specifications..................67 Signal Input Specifications ..................67 Signal Output Specifications...................67 Front Panel User Interface (Consoles w/Display)...........67 Probe Circuit Codes ......................68 Appendix A: TLS-50 and TLS-50C Safety Instructions ...... A-1 Figures Figure 1. Locating the console form number .............1 Figure 2.
-
Page 6: Figure 1. Locating The Console Form Number
TLS-50C w/o keypad or display, w/com, up to 3 probes 8469X0-460 TLS-50 w/o keypad or display, w/com and relay, up to 6 probes Label on top of console MANUFACTURED BY: VEEDER-ROOT, 125 POWDER FOREST DR. SIMSBURY, CT. 06070 U.S.A. FORM NO.: 846960-XX0 SERIAL NO.: XXXXXXXXXXXXXX consoles\formlabel.eps Console Form No. -
Page 7: Introduction
Introduction Related Manuals TLS-50 system specifications • After the console is wired to its power source and probes, you should program the console following the setup instructions contained in the TLS-50 Setup & Operation Manual. Related Manuals 577013-609 TLS-50 Setup & Operation Manual 576013-635 RS-232 Serial Interface Manual 576013-859... -
Page 8: Site Considerations
This system makes TLS-50 probes safe for use in a Class I, Group D hazardous location. TLS-50 probe wiring is intrinsically safe only when connected to Veeder-Root's TLS-50 Consoles. Reference Form Number 8469 (TLS-50/TLS-50C Consoles) and Form Number 8462, 8463, 8468, and 8473 (Probes). -
Page 9: National Electrical Code Compliance
1000 feet (304 m). Wire runs must be less than 1000 feet to meet intrinsic safety requirements. Splices Veeder-Root recommends that no splices be made in the wire run between a probe junction box and the console. Each splice degrades signal strength and could result in poor system performance. Wire Gauges - Color coded Shielded cable must be used in all installations. -
Page 10: Probe Wiring Safety Issues
Site Considerations Probe Wiring Safety Issues Probe Wiring Safety Issues WARNING Probes operate in areas where flammable liquids and explosive vapors may be present. Improper installation may result in fire or explosion causing serious injury or death. Practice the following: 1. - Page 11 Site Considerations Selecting a Console Location Select a mounting location on the inside of any building. The console must be protected from severe vibration, extremes in temperature and humidity, rain, and other conditions that could harm computerized electronic equipment. The equipment is designed to operate safely under the following range of conditions: Temperature range 0 to 40°C - ( storage temperature range of -40 to +74°C).
-
Page 12: Console Installation
Console Installation Mounting the Console Figure 3 illustrates recommended console mounting. Install the console fastening devices to the mounting surface using the hole pattern (6.7” x 5.7”) shown in Figure 4. Mounting screws up to 3/16” diameter may be used. Install metal conduit (1/2”... -
Page 13: Figure 4. Console Dimensions And Designated Conduit Knockouts
Console Installation Mounting the Console 5.3'' 0.93'' (135 mm) (23,6 mm) 0.93'' (23,6 mm) 7.4" (188 mm) 0.34'' 6.7" consoles\tls50dimen.eps (8,6 mm) typ. (170 mm) 6.4'' (163 mm) 0.7'' (17,8) 5.7'' (145 mm) 2.6'' (66) 0.22'' (5,6 mm) dia. console mounting holes (4 places) 1/2-inch IPS and .56 inch (22 &... -
Page 14: Wiring The Console
Console Installation Wiring the Console Wiring the Console WARNING The console contains voltages which can be lethal. It is connected to devices that must be intrinsically safe. Connecting power wires to a live circuit can cause electrical shock that may result in serious injury or death. -
Page 15: Probe Installation
