AO 046
S-DIAS Analog Output Module
Instruction Manual
Date of creation: 06.06.2017
Version date: 26.07.2023
Article number: 20-010-046-E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AO 046 and is the answer not in the manual?

Questions and answers

Related Manuals for SIGMATEK AO 046

Summary of Contents for SIGMATEK AO 046

  • Page 1 AO 046 S-DIAS Analog Output Module Instruction Manual Date of creation: 06.06.2017 Version date: 26.07.2023 Article number: 20-010-046-E...
  • Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
  • Page 3 AO 046 with 4 outputs (voltage/current switchable) The S-DIAS AO 046 analog output module has four ±10.8 V or 0-21.6 mA analog outputs with a resolution of 16 bits. The analog out- puts are powered by an external +24 V supply. The analog output sys- tem is galvanically separated from the potential of the S-DIAS bus.

  • Page 4: Table Of Contents

    AO 046 S-DIAS ANALOG OUTPUT MODULE Contents Introduction ................5 Target Group/Purpose of this Operating Manual ...... 5 Important Reference Documentation ......... 5 Contents of Delivery ..............5 Basic Safety Directives ............6 Symbols Used ................6 Disclaimer ..................8 General Safety Directives ............
  • Page 5 S-DIAS ANALOG OUTPUT MODULE AO 046 Miscellaneous ................18 Environmental Conditions ............18 Mechanical Dimensions ............19 Connector Layout ..............20 Status LEDs ................. 21 Applicable Connectors ............... 22 Label Field ................... 23 Wiring ..................24 Wiring Example ................24 Note ....................
  • Page 6 AO 046 S-DIAS ANALOG OUTPUT MODULE 14 Disposal ..................33 15 Hardware Class AO046 ............34 15.1 General ..................35 15.2 Analog Outputs [1-4] ..............36 15.3 Time Offset Mode ................ 38 15.4 Communication Interfaces ............38 15.5 Internal Properties ..............39 15.5.1...

  • Page 7: Introduction

    General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours.

  • Page 8: Basic Safety Directives

    AO 046 S-DIAS ANALOG OUTPUT MODULE Basic Safety Directives Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the speci- fied measures are not taken.
  • Page 9 S-DIAS ANALOG OUTPUT MODULE AO 046 INFORMATION Information  Provides important information on the product, handling or relevant sections of the documentation, which require atten- tion. 26.07.2023 Page 7...

  • Page 10: Disclaimer

    It does not guarantee properties under the warranty. Please thoroughly read the corresponding documents and this operat- ing manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations.

  • Page 11: General Safety Directives

    S-DIAS ANALOG OUTPUT MODULE AO 046 General Safety Directives The Safety Directives in the other sections of this operating manual must be observed. These instructions are visually emphasized by symbols. INFORMATION According to EU Directives, the operating manual is a component of a product.

  • Page 12: Software/Training

    AO 046 S-DIAS ANALOG OUTPUT MODULE CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.

  • Page 13: Standards And Directives

    The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product AO 046 conforms to the following European directives: • 2014/35/EU Low-voltage Directive • 2014/30/EU Electromagnetic Compatibility (EMC Directive) •...

  • Page 14: Type Plate

    AO 046 S-DIAS ANALOG OUTPUT MODULE Type Plate HW: Hardware version SW: Software version Page 12 26.07.2023...

  • Page 15: Technical Data

    S-DIAS ANALOG OUTPUT MODULE AO 046 Technical Data Analog Output Voltage Specifications Number of channels -10 … +10 V Output range 0 ... +10 V Output value -30,000 ... +30,000 0 ... +60,000 -10.8 … +10.8 V 0 … +10.8 V Output voltage over range 0 …...

