AI 0812 S-DIAS Analog Input Module Instruction Manual Date of creation: 25.07.2016 Version date: 26.07.2023 Article number: 20-009-0812-E...
Page 2
(print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
Page 3
AI 0812 S-DIAS Analog Input Module AI 0812 with 8 inputs PT1000/KTY The S-DIAS analog input module AI 0812 has eight PT1000/KTY inputs. As temperature sensors PT1000, KTY10-62, KTY11-62, KTY81-110, KTY81-120, KTY81-150, KTY81-121, and KTY81-122 are supported. 26.07.2023 Page 1...
AI 0812 S-DIAS ANALOG INPUT MODULE Contents Introduction ................5 Target Group/Purpose of this Operating Manual ...... 5 Important Reference Documentation ......... 5 Contents of Delivery ..............5 Basic Safety Directives ............6 Symbols Used ................6 Disclaimer ..................8 General Safety Directives ............
Page 5
S-DIAS ANALOG INPUT MODULE AI 0812 Connector Layout ..............18 Status LEDs ................. 19 Applicable Connectors ............... 19 Label Field ................... 20 Wiring ..................21 Wiring Example ................21 Note ....................22 Assembly/Installation ............23 Check Contents of Delivery ............23 Mounting ..................
Page 6
AI 0812 S-DIAS ANALOG INPUT MODULE 14.2 Repair ................... 30 15 Disposal ..................30 16 Hardware Class AI0812 ............31 16.1 General ..................32 16.2 Analog Inputs [1-8] ..............33 16.3 Communication Interfaces ............33 Page 4 26.07.2023...
General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours.
AI 0812 S-DIAS ANALOG INPUT MODULE Basic Safety Directives Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the speci- fied measures are not taken.
Page 9
S-DIAS ANALOG INPUT MODULE AI 0812 INFORMATION Information Provides important information on the product, handling or relevant sections of the documentation, which require atten- tion. 26.07.2023 Page 7...
It does not guarantee properties under the warranty. Please thoroughly read the corresponding documents and this operat- ing manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations.
S-DIAS ANALOG INPUT MODULE AI 0812 General Safety Directives The Safety Directives in the other sections of this operating manual must be observed. These instructions are visually emphasized by symbols. INFORMATION According to EU Directives, the operating manual is a component of a product.
AI 0812 S-DIAS ANALOG INPUT MODULE CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product AI 0812 conforms to the following European directives: • 2014/35/EU Low-voltage Directive • 2014/30/EU Electromagnetic Compatibility (EMC Directive) •...
S-DIAS ANALOG INPUT MODULE AI 0812 Technical Data Analog Input Specifications Resistance/Temperature Number of inputs Measurement range see the following measurement range table Resolution 0,1 °C or 0,1 Ohm Conversion time for all channels 1 ms Input resistance > 30 KΩ...
AI 0812 S-DIAS ANALOG INPUT MODULE Electrical Requirements Voltage supply from S-DIAS bus +24 V typically 24 mA at +18 V maximum 27 mA at +18 V Current consumption on the S-DIAS bus typically 22 mA at +24 V maximum 24 mA at +24 V...
Page 17
S-DIAS ANALOG INPUT MODULE AI 0812 26.07.2023 Page 15...
AI 0812 S-DIAS ANALOG INPUT MODULE Miscellaneous Article number 20-009-0812 Standard designed according to UL Approbations UKCA Environmental Conditions Storage temperature -20 ... +85 °C Environmental temperature 0 ... +60 °C Humidity 0-95 %, non-condensing Installation altitude above sea 0-2000 m without derating level >...
S-DIAS ANALOG INPUT MODULE AI 0812 Status LEDs Module Status green module active No supply available BLINKING (5 no communication User yellow can be set from the application (e.g. the module LED can be set to blinking through the visualiza-...
AI 0812 S-DIAS ANALOG INPUT MODULE Label Field Manufacturer Weidmüller Type MF 10/5 CABUR MC NE WS Weidmüller article number 1854510000 Compatible printer Weidmüller Type Printjet Advanced 230V Weidmüller article number 1324380000 Page 20 26.07.2023...
AI 0812 S-DIAS ANALOG INPUT MODULE Note The signals recorded by the analog modules are very small, as compared to the digital signals. To ensure error-free operation, a careful wiring method must be followed: • The DIN rail must have an adequate mass connection.
S-DIAS ANALOG INPUT MODULE AI 0812 Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter Contents of Delivery. INFORMATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system.
AI 0812 S-DIAS ANALOG INPUT MODULE Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches.
Page 27
S-DIAS ANALOG INPUT MODULE AI 0812 Recommended minimum distances of the S-DIAS modules to the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) 26.07.2023 Page 25...
AI 0812 S-DIAS ANALOG INPUT MODULE 10 Addressing 10.1 Address Mapping Overview Address Size Description (hex) (bytes) 0000 Cyclic Data for Firmware 0080 cCyclic Data for the HW class 0100 CFG for the Firmware 0180 CFG/version for the HW class...
Page 29
S-DIAS ANALOG INPUT MODULE AI 0812 Cyclic Data for Firmware (memory address range) 0100 Checksum 0102 data length info (special-purpose or status bits) 0104 Bit 0 PMB mode Bit 1 boot loader/update request 0105 reserved Standard Mode (info-register bit 0 = 0)
S-DIAS ANALOG INPUT MODULE AI 0812 12 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and stor- age, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport.
AI 0812 S-DIAS ANALOG INPUT MODULE 14 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instruc- tions from chapter 2 Basic Safety Directives. 14.1 Service This product was constructed for low-maintenance operation. 14.2 Repair INFORMATION In the event of a defect/repair, send the device with a detailed error description to the address listed at the beginning of this document.
S-DIAS ANALOG INPUT MODULE AI 0812 16 Hardware Class AI0812 Hardware Class AI0812 for the S-DIAS Analog Input Module AI0812 This hardware class is used to control the AI0812 hardware module with 8 temperature inputs. More information on the hardware can be found in the module documentation.
AI 0812 S-DIAS ANALOG INPUT MODULE 16.1 General Class State State This server shows the actual status of the hardware class. Device ID State The device ID of the hardware module is shown in this server. FPGA Version State FPGA version of the module in 16#XY (e.g. 16#10 = version 1.0).
S-DIAS ANALOG INPUT MODULE AI 0812 16.2 Analog Inputs [1-8] CableBreak State Cable break detection: Bit 0 cable break at input TMP_1 Bit 1 cable break at input TMP_2 Bit 2 cable break at input TMP_3 Bit 3 cable break at input TMP_4...
Page 36
AI 0812 S-DIAS ANALOG INPUT MODULE Documentation Changes Change Affected Chapter Note date page(s) 27.03.2017 1.2 Measurement Range of Added value for short circuit monitoring Temperature Inputs 17.08.2017 1.5 Environmental Conditions Added operating conditions 3.2 Applicable Connectors Added sleeve length Added info regarding ultrasonically welded strands 08.09.2017...