Probe Installation Probe Manhole Installation At each underground probe location, install a 14-inch (355 mm) minimum diameter approved manhole according to the manufacturer’s instructions (Note: probes should be located at least 24 inches (610 mm) from the submersible pump to avoid erroneous probe readings when the pump is running). Position the manhole so that there is necessary clearance for junction box installation and wiring. -
Page 16: Figure 7. Tls-50 Probe Installation Example - Underground Storage Tank
Probe Installation Probe Installation CAUTION! Handle probes carefully. Striking or dropping the probe will result in loss of calibration and could cause permanent damage. Probe cable Weatherproof junction box with 1/2" NPT 14'' min. dia. manhole threads (16 cubic inch minimum) Riser cap with cord grip Cord grip seals bushing and nut... -
Page 17: Special Instructions For Ust's With Metal Riser Caps
At sites that require installation of a riser adaptor (Phil-Tite M/F 4X4 or equivalent) at the top of the riser, do so following the manufacturer’s instructions. Next screw the adapter ring from the Veeder-Root kit ( 312020-952) onto the riser adaptor by hand until the gasket contacts the sealing surface. -
Page 18: Installing Field Wiring From Probes To Tls-50 Console
Probe Installation Installing Field Wiring from Probes to TLS-50 Console Installing Field Wiring from Probes to TLS-50 Console Two wiring run methods are commonly used for probes - Shielded wiring pulled through buried, sealed 1/2” rigid conduit (discussed in the following paragraphs); or direct burial cable (discussed on page 15). WARNING Probes operate in areas where flammable liquids and explosive vapors may be present. -
Page 19: Sealing Field Connections
Probe Installation Buried Rigid Conduit SEALING FIELD CONNECTIONS 1. Pull the wires from the probe canister into the junction box. Pull two wires from the console through the seal-off box and into the junction box. 2. Using wire nuts, connect the two wires from the probe to the two wires coming from the console. Be sure to observe color codes or tags when making these connections. -
Page 20: Direct Burial Cable - Probe To Console Field Wiring
1/4” to 1/ 2” bead of Veeder-Root recommended silicone sealant over the backer rod to within a minimum of 3/8” below the pavement surface [see Figure 13]. -
Page 21: Connecting Probes To The Console
Probe Installation Connecting Probes to the Console Connecting Probes to the Console WARNING The equipment is used in location where lethal voltages and explosive vapors or flammable fuels may be present. Care must be taken when installing, servicing or replacing parts in the system or serious injury or death from explosion, fire or shock may occur. -
Page 22: Grounding Probe Shields And Drain Wires
Probe Installation Precautions To Follow When Connecting Probes to TLS-50 Console Probe Number TANK Number & Product PROBE 1 TANK PROBE 2 IN TANK PROBE 3 IN TANK PROBE 4 IN TANK PROBE 5 IN TANK PROBE 6 IN TANK consoles\tls50\prbtnk.eps Figure 14. -
Page 23: System Setup Security
Probe Installation System Setup Security System Setup Security To protect against unauthorized access to system operation DIP switch 4 of SW1 on the Power Supply board lets you lockout setup and diagnostic menus after making initial programming (for consoles w/display only). Consoles are shipped from the factory with this switch in the open (disabled) position. -
Page 24: Figure 17. Connecting I/O Devices To Console
Probe Installation Overfill Alarm Relay WARNING SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY. CONSOLE NO REPAIRS SHOULD BE ATTEMPTED. REFER SERVICING TO QUALIFIED POWER PERSONNEL ONLY. RELAY RATING 120/240 VAC 2 A MAX PROBE 1 PROBE 2 SETUP PROBE 3 PROBE 4 PROBE 5 PROBE 6... -
Page 25: Applying Power To System
