StarTech.com P2DD46A22-KVM-SWITCH Quick Start Manual page 2

HK_LCode + V
HK_LCode + C
HK_LCode + F9~F10
HK_LCode + Up Arrow
Key
or
HK_LCode + Down
Arrow Key
HK_LCode + B
HK_LCode + H + 0~9
HK_LCode + R
Serial Commands
The following Serial Commands are intended to be used with the KVM Serial Connection Port, allowing control over the function
of the KVM Switch. The Host Device that controls the KVM Switch requires the following parameters:
Baudrate: 115200bps
Parity: None
Data Bits: 8
Stop Bits: 1
Serial Command
sw 1~2
audio 1~2
com 1~2
bind 2~3
unbind 2~3
hotkey 0~4
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
• Disable the binding between PC (USB/Video) and Serial
when switching between PC 1 or PC 2.
• Allows switching of PC Ports USB and Video functions,
while Serial does not switch.
• Enable the binding of PC (USB/Video) and Serial
switching. (Enabled by default)
• Serial will switch with the PC Ports USB and Video
functions.
• Serial Unbound: Selects only the Serial source between
PC 1 or PC 2, does not switch USB and Video.
• Serial Bound: Select PC 1 or PC 2 and their respective
USB/Video/Serial Ports.
• Select the next/previous PC Port.
• If Audio is unbound, the audio will not switch
• If Serial is unbound, the serial ports will not switch
• Enable or Disable the Beep that indicates HotKey Com-
mand Inputs. (Enabled by default)
• Start Autoscan and set time delay.
• "x" = 1 - 10sec, 2 - 20sec, 3 - 30sec, 4 - 40sec, 5
- 50sec, 6 - 60sec, 7 - 70sec, 8 - 80sec, 9 - 90sec, 0 -
100sec
• Press any key to stop Autoscan
• Reset all Hotkey Commands to factory defaults
Function
• Switch the active PC Port
• Switch the active Audio Port
• Switch the active RS232 Port
• Bind selected peripheral with the active PC Port
• 2 = Audio
• 3 = RS232
• Unbind selected peripheral from the active PC Port
• 2 = Audio
• 3 = RS232
• Change the hotkey prefix
• 0 = ScrLk
• 1 = CapsLk
• 2 = NumLk
• 3 = Left Ctrl
• 4 = Right Ctrl
