SECTION 2: PRODUCT DESCRIPTION
TABLE 1: PRODUCT IDENTIFICATION NUMBER (PIN), CONT'D
FEATURE FEATURE DESCRIPTION
VOLTS Voltage (PIN 11 and 12)
STARTER Starter (PIN 13)
DESIGN Design Series (PIN 14)
DEV Development Level (PIN 15)
POWER
Power Field (PIN 16 and 17)
TRANS Cntrl Transformer (PIN 18)
PFC Power Factor Capacitor (19)
AMB Ambient Kits (PIN 20)
BAS Bas Reset/Offset (PIN 21)
LCD Language (PIN 22)
RDOUT Readout Kits (PIN 23)
SAFETy Safety Codes (PIN 24)
SENSOR Suction Temp (PIN 25)
PUMP Motor Current Module (PIN 26)
REMOTE Remote Panel (PIN 27)
SEQ Sequence Kit (PIN 28)
TEMP Leaving Water Temp(29,30)
CHICAGO Chicago Code Kit (PIN 31)
24
OPTION
17 200/3/60
28 230/3/60
40 380/3/60
46 460/3/60
50 380-415/3/50
58 575/3/60
X Across the Line starter
A Design Series A (MicroChannel)
B Design Series B (Tube and Fin)
A Development Level A
SX SP Supply TB
SD SP NF Disconnect Switch
BX SP Circuit Breaker w/ Lockable Handle
DB SP NF Disc Switch w/Ind Sys CB
X No Control Transformer Required
T Control Transformer Required
Q Special Control Transformer Required
X No Power Capacitor required
C Power Capacitor required
Q Special Power Capacitor required
H High Ambient Kit (Standard) (factory)
High Ambient Kit required (field)Both Low/High Ambient Kit
AG
required (factory)
Q Special Ambient Kit required
T BAS/EMS Reset/Offset (standard)required
Q Special BAS Reset/Offset required
X English
RX Discharge Pressure Readout (standard)X
Q Special Quote
L N American Safety Code (cUL/cETL)
XT Suction Temp Readout (standard)X
Q Special Quote
C Motor Current Module (standard)
X X
Q Special Quote
X X
Q Special Quote
NUM Leaving Water Temp = {TEMP/NUM} degrees
QQ Special LWT requirements
X No Chicago Code Kit required
B Both Chicago Code and Serv Isolation
C Chicago Code Kit required
S Service Isolation Valves
Q Special Chicago Code Kit required
ISSUE DATE: 12/19/2023
OPTION DESCRIPTION
FORM QCC3-NM1