Applying Power to System Cold Boot - Initial Power Up (Consoles w/Display) Once all devices are connected to the console, attach the console power wires to the appropriate power panel connections. Close the front panel of the console. Switch on the AC power breaker. The system will automatically run a cold boot self-diagnostic program when you power up the console for the first time: Test Passed Test Failed... -
Page 26: Warm Boot
Applying Power to System Warm Boot Warm Boot CONSOLES WITH DISPLAY Once the system is setup, every time power to consoles is switched Off and On, the software will run a self- diagnostic warm boot program and display the test results: Test Passed Test Failed Action (If Failed) -
Page 27: Rs-232 Communications
TO A DEVICE LESS THAN 50 FEET FROM THE CONSOLE Veeder-Root recommends that you use a null-modem cable no longer than 50 feet for direct connections between the console and a remote device. Cable runs longer than 50 feet can result in data errors, component damage, or both. -
Page 28: Surge Protection For Communication Devices
RS-232 Communications Surge Protection for Communication Devices Computer Console DB-9 Connector Available ALL FUNCTIONS NORMAL Port T1 VOL: 9889 GAL DB-25 Connector TLS-50 DB-9 Connector 2 Twisted Pairs (24 - 26 AWG) DB-25 Connector DB-25 Connector RTS/DTR RTS/DTR CONTROL CONTROL Loopback Loopback Normal... -
Page 29: System Serial Security
RS-232 Communications System Serial Security System Serial Security To protect against unauthorized access to system operation DIP switch 1 of SW1 on the Power Supply board lets you enter a 6-digit security code before the system will respond to a serial command (only applies to consoles having form numbers 8469X0-260, 230, &... -
Page 30: Db-9 Connector Pin-Outs
RS-232 Communications DB-9 Connector Pin-Outs Table 2.- RS-232 Setup Options and Defaults Setup Options Console Form Numbers Default Handshaking None, XON/XOFF, or hardware 8469X0-260 XON/XOFF 8469X0-230, -460 None Printer page eject Yes or no 8469X0-260 8469X0-230, -460 Answer on options 0 to 9 8469X0-260 8469X0-230, -460... -
Page 31: Rs-232 Commands
RS-232 Commands System Reset ............page 27 Remote Alarm Reset . -
Page 32: Function Code: 001
RS-232 Commands Function Code: 001 Function Code: 001 Function Type: System Reset Version 1 Command Format: Display: <SOH>S00100 Computer: <SOH>s00100 Typical Response Message, Display Format: <SOH> S00100 <ETX> Typical Response Message, Computer Format: <SOH>s001000000000000&&CCCC<ETX> Notes: 0000000000 - Not Used. && - Data Termination Flag CCCC - Message Checksum... -
Page 33: Function Code: 003
RS-232 Commands Function Code: 003 Function Code: 003 Function Type: Remote Alarm Reset Version 1 Command Format: Display: <SOH>S00300 Computer: <SOH>s00300 Typical Response Message, Display Format: <SOH> S00300 <ETX> Typical Response Message, Computer Format: <SOH>s0030000000000&&CCCC<ETX> Notes: 0000000000 - Not Used &&... -
Page 34: Function Code: 201
RS-232 Commands Function Code: 201 Function Code: 201 Function Type: In-Tank Inventory Report V e r s i o n 1 Command Format: Display: <SOH>I201TT Computer: <SOH>i201TT Typical Response Message, Display Format: <SOH> I201TT TANK VOLUME TC VOLUME HEIGHT WATER TEMP 5329 5413... -
Page 35: Function Code: 205
RS-232 Commands Function Code: 205 Function Code: 205 Function Type: In-Tank Status Report V e r s i o n 1 Command Format: Display: <SOH>I205TT Computer: <SOH>i205TT Typical Response Message, Display Format: <SOH> I205TT TANK STATUS ALL FUNCTIONS NORMAL <ETX> Typical Response Message, Computer Format: <SOH>i205TT0000000000TTnnAA... -
Page 36: Function Code: 504
