- Page 1 AM 222 S-DIAS Analog Mixed Module Instruction Manual Date of creation: 20.03.2015 Version date: 22.11.2023 Article number: 20-017-222-E...
- Page 2 (print, photocopy, microfilm or in any other process) without the express permission. We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsi- ble for technical or printing errors in the handbook and assumes no responsibility for damages that occur through...
- Page 3 2 current inputs 2 current outputs The S-DIAS AM 222 analog mixed module has two current inputs, 0-20 mA and 4-20 mA respectively, each with a 16-bit resolution as well as two current outputs, 0-20 mA and 4-20 mA respectively, with a 12-bit resolution.
-
Page 4: Table Of Contents
AM 222 S-DIAS ANALOG MIXED MODULE Contents Introduction ................5 Target Group/Purpose of this Operating Manual ...... 5 Important Reference Documentation ......... 5 Contents of Delivery ..............5 Basic Safety Directives ............6 Symbols Used ................6 Disclaimer ..................8 General Safety Directives ............ - Page 5 S-DIAS ANALOG MIXED MODULE AM 222 Mechanical Dimensions ............17 Connector Layout ..............18 Status LEDs ................. 19 Applicable Connectors ............... 19 Label Field ................... 20 Wiring ..................21 Wiring Example ................21 Note ....................22 Signal Source connection ............23 Load Connection.................
- Page 6 AM 222 S-DIAS ANALOG MIXED MODULE 14 Maintenance ................31 14.1 Service ..................31 14.2 Repair ................... 31 15 Disposal ..................31 16 Hardware Class AM222 ............32 16.1 General ..................33 16.2 Analog Inputs and Outputs ............34 16.3 Cable Break Detection and Measurement Values ....35 16.4...
-
Page 7: Introduction
General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours. -
Page 8: Basic Safety Directives
AM 222 S-DIAS ANALOG MIXED MODULE Basic Safety Directives Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes: DANGER Danger indicates that death or serious injury will occur, if the speci- fied measures are not taken. - Page 9 S-DIAS ANALOG MIXED MODULE AM 222 INFORMATION Information Provides important information on the product, handling or relevant sections of the documentation, which require atten- tion. 22.11.2023 Page 7...
-
Page 10: Disclaimer
It does not guarantee properties under the warranty. Please thoroughly read the corresponding documents and this operat- ing manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations. -
Page 11: General Safety Directives
S-DIAS ANALOG MIXED MODULE AM 222 General Safety Directives The Safety Directives in the other sections of this operating manual must be observed. These instructions are visually emphasized by symbols. INFORMATION According to EU Directives, the operating manual is a component of a product. -
Page 12: Software/Training
AM 222 S-DIAS ANALOG MIXED MODULE CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber. -
Page 13: Standards And Directives
The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product AM 222 conforms to the following European directives: • 2014/35/EU Low-voltage Directive • 2014/30/EU Electromagnetic Compatibility (EMC Directive) •... -
Page 14: Type Plate
AM 222 S-DIAS ANALOG MIXED MODULE Type Plate HW: Hardware version SW: Software version Page 12 22.11.2023... -
Page 15: Technical Data
S-DIAS ANALOG MIXED MODULE AM 222 Technical Data Analog Input Specifications Number of channels Measurement range 0-20 mA 4-20 mA Measurement value 0-20.000 4.000-20.000 An open or shorted input returns -2147483632 in the hardware class. Note: starting from FW V1.10 the lower limit can be set to a value of 0- 4000µA valid for all input channels. -
Page 16: Analog Output Specifications
AM 222 S-DIAS ANALOG MIXED MODULE Analog Output Specifications Number of channels Output range 0-20 mA 4-20 mA Output value 0-20.000 4.000-20.000 Current resolution 12-bit (ca. 5 µA/LSB) Refresh time for all channels 1 ms Settling time 50 µs + load * capacitive load (63 % of the end value) 100 µs + 2*load * capacitive load (86 % of the end value) -
Page 17: Electrical Requirements
S-DIAS ANALOG MIXED MODULE AM 222 Electrical Requirements External +24 V supply +18-30 V DC Current consumption of the +24 V typically 27 mA at +18 V maximum 31 mA at +18 V supply without load on the analog typically 24 mA at +24 V... -
Page 18: Miscellaneous
AM 222 S-DIAS ANALOG MIXED MODULE Miscellaneous Article number 20-017-222 Standard UL 508 (E247993) Approbations UL, cUL, CE Environmental Conditions -20 … +85 °C Storage temperature 0 … +60 °C Environmental temperature Humidity 0-95 %, non-condensing Operating conditions Pollution degree 2... -
Page 19: Mechanical Dimensions
S-DIAS ANALOG MIXED MODULE AM 222 Mechanical Dimensions 22.11.2023 Page 17... -
Page 20: Connector Layout
