Using the Mute Buttons
The mute buttons under each physical faders are
represented in two types: tap the right one to
mute all channel on Program output port and
Preview output port. You can also access a mute
button by entering the audio setting interface and
then tapping the mute icon.
When a channel is muted, the button on the front
panel and icon on the audio setting will be
illuminated red.
www.rgblink.com
Using the Physical and Virtual Faders
mini-mx features two physical faders and two virtual
faders.
Same operations as described before: use the sliders
to adjust the level for the output channel and the
virtual fader position will be mirrored in real-time on
audio setting interface.
The left one is for simultaneous audio management
of four HDMI signals on Program output port and
Preview output port.
Tap the button on
corresponding channel on Program output or
Preview output.
the left can mute