RS-232 Commands Function Code: 504 Function Code: 504 Function Type: Set System (RS-232) Security Code V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S50400aaaaaa Display: <SOH>I50400 Computer: <SOH>s50400aaaaaa Computer: <SOH>i50400 Typical Response Message, Display Format: <SOH>... -
Page 37: Function Code: 50C
RS-232 Commands Function Code: 50C Function Code: 50C Function Type: Set Remote Printer Page Eject Flag Version 1 Command Format: Set: Inquire: Display: <SOH>S50C00f Display: <SOH>I50C00 Computer: <SOH>s50C00f Computer: <SOH>i50C00 Typical Response Message, Display Format: <SOH> I50C00 <ETX> Typical Response Message, Computer Format: <SOH>i50C000000000000f&&CCCC<ETX>... -
Page 38: Function Code: 50D
RS-232 Commands Function Code: 50D Function Code: 50D Function Type: Set Print Temperature Compensation Flag Version 1 Command Format: Set: Inquire: Display: <SOH>S50D00f Display: <SOH>I50D00 Computer: <SOH>s50D00f Computer: <SOH>i50D00 Typical Response Message, Display Format: <SOH> I50D00 <ETX> Typical Response Message, Computer Format: <SOH>i50D000000000000f&&CCCC<ETX>... -
Page 39: Function Code: 50E
RS-232 Commands Function Code: 50E Function Code: 50E Set Temperature Compensation Value Version 1 Function Type: Command Format: Set: Inquire: Display: <SOH>S50E00TTT.T Display: <SOH>I50E00 Computer: <SOH>s50E00FFFFFFFF Computer: <SOH>i50E00 Notes: TTT.T - Compensation Temperature, Degrees and tenths (Decimal) FFFFFFFF - Compensation Temperature, Degrees (ASCII Hex IEEE float) Typical Response Message, Display Format: <SOH>... -
Page 40: Function Code: 517
RS-232 Commands Function Code: 517 Function Code: 517 Function Type: Set System Type & Language Flags Version 1 Command Format: Set: Inquire: Display: <SOH>S51700ULL Display: <SOH>I51700 Computer: <SOH>s51700ULL Computer: <SOH>i51700 Typical Response Message, Display Format: <SOH> I51700 <ETX> Typical Response Message, Computer Format: <SOH>i517000000000000ULL&&CCCC<ETX>... -
Page 41: Function Code: 601
RS-232 Commands Function Code: 601 Function Code: 601 Function Type: Set Tank Configuration Version 1 Command Format: Set: Inquire: Display: <SOH>S601TTf Display: <SOH>I601TT Computer: <SOH>s601TTf Computer: <SOH>i601TT Typical Response Message, Display Format: <SOH> I601TT <ETX> Typical Response Message, Computer Format: <SOH>i601TT0000000000TTf... -
Page 42: Function Code: 604
RS-232 Commands Function Code: 604 Function Code: 604 Function Type: Set Tank 1 Point (Full Height Volume) Version 1 Command Format: Set: Inquire: Display: <SOH>S604TTVVVVVV Display: <SOH>I604TT Computer: <SOH>s604TTFFFFFFFF Computer: <SOH>i604TT Notes: TT - Tank Number (Decimal, 00 = all) VVVVVV - Full Height Volume, (Decimal) FFFFFFFF - Full Height Volume, (ASCII Hex IEEE float) Typical Response Message, Display Format:... -
Page 43: Function Code: 605
RS-232 Commands Function Code: 605 Function Code: 605 Function Type: Set Tank 4-Point (Full, 3/4, 1/2, & 1/4 Height) Volumes Version 1 Command Format: Set: Inquire: Display: <SOH>S605TTGGGGGGggggggGGGGGGgggggg Display: <SOH>I605TT or: <SOH>S605TTGGGG,gggg,GGGG,ggg Computer: <SOH>s605TTFFFFFFFFffffffffFFFFFFFFffffffff Computer: <SOH>i605TT Notes: TT - Tank Number (Decimal, 00 = all) GGGGGG - Full Height Volume, Gallons (Decimal) gggggg - 3/4 Height Volume, Gallons (Decimal) GGGGGG - 1/2 Height Volume, Gallons (Decimal) -
Page 44: Function Code: 606
RS-232 Commands Function Code: 606 Function Code: 606 Function Type: Set Tank 20 Point Full, 95%, 90%,... Volumes Version 1 Command Format: Set: Inquire: Display: <SOH>S606TTGGGGGGggggggGGGGGGgggggg... Display: <SOH>I606TT or: <SOH>S606TTGGGG,gggg,GGGG,... Computer: <SOH> Computer: <SOH>i606TT s 6 0 6 T F F F F F F F F . . . Notes: TT - Tank Number (Decimal, 00=all) GGGGGGgggggg - Series of 20 Volumes, Gallons (Decimal) -
Page 45: Function Code: 607