AM 222 S-DIAS ANALOG MIXED MODULE Connector Layout INFORMATION The connections of the +24 V supply (X3: pin 1 and pin 2) or the GND supply (X3: pin 3 and pin 4) are internally bridged. To supply the mod- ule, only one connection to a +24 V pin (pin 1 or pin 2) and a GND pin (pin 3 or pin 4) is required. -
Page 21: Status Leds
S-DIAS ANALOG MIXED MODULE AM 222 Status LEDs Module Status green module active no supply available BLINKING (5 Hz) no communication User yellow can be set from the application (e.g. the module LED can be set to blinking through the... -
Page 22: Label Field
AM 222 S-DIAS ANALOG MIXED MODULE Label Field Manufacturer Weidmüller Type MF 10/5 CABUR MC NE WS Weidmüller article number 1854510000 Compatible printer Weidmüller Type Printjet Advanced 230V Weidmüller article number 1324380000 Page 20 22.11.2023... -
Page 23: Wiring
S-DIAS ANALOG MIXED MODULE AM 222 Wiring Wiring Example 22.11.2023 Page 21... -
Page 24: Note
AM 222 S-DIAS ANALOG MIXED MODULE Note The signals recorded by the analog modules are very small, as compared to the digital signals. To ensure error-free operation, a careful wiring method must be followed: • The DIN rail must have an adequate mass connection. -
Page 25: Signal Source Connection
S-DIAS ANALOG MIXED MODULE AM 222 Signal Source connection Load Connection 22.11.2023 Page 23... -
Page 26: Assembly/Installation
AM 222 S-DIAS ANALOG MIXED MODULE Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter Contents of Delivery. INFORMATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system. -
Page 27: Mounting
S-DIAS ANALOG MIXED MODULE AM 222 Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches. - Page 28 AM 222 S-DIAS ANALOG MIXED MODULE Recommended minimum distances of the S-DIAS modules to the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) Page 26 22.11.2023...
-
Page 29: Addressing
S-DIAS ANALOG MIXED MODULE AM 222 10 Addressing 10.1 Address Mapping Overview Address Size Description (hex) (bytes) Cyclic Data for Firmware (mem – address range) 0000 Analog output value 1: 0-20 mA (0-20000) 0002 Analog output value 2: 0-20 mA (0-20000) Cyclic Data for the HW Class (mem –... - Page 30 AM 222 S-DIAS ANALOG MIXED MODULE Standard mode (info register bit 0 = 0) 0106 AI configuration Bit 0-1 AI1 Cfg 0: 0-20mA 1: 4-20mA (starting from FW V1.10 the lower limit corresponds to the value in 0x112 in µA)
-
Page 31: Supported Cycle Times
S-DIAS ANALOG MIXED MODULE AM 222 11 Supported Cycle Times 11.1 Cycle Times below 1 ms (in µs) V1.10 11.2 Cycle Times equal to or above 1 ms (in ms) V1.10 V1.10 22.11.2023 Page 29... -
Page 32: Transport/Storage
AM 222 S-DIAS ANALOG MIXED MODULE 12 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and stor- age, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport. -
Page 33: Maintenance
S-DIAS ANALOG MIXED MODULE AM 222 14 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instruc- tions from chapter 2 Basic Safety Directives. 14.1 Service This product was constructed for low-maintenance operation. 14.2 Repair INFORMATION In the event of a defect/repair, send the device with a detailed error description to the address listed at the beginning of this document. -
Page 34: Hardware Class Am222
Hardware Class AM222 for the S-DIAS AM222 Analog Module This hardware class is used to control the AM 222 hardware module. The module has 2 analog inputs, 0-20 mA or 4-20 mA and 2 analog outputs 0-20 mA or 4-20 mA. More infor- mation on the hardware can be found in the module documentation. -
Page 35: General
S-DIAS ANALOG MIXED MODULE AM 222 16.1 General Class State State This server shows the actual status of the hardware class. Device ID State The device ID of the hardware module is shown in this server. FPGA Version State FPGA version of the module in 16#XY (e.g. 16#10 = version 1.0). -
Page 36: Analog Inputs And Outputs
AM 222 S-DIAS ANALOG MIXED MODULE 16.2 Analog Inputs and Outputs AI[1-2] Config Property Analog input [1-2] settings: AI[1-2] used as analog input (range: 0-20 mA) AI[1-2] used as analog input (range: 4-20 mA) AI[1-2] disabled as an initialization value... -
Page 37: Cable Break Detection And Measurement Values
S-DIAS ANALOG MIXED MODULE AM 222 16.3 Cable Break Detection and Measurement Values Range Detec- State Detection lower measurement limit (cable break detection) tion Bit 0 cable break at input AI1 Bit 1 cable break at input AI2 0-20 mA mode: The limit for the lower measurement range is <... - Page 38 AM 222 S-DIAS ANALOG MIXED MODULE Documentation Changes Change date Affected Chapter Note page(s) 26.03.2015 2.2 Applicable Connectors Added Connections 09.07.2015 1.5 Electrical Requirements Changed electrical requirements 20.01 2016 1.6 Miscellaneous Standard changed 25.01.2016 1.5 Electrical Requirements Graphics added 09.03.2016 1.1 Analog Input Specifica-...
- Page 39 S-DIAS ANALOG MIXED MODULE AM 222 22.11.2023 5.1 Analog Input Specifica- Maximum input current allowed added tions 22.11.2023 Page 37...
