StarTech.com P4AD122-KVM-SWITCH Quick Start Manual

4-Port 4K 60Hz DisplayPort KVM Switch - USB 5Gbps Hub
Product Diagram
P4AD122-KVM-SWITCH
Front View
3 4
Rear View
6
3
8 9 10
Port
Port Selection LED
1
Indicators
2
Power LED
3 Console USB HID Port
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
1 2
5
1
7
11 10 11 10 11 10
Function
Solid Green: PC 1 - 4 connected (powered on)
•
Solid Red: Selected PC Port
•
Solid Green: KVM Switch is powered on
•
Connect a USB Human Interface Devices (HIDs)
•
(e.g. Keyboard, Mouse, Trackpad, Number
Keypad, or Drawing Tablet)
Front (x1) and Rear (x3)
•
4
Console USB Hub Ports
5 Port Selection Buttons
Console DisplayPort
6
Output Port
7
PC DisplayPort Input Ports
8 Power Input Port
9
Console Audio Port
10 PC USB Host Connections
11 PC Audio Ports
Product Information
For the latest manuals, product information, technical specifications, and declarations
of conformance, please visit:
Requirements
Source PCs
• Computers x 4
DisplayPort and USB 5Gbps enabled
•
• DisplayPort Cables x 4
• SuperSpeed USB 5Gbps Cable x 4
• (Optional) 3.5mm Audio Cables (Male to Male) x 4
Console
11 4
• DisplayPort Display x 1
• DisplayPort Cable x 1
• USB Mouse x 1
• USB Keyboard x 1
• (Optional) Audio Device (e.g. Headphones) x 1
• (Optional) USB HID Devices x 1
• (Optional) SuperSpeed USB 5Gbps Peripheral Devices x 1
Package Contents
• KVM Switch x 1
• Universal Power Adapter (NA/EU/UK/ANZ) x 1
• Set of Rubber Feet x 1
• Quick-Start Guide x 1
Quick-Start Guide
Connect SuperSpeed USB 5Gbps Peripheral
•
Devices
Press and release to select PC 1 - 4
•
Connect to a DisplayPort Input on a Display
•
Connect to a DisplayPort Output on PCs 1 - 4
•
Connect the included Universal Power Adapter
•
Connect an Audio Device (e.g. Speakers or
•
Headset)
Connect to a SuperSpeed USB 5Gbps Port on
•
PCs 1 - 4
Connect to an Audio Port (for Speaker or
•
Microphone) on PCs 1 - 4
www.StarTech.com/P4AD122-KVM-SWITCH
Manual Revision: April 17, 2024