RS-232 Commands Function Code: 607 Function Code: 607 Function Type: Set Tank Diameter V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S607TTHHH.HH Display: <SOH>I607TT Computer: <SOH>s607TTFFFFFFFF Computer: <SOH>i607TT Notes: TT - Tank Number (Decimal, 00 = all) HHH.HH - Tank Diameter (Decimal) FFFFFFFF - Tank Diameter (ASCII Hex IEEE float) -
Page 46: Function Code: 608
RS-232 Commands Function Code: 608 Function Code: 608 Function Type: Set Tank Tilt V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S608TTHHH.HH Display: <SOH>I608TT Computer: <SOH>s608TTFFFFFFFF Computer: <SOH>i608TT Notes: TT - Tank Number (Decimal, 00 = all) HHH.HH - Tank Tilt, (Decimal) FFFFFFFF - Tank Tilt, (ASCII Hex IEEE float) Typical Response Message, Display Format:... -
Page 47: Function Code: 609
RS-232 Commands Function Code: 609 Function Code: 609 Function Type: Set Tank Thermal Expansion Coefficient V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S609TTc.cccccc Display: <SOH>I609TT Computer: <SOH>s609TTFFFFFFFF Computer: <SOH>i609TT Notes: TT - Tank Number (Decimal, 00 = all) c.cccccc - Thermal Expansion Coefficient (decimal) FFFFFFFF -... -
Page 48: Function Code: 60A
RS-232 Commands Function Code: 60A Function Code: 60A Function Type: Set Tank Linear Calculated Full Volume V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S60ATTVVVVVV Display: <SOH>I60ATT Computer: <SOH>s60ATTFFFFFFFF Computer: <SOH>i60ATT Notes: TT - Tank Number (Decimal, 00 = all) VVVVVV - Full Height Volume, (Decimal) FFFFFFFF - Full Height Volume, (ASCII Hex IEEE float) -
Page 49: Function Code: 621
RS-232 Commands Function Code: 621 Function Code: 621 Function Type: Set Tank Low Level Limit Version 1 Command Format: Set: Inquire: Display: <SOH>S621TTVVVVVV Display: <SOH>I621TT Computer: <SOH>s621TTFFFFFFFF Computer: <SOH>i621TT Notes: TT - Tank Number (Decimal, 00 = all) VVVVVV - Low Level Limit, (Decimal) FFFFFFFF - Low Level Limit, (ASCII Hex IEEE float) Typical Response Message, Display Format: <SOH>... -
Page 50: Function Code: 624
RS-232 Commands Function Code: 624 Function Code: 624 Set Tank High Water Level Limit Version 1 Function Type: Command Format: Set: Inquire: Display: <SOH>S624TTHH.H Display: <SOH>I624TT Computer: <SOH>s624TTFFFFFFFF Computer: <SOH>i624TT Notes: TT - Tank Number (Decimal, 00 = all) HH.H - High Water Level Limit, (Decimal) FFFFFFFF - High Water Level Limit, (ASCII Hex IEEE float) Typical Response Message, Display Format: <SOH>... -
Page 51: Function Code: 628
RS-232 Commands Function Code: 628 Function Code: 628 Set Tank Max Volume Limit Version 1 Function Type: Command Format: Set: Inquire: Display: <SOH>S628TTVVVVVV Display: <SOH>I628TT Computer: <SOH>s628TTFFFFFFFF Computer: <SOH>i628TT Notes: TT - Tank Number (Decimal, 00 = all) VVVVVV - Max Volume Limit, (Decimal) FFFFFFFF - Max Volume Limit, (ASCII Hex IEEE float) Typical Response Message, Display Format: <SOH>... -
Page 52: Function Code: 638
RS-232 Commands Function Code: 638 Function Code: 638 Function Type: Set Tank Overfill Level Limit V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S638TTDDD Display: <SOH>I638TT Computer: <SOH>s638TTDDD Computer: <SOH>i638TT Notes: TT - Tank Number (Decimal, 00 = all) DDD - Overfill Level Limit, (Decimal 0-100%) Typical Response Message, Display Format: <SOH>... -
Page 53: Function Code: 881
RS-232 Commands Function Code: 881 Function Code: 881 Function Type: Set Communication Port Data Version 1 Command Format: Set: Inquire: Display: <SOH>S881CCBBBBBPSDTAA Display: <SOH>I881CC Computer: <SOH>s881CCBBBBBPSDTAA Computer: <SOH>i881CC Typical Response Message, Display Format: <SOH> I881CC CC BBBBB P S D T AA <ETX>... -
Page 54: Function Code: 882
