FORM QCC3-NM1
ISSUE DATE: 12/19/2023
MOUNT
TYPE
W
CP1 3
CP2 3
MODEL NUMBER
CP-1D-510
CP-1D-900
CP-1D-1200
CP-1D-1360
CP-1D-1785N
MODEL NUMBER
C2P-1D-1350
C2P-1D-1350
C2P-1D-1800
C2P-1D-2400
C2P-1D-2400
C2P-1D-2720
C2P-1D-3570N
Quantech

Isolator information

1 in. deflection spring isolator cross-reference
CP
Ø1/2"
T"
D"
W"
DIMENSION DATA (INCHES)
D L
5/8 7-3/4
5/8 10-1/2
RATED CAPACITY (FOR UNITS WITH ALL LOAD POINTS
COLOR CODE
BLACK
DARK GREEN
GRAy
WHITE
GRAy/RED
COLOR CODE
DARK PURPLE
DARK PURPLE
DARK GREEN
GRAy
GRAy
WHITE
GRAy/RED
5/8"
H"
C"
B"
L"
LD13759A
B C
6-1/2 4-3/4
9-1/4 7-3/4
LESS THAN 1785 LB (810 KG)
(LB)
Up thru 434
435 thru 765
766 thru 1020
1021 thru 1156
1157 thru 1785
RATED CAPACITY (FOR UNITS WITH ANY LOAD POINT
ABOVE 1518 LB (689 KG)
(LB)
Up thru 1148
Up thru 1148
1149 thru 1530
1531 thru 2040
1531 thru 2040
2041 thru 2312
2313 thru 3570
SECTION 5: TECHNICAL DATA
T H
1/2 5-5/8
9/16 6
(KG)
Up thru 197
198 thru 347
348 thru 463
464 thru 524
525 thru 810
(KG)
Up to 521
Up to 521
522 - 694
695 - 925
695 - 925
926 - 1049
1050 - 1619
97
5 5
