List Of Tags - THORLABS ULN15TK User Manual

Ultra-Low-Noise Laser System
4.2.2

List of Tags

Corresponding to the 'write_param,' 'read_param,' and 'save_param' commands
Name
Laser Configuration
laser_state
laser.current
laser.case.temperature
Laser TEC Control System
laser_tec_ctrl.temperature
laser_tec_ctrl.setpoint
FBG TEC Control System
fbg_tec_ctrl.temperature
fbg_tec_ctrl.setpoint
External TEC Setpoint Adjustment
tec_adj.select
tec_adj.range
tec_adj
Page 8
Type Default
Value
Int. N/A
Float 0
Float N/A
Float N/A
Float 25
Float N/A
Float 25
Int 120
Float 1
Float N/A
Chapter 4: Software Communications
Access
60 = Laser on
61 = Laser off (Normal)
62 = Laser off because of interlock
63 = Laser off because of one of the
following faults:
R
• Laser TEC in error mode
• FBG TEC in error mode
• AUX TEC timeout
64 = Laser state is unknown
65 = Laser is starting (flashing LED)
R/W Nominal open-loop laser current (A)
R Laser case temperature reading in Celsius.
R Laser temperature reading in Celsius.
Set point for the laser TEC control system.
R/W
(deg C)
R FBG temperature reading in Celsius.
Set point for the FBG TEC control system.
R/W
(deg C)
The selected TEC control on which tec_adj
acts:
120: None
R/W
121: Laser TEC
122: FBG TEC
The full-scale range of the TEC setpoint
R/W
adjustment +/- (deg C)
The active tec setpoint adjustment applied
R
to the selected TEC (deg C)
Descriptions
TTN282198 -D02