RS-232 Commands Function Code: 882 Function Code: 882 Function Type: Initialize Communication Port Data Version 1 Command Format: Set: Inquire: Display: <SOH>S882CC149 Display: <SOH>I882CC Computer: <SOH>s882CC149 Computer: <SOH>i882CC Notes: 149 - This verification code must be sent to confirm the command Typical Response Message, Display Format: <SOH>... -
Page 55: Function Code: 883
RS-232 Commands Function Code: 883 Function Code: 883 Function Type: Set Serial Communication Language V e r s i o n 1 Command Format: Set: Inquire: Display: <SOH>S88300LL Display: <SOH>I88300 Computer: <SOH>s88300LL Computer: <SOH>i88300 Typical Response Message, Display Format: <SOH> I88300 <ETX>... -
Page 56: Function Code: 884
RS-232 Commands Function Code: 884 Function Code: 884 Function Type: Set Serial Handshaking Version 1 Command Format: Set: Inquire: Display: <SOH>S88400f Display: <SOH>I88400 Computer: <SOH>s88400f Computer: <SOH>i88400 Typical Response Message, Display Format: <SOH> I88400 <ETX> Typical Response Message, Computer Format: <SOH>i884000000000000f&&CCCC<ETX>... -
Page 57: Function Code: 902
RS-232 Commands Function Code: 902 Function Code: 902 Function Type: System Revision Level Report V e r s i o n 1 Command Format: Display: <SOH>I90200 Computer: <SOH>i90200 Typical Response Message, Display Format: <SOH> I90200 SOFTWARE# 349771-vvv-rrr A B CREATED - YY.MM.DD.HH.mm <ETX>... -
Page 58: Function Code: A01
RS-232 Commands Function Code: A01 Function Code: A01 Function Type: Probe Type and Serial Number V e r s i o n 1 Command Format: Display: <SOH>IA01TT Computer: <SOH>iA01TT Typical Response Message, Display Format: <SOH> IA01TT PP KKKK LLLL.LL SSSSSS cccc <ETX>... -
Page 59: Function Code: A02
RS-232 Commands Function Code: A02 Function Code: A02 Function Type: Probe Factory Dry Calibration Values V e r s i o n 1 Command Format: Display: <SOH>IA02TT Computer: <SOH>iA02TT Typical Response Message, Display Format: <SOH> IA02TT TT PP CCC.CCCC <ETX> Notes: TT - Tank Number (Decimal, 00 = all) PP - Probe Type: 03 = MAG1... -
Page 60: Function Code: A10
RS-232 Commands Function Code: A10 Function Code: A10 Function Type: Probe Last Sample Buffers V e r s i o n 1 Command Format: Display: <SOH>IA10TT Computer: <SOH>iA10TT Typical Response Message, Display Format: <SOH> IA10TT TT PP nnnnn ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss... -
Page 61: Function Code: A11
RS-232 Commands Function Code: A11 Function Code: A11 Probe Fast Average Buffers Version 1 Function Type: Command Format: Display: <SOH>IA11TT Computer: <SOH>iA11TT Typical Response Message, Display Format: <SOH> IA11TT TT PP nnnnn ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss... -
Page 62: Function Code: A12
RS-232 Commands Function Code: A12 Function Code: A12 Function Type: Probe Standard Average Buffers V e r s i o n 1 Command Format: Display: <SOH>IA12TT Computer: <SOH>iA12TT Typical Response Message, Display Format: <SOH> IA12TT TT PP nnnnn ssss.sss ssss.sss ssss.sss ssss.sss ssss.sss... -
Page 63: Troubleshooting
Troubleshooting This section contains information to help diagnose system problems. Probe troubleshooting • CPU/Power board replacement • System specifications • System compatible probes • Dual-Function Front Panel Keys (consoles w/Keypads Only) Two of the six front panel keys have dual functions [Figure 21]. consoles\tls50\dkey.eps Back Enter... -
Page 64: Figure 22. Diagnostic Menu - Overview
Troubleshooting Probe Troubleshooting Prints out the Diagnostic Report if your console has the Serial Package option, DIAGNOSTICS you have made the correct communication setup selections, and you have PRESS <ENTER> a serial printer connected. SOFTWARE VERSION XXXXXX-XXX Y T1: PROBE TYPE: T2: PROBE TYPE: T6: PROBE TYPE: GLB01... -
Page 65: Figure 23. Diagnostic Menu - Explanation
