SECTION 10: MAINTENANCE
The table below shows the minimum, maximum, and
default values.

TABLE 53 - MINIMUM, MAXIMUM AND DEFAULT VALUES

DESCRIPTION
DE MODIFIER ADDRESS
DE MODIFIER OFFSET
P1 BAUD RATE
P2 BAUD RATE
P1, P2 MANUAL Mac
ADDRESS
P1, P2 PARITy
P1 PROTOCOL
P2 PROTOCOL
P1, P2 STOP BITS
RESET REAL TIME ERROR
The table below shows the real time error numbers and
a description of each.

TABLE 54 - REAL TIME ERROR NUMBERS

ERROR
NUMBER (##)
0 All Ok
1 Datum Type Ok Test Failed
2 English Text Too Long
3 Floating Point Exception
4 Get Packet Failed
5 Get Type Failed
6 Invalid Unit Conversion
7 Invalid Hardware Selection
8 Real Time Fault
9 Spanish Text Too Long
10 Thread Exited
11 Thread Failed
12 Thread Stalled
13 Io Board Reset
14 Bram Invalid
15 Bacnet Setup Failed
170
MINIMUM
-1
-1
1200
1200, 4800, 9600, 19200, 38400, 76800, AUTO SELECTABLE
1200
1200, 4800, 9600, 19200, 38400, 57600 SELECTABLE
-1
NONE
NONE, EVEN, ODD, IGNORE SELECTABLE
BACNET
TERMINAL
TERMINAL, MODBUS IO, MODBUS SERVER, API, MODBUS CLIENT SELECTABLE
1
NO
DESCRIPTION
MAXIMUM
41943
99
76800
57600
127
IGNORE
API
BACNET, API SELECTABLE
MODBUS CLIENT
2
yES
Unit data that can be read and modified using specific
Modbus Register Addresses; and the data associated
with the addresses, is outlined in the following descrip-
tion:
FORM QCC3-NM1
ISSUE DATE: 12/19/2023
DEFAULT
-1
-1
4800
1200
-1
NONE
BACNET
API
1
NO
