RGBlink mini-mx Quick Start Manual page 8

Port
HDMI 1~4 Inputs
❻
❼ Locking Hole
❽ USB-C Power Port
Power Switch
❾
Headphone Output
❿
⓫ 6.35mm TRS Jack
⓬ Line-in
MIC in 2
⓭
MIC in 1
⓮
+48V DIP Switch
⓯
Warning：
Except condenser microphones that require phantom power, please Turn Off phantom
power switch when connecting other devices.
www.rgblink.com
Program or HDMI 1~4.
4K resolution and downward compatible with all
resolution.
Use with T-lock to fix the device.
PD protocol, 12V 3A.
Rocker switch to power on or off device.
3.5mm mini-jack for listening each analog input and
HDMI input.
Balanced XLR audio output.
Balanced 6.35mm XLR jack to connect to mobile phone,
computer or audio console.
XLR/TRS Neutrik MIC in port.
XLR/TRS Neutrik MIC in port with 48V Phantom Power
supported.
48V Phantom Power supported.

Defaults to OFF.