Troubleshooting Probe Troubleshooting DIAGNOSTICS PRESS <ENTER> Console's current software version: XXXXXX-XXX SOFTWARE VERSION XXXXXX-XXX Y Options: Y= 1 Alarm package, Y= 2 Serial and Alarm Package). T1: PROBE TYPE: GLB01 Probe's serial number. T1: SERIAL NUMBER XXXXX Probe's manufacturing code. T1: PROBE ID 0XD011 T1: PROBE LENGTH... -
Page 66: Probe Diagnostic Report
Troubleshooting Replacing the CPU Board Probe Diagnostic Report The Diagnostic Report example below is a printout of probe information, for all tanks. The probe functions are discussed in Figure 23. DIAGNOSTICS SOFTWARE VERSION 349771-001-A TANK PROBE TYPE GLB8 GLB8 GLB8 SERIAL NUMBER 123001 123002... -
Page 67: Figure 24. Cpu Board Voltage Test Points (Keypad/Display Version Shown)
Troubleshooting Replacing the CPU Board These voltage test points are on the back of the CPU board (directly behind this upper left corner) Cable to Power Supply Board LED1 PROM chip TLS-50 CPU STATIC SENSITIVE - WEAR GROUNDED ANIT-STATIC WRIST STRAP BEFORE consoles\tls50\cpu.eps HANDLING THIS BOARD! Figure 24. -
Page 68: Prom Chip Replacement (Software Upgrade)
Troubleshooting PROM Chip Replacement (Software Upgrade) PROM Chip Replacement (Software Upgrade) The PROM chip is replaced when a software upgrade is installed. This procedure requires that you perform a RAM clear. 1. If possible, record the current setup information. Turn off power to the system. 2. -
Page 69: Figure 25. Removing Prom Chip
Troubleshooting PROM Chip Replacement (Software Upgrade) Chip socket Chip Removal Tool (Digikey Part No. K293-ND, Removable or equivalent) chip Lifting hooks Chip removal slots Chip socket Chip Removal Tool (P/N 576036-022) lifting hooks Incorrect Correct go down in Angle Angle slots and under chip until tool rests on socket... -
Page 70: Figure 26. Replacing Prom Chip (Keypad/Display Version Shown)
Troubleshooting PROM Chip Replacement (Software Upgrade) These voltage test points are on the back of the CPU board (directly behind this upper left corner)) Cable to Power Supply Board LED1 PROM chip socket consoles\tls50\50cpurm.eps 1) Orient PROM so that the small indented dot on top of the chip is on the same side with the small triangle embossed in the socket's base;... -
Page 71: Replacing The Power Supply Board
Troubleshooting Replacing the Power Supply Board Replacing the Power Supply Board The Power Supply board must be replaced when: Probe data is not being processed, or • The voltage between the GND and 8V test points [Figure 24] on the back of the CPU board is less than 7 Vdc. •... -
Page 72: Console Specifications
Console Specifications PHYSICAL SPECIFICATIONS Width (door closed): 7.6”, open 9.6”) Depth (door closed 2.6”, open 9”)) • Height: 6.7” Weight: 3.5 lbs. • Two PC boards in console: CPU (in door) and Power Supply (in unit) • ENVIRONMENTAL SPECIFICATIONS Console storage and operation: indoor, climate controlled. •... -
Page 73: Probe Circuit Codes
Console Specifications Probe Circuit Codes Probe Circuit Codes Table 2 lists the probes that can be used with various TLS-50 Console Form Nos. Probe Form Nos. 8990 are only compatible with Console Form Nos. 846910-XXX. Table 2.- Probe Circuit Codes Circuit Probe Water... -
Page 74: Appendix A: Tls-50 And Tls-50C Safety Instructions
Appendix A: TLS-50 and TLS-50C Safety Instructions 1. Refer to Veeder-Root Descriptive System Document 331940-003 for system installation requirements. This drawing can be found on the Veeder-Root Tech Docs CD-ROM shipped with your console. 2. Refer to the site preparation procedures in this manual for general instructions on safe installation, use, and replacement. - Page 76 For technical support, sales or other assistance, please visit: www.veeder.com...
