RGBlink mini-mx Quick Start Manual page 5

❹ Channel Fader
Listen and Mute
❺
Buttons
❻ T-Bar
Page Up
❼
Page Down
❽
Button 1~8
❾
❿ 5-Direction Joystick
⓫ MENU Button
www.rgblink.com
Layer A/Layer
Interface.
Control audio volume level for MIC1 、MIC2 、Line-in 、
Bluetooth、PREVIEW、PROGRAM.
Listen Button: Audio management for monitoring

port. Button illuminated green allows users to monitor
the audio from a channel ; no button light indicates
monitoring function is OFF.
Mute Button: Mute that channel at Program port.

When a channel is muted, the button will be
illuminated red; no button light indicates the channel
is ON at Program port.
Preview and Program views can be transitioned by
pushing T-bar.
Press to return to previous operation interface or page.
Press to enter the next page.
Button 1~8 correspond to 1~8 items in MENU.

Button 1~4 : Used as HDMI input switch button if

Layer A or B is selected or source selection button
when selecting other layers.
Button 5~8 : Used as source selection button when

selecting layers except Layer A and Layer B.
No button light for no input. When there is an input

signal, button will be illuminated white. When the
signal is in Preview, the button will be illuminated
green; when the signal is being edited, the button will
be illuminated blue.
Move Up/Down/Left/Right: Position adjustment for

layer; set pan, tilt and zoom for PTZ camera.
Press: Press joystick to enter full screen if Layer A or B

is selected and press it once more to to restore; push
joystick to enter PTZ Control Interface when under
PTZ control.
Single Click: In Main Interface, click to enter MENU; in

MENU, click to enter Main Interface; in interface
except MENU and Main Interface, click to return back
to previous page.
Long Press: In interface except Main Interface, long

press to enter Main Interface; in Main Interface, long
B/Logo/Overlay to enter Layout
3