  • Page 16: Analog Output Current Specifications

    AO 046 S-DIAS ANALOG OUTPUT MODULE Analog Output Current Specifications Number of channels Output range 0-20 mA 4-20 mA Output value 0-60,000 12,000-60,000 Output voltage over range 0-21.6 mA 3.8-21.6 mA Output value over range 0-64,800 11,400-64,800 Resolution current 16-bit (ca. 0.3 µA/LSB) Refresh time of all channels minimum 100 µs (corresponds to the S-DIAS cycle time)

  • Page 17: Settling Time Of The Analog Outputs

    S-DIAS ANALOG OUTPUT MODULE AO 046 Settling Time of the Analog Outputs The diagram should display the settling time curve of the analog outputs. An internal mod- ule offset for the time of the S-DIAS Sync can be set. Starting from this time point, the con- stant write process from the S-DIAS bus in the direction of the digital-analog converter begins.

  • Page 18: Electrical Requirements

    AO 046 S-DIAS ANALOG OUTPUT MODULE Electrical Requirements External +24 V supply +18-30 V DC Current consumption of the +24 V typically 34 mA maximum 44 mA supply without load on the analog outputs Current consumption of the +24 V...
  • Page 19 S-DIAS ANALOG OUTPUT MODULE AO 046 26.07.2023 Page 17...

  • Page 20: Voltage Monitoring External +24 V Supply

    AO 046 S-DIAS ANALOG OUTPUT MODULE Voltage Monitoring External +24 V Supply Supply voltage +24 V query of the supply voltage with hysteresis: voltage > 18,0 V -> LED on, ExternVoltageOk=1 voltage < 16,0 V -> LED off, ExternVoltageOk=0 (DC OK-LED shines green)

  • Page 21: Mechanical Dimensions

    S-DIAS ANALOG OUTPUT MODULE AO 046 Mechanical Dimensions 26.07.2023 Page 19...

  • Page 22: Connector Layout

    AO 046 S-DIAS ANALOG OUTPUT MODULE Connector Layout INFORMATION Per channel, either voltage or current can be output only! Between the channels, it possible to select between current and volt- age as desired! The connections of the +24 V supply (X5: pin 1 and pin 2) or the GND supply (X5: pin 3 and pin 4) are internally bridged.

  • Page 23: Status Leds

    S-DIAS ANALOG OUTPUT MODULE AO 046 Status LEDs green Module Status module active No supply available BLINKING (5 Hz) no communication yellow User can be set from the application (e.g. the module LED can be set to blinking through the visuali-...

  • Page 24: Applicable Connectors

    AO 046 S-DIAS ANALOG OUTPUT MODULE Applicable Connectors Connectors: X1, X2: Connectors with spring terminals (included in delivery) The spring terminals are suitable connecting ultrasonically compacted (ultrasonically weld- ed) strands. Connections: Stripping length/Sleeve length: 10 mm Mating direction: parallel to the conductor axis or circuit board Conductor cross section rigid: 0.2-1.5 mm...

  • Page 25: Label Field

    S-DIAS ANALOG OUTPUT MODULE AO 046 Label Field Manufacturer Weidmüller Type MF 10/5 CABUR MC NE WS Weidmüller article number 1854510000 Compatible printer Weidmüller Type Printjet Advanced 230V Weidmüller article number 1324380000 26.07.2023 Page 23...

  • Page 26: Wiring

    AO 046 S-DIAS ANALOG OUTPUT MODULE Wiring Wiring Example Per channel, only voltage or current can be output! Page 24 26.07.2023...

  • Page 27: Note

    S-DIAS ANALOG OUTPUT MODULE AO 046 Note The signals recorded by the analog modules are very small, as compared to the digital signals. To ensure error-free operation, a careful wiring method must be followed: • The 0 V connection of the supply voltage must be connected with the 0 V collection point over the shortest route possible.

  • Page 28: Assembly/Installation

    AO 046 S-DIAS ANALOG OUTPUT MODULE Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter Contents of Delivery. INFORMATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system.

