12P Hex/12P Hex Pearl
Unpacking: Thank you for purchasing the 12P Hex/12P Hex Pearl by
ADJ Products, LLC. Every 12P Hex/12P Hex Pearl has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
fixture for any damage and be sure all accessories necessary to oper-
ate the unit has arrived intact. In the case damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Do not return this unit to your dealer
without first contacting customer support.
Introduction: The 12P Hex/12P Hex Pearl is a DMX intelligent, LED
par fixture. This fixture can be used in a stand alone mode or con-
nected in a Master/Slave configuration. This par has five operating
modes: Sound Active mode, Program mode, RGBWA + UV dimmer
mode, Static Color mode, and DMX control mode. The 5P has 4 DMX
channel modes; 6, 7, 8, & 12.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
ADJ Products, LLC - www.adj.com - 12P Hex/12P Hex Pearl User Manual Page 2
Introduction 12P Hex/12P Hex Pearl
• Multi-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• 5 Dimmer Curves
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 4 DMX Modes: 6 Channel Mode, 7 Channel Mode, 8 Channel
Mode, & 12 Channel Mode.
• Dotz Par RF compatiable (Not Included)
• Power Cord Daisy Chain (See page 11)
12P Hex/12P Hex Pearl
The 12P Hex/12P Hex Pearl carries a 2 year limited warranty. Please
fill out the enclosed warranty card to validate your purchase. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.) number. The
R.A. number must be clearly written on the outside of the return pack-
age. A brief description of the problem as well as the R.A. number
must also be written down on a piece of paper included in the ship-
ping carton. If the unit is under warranty, you must provide a copy of
your proof of purchase invoice. You may obtain a R.A. number by con-
tacting our customer support team on our customer support number.
All packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper.
12P Hex/12P Hex Pearl
The unit should be mounted using a mounting clamp (not provided),
affixing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is firmly fixed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit's weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the fixture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people's grasp.
ADJ Products, LLC - www.adj.com - 12P Hex/12P Hex Pearl User Manual Page 3
Features

Warranty Registration

Installation
