Front Panel - RGBlink mini-mx Quick Start Manual

❶
❷
❸
❹
❺
Audio Volume Controls
❶
❷ Toggle
Layer Selection Buttons
❸
www.rgblink.com

Front Panel

⓭
Embedded audio volume adjustment for HDMI 1~4
inputs.
Size adjustment for Layer A and Layer B.

Zoom in/out for PTZ control.

Indicate Background, Layer A, Layer B, Logo, Overlay

and Text.
No button light for closed layer.

Single Click: Single click to add layer to PVW window.

Button illuminated blue indicates enabled and
selected state, which allows you to use Button 1~8 to
select correspond layer signal or source. Button
illuminated green indicates enabled but un-selected
state. Click the button illuminated blue again to close
enabled layer.
Long Press: Long press Button Background to enter

Media Management Interface. Long press Button
❼ ❽
❻
⓬
⓫
❿
❾
2
