FORM QCC3-NM1
ISSUE DATE: 12/19/2023
TABLE 61 - PRESSURE CONVERSION CHART -
GAUGE OR DIFFERENTIAL
PSI = BAR
20 1.38
30 2.07
40 2.76
50 3.45
60 4.14
70 4.83
80 5.52
90 6.21
100 6.9
110 7.59
120 8.28
130 8.97
140 9.66
150 10.34
160 11.03
170 11.72
180 12.41
190 13.1
200 13.79
210 14.48
220 15.17
230 15.86
240 16.55
250 17.24
260 17.93
270 18.62
280 19.31
290 20
300 20.69
310 21.38
320 22.07
330 22.76
340 23.45
350 24.14
360 24.83
370 25.52
380 26.21
390 26.9
400 27.59
Quantech
BAR = PSI
1.5 21.8
2 29
2.5 36.3
3 43.5
3.5 50.8
4 58
4.5 65.3
5 72.5
5.5 79.8
6 87
6.5 94.3
7 101.5
7.5 108.8
8 116
8.5 123.3
9 130.5
9.5 137.8
10 145
10.5 152.3
11 159.5
11.5 166.8
12 174
12.5 181.3
13 188.5
13.5 195.8
14 203
14.5 210.3
15 217.5
15.5 224.8
16 232
16.5 239.3
17 246.5
17.5 253.8
18 261
18.5 268.3
19 275.5
19.5 282.8
20 290
20.5 297.3
TABLE 62 - R-410A PRESSURE-TEMPERATURE
CHART
PSIG TEMP ˚F
0 -60
2 -58
4 -54
6 -50
8 -46
10 -42
12 -39
14 -36
16 -33
18 -30
20 -28
22 -26
24 -24
26 -20
28 -18
30 -16
32 -14
34 -12
36 -10
38 -8
40 -6
42 -4
44 -3
46 -2
48 0
50 1
52 3
54 4
56 6
58 7
60 8
62 10
64 11
66 13
68 14
70 15
72 16
74 17
76 19
SECTION 10: MAINTENANCE
PSIG TEMP ˚F
78 20
80 21
85 24
90 26
95 29
100 32
105 34
110 36
115 39
120 41
125 43
130 45
135 47
140 49
145 51
150 53
160 57
170 60
180 64
190 67
200 70
210 73
220 76
225 78
235 80
245 83
255 85
265 88
275 90
285 92
295 95
305 97
325 101
355 108
375 112
405 118
500 134
600 149
700 159
175