  • Page 29: Mounting

    S-DIAS ANALOG OUTPUT MODULE AO 046 Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches.
  • Page 30 AO 046 S-DIAS ANALOG OUTPUT MODULE Recommended minimum distances of the S-DIAS modules to the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) Page 28 26.07.2023...

  • Page 31: Addressing

    S-DIAS ANALOG OUTPUT MODULE AO 046 10 Addressing Address Size Access Description Reset (hex) (bytes) Type value 000E PDO Write LED Overwrite Register Bit 1…0: LED Channel 1 00 = off (HW status active, no SW overwrite) 01 = Enable SW Overwrite "0"...
  • Page 32 AO 046 S-DIAS ANALOG OUTPUT MODULE 0030 PDO Read Status Register Bit 0: edge limit analog output 1 Bit 1: edge limit analog output 2 Bit 2: edge limit analog output 3 Bit 3: edge limit analog output 4 Bit 4: temperature >...
  • Page 33 S-DIAS ANALOG OUTPUT MODULE AO 046 0040 0040 Raw value output 1 (for PMB) 0000 0042 Raw value output 2 (for PMB) 0000 0044 Raw value output 3 (for PMB) 0000 0046 Raw value output 4 (for PMB) 0000 DAC Control...

  • Page 34: Transport/Storage

    AO 046 S-DIAS ANALOG OUTPUT MODULE 11 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and stor- age, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport.

  • Page 35: Maintenance

    S-DIAS ANALOG OUTPUT MODULE AO 046 13 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instruc- tions from chapter 2 Basic Safety Directives. 13.1 Service This product was constructed for low-maintenance operation. 13.2 Repair INFORMATION In the event of a defect/repair, send the device with a detailed error description to the address listed at the beginning of this document.

  • Page 36: Hardware Class Ao046

    Hardware Class AO046 For the S-DIAS AO046 analog output module This hardware class is used to control the AO 046 hardware module. The module has 4 (±10 V, 0-10 V or 0-20 mA, 4-20 mA) analog outputs. More information on the hardware can be found in the module documentation.

  • Page 37: General

    S-DIAS ANALOG OUTPUT MODULE AO 046 15.1 General Class state State This server shows the actual status of the hardware class. Device ID State The device ID of the hardware module is shown in this server. FPGA version State FPGA version of the module in 16#XY (e.g. 16#10 = version 1.0).

  • Page 38: Analog Outputs [1-4]

    AO 046 S-DIAS ANALOG OUTPUT MODULE 15.2 Analog Outputs [1-4] Analog Output Output The analog output can be set with the write() method. Values are output [1-4] depending on configuration. With the “Analog Output Config” 4-7, the output value can be overridden with the overrange settings.
  • Page 39 S-DIAS ANALOG OUTPUT MODULE AO 046 Error Bits State In this server the error status bits are shown. The respective bits mean the following: Bit 1 Edge limitation output AO1 Bit 2 Edge limitation output AO2 Bit 3 Edge limitation output AO3...

  • Page 40: Time Offset Mode

    AO 046 S-DIAS ANALOG OUTPUT MODULE 15.3 Time Offset Mode Analog Output Property This setting defines whether the time offset mode should be used for the Time Offset analog outputs. time offset mode for analog outputs deactivated time offset mode for analog outputs activated...

  • Page 41: Internal Properties

    S-DIAS ANALOG OUTPUT MODULE AO 046 15.5 Internal Properties The values for the analog output are transmitted as 16-bit value in a range of ±30,000 resp.0-60,000 increments. To be able to use the full resolution of the DAC values for the minimum and maximum value settings are needed which allow 60,000 increments.
  • Page 42 AO 046 S-DIAS ANALOG OUTPUT MODULE Documentation Changes Change date Affected Chapter Note page(s) 23.06.2017 1.2 Analog Output Current Values Overrange changed Specifications 07.07.2017 3 Connector Layout Internally connected added 26.07.2017 1.2 Output Accuracy Analog Chapter new Outputs Voltage 1.4 Output Accuracy Analog...
