FORM QCC3-NM1
ISSUE DATE: 12/19/2023
1
5

FIGURE 3 - POWER PANEL COMPONENTS

Quantech
2
3
6
Item
Description
1
Fan contactor
2
Fan fuses
3
Fan contactor
4
Disconnect switch (optional)
5
XTBF1
6
Compressor contactors
7
Compressor overloads
SECTION 2: PRODUCT DESCRIPTION
4
7
2
LD13248
21
