INSTALLATION INSTRUCTIONS
EARTH-FRIENDLY R-410A REFRIGERANT
!
RECOGNIZE THIS SYMBOL AS AN INDICATION OF IMPORTANT SAFETY INFORMATION!
WARNING
!
THESE INSTRUCTIONS ARE INTENDED AS AN AID TO
QUALIFIED, LICENSED SERVICE PERSONNEL FOR PROPER
INSTALLATION, ADJUSTMENT AND OPERATION OF THIS UNIT.
READ THESE INSTRUCTIONS THOROUGHLY
ATTEMPTING INSTALLATION OR OPERATION. FAILURE TO FOL-
LOW THESE INSTRUCTIONS MAY RESULT IN IMPROPER
INSTALLATION, ADJUSTMENT, SERVICE OR MAINTENANCE
POSSIBLY RESULTING IN FIRE, ELECTRICAL SHOCK,
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
PLEASE READ CAREFULLY AND KEEP IN A SAFE PLACE FOR FUTURE REFERENCE BY A SERVICEMAN
13 & 14.5 SEER SERIES
CONDENSING UNITS
1
1
⁄
- 5 TONS FEATURING
2
NOTE: Appearance of unit may vary.
DO NOT DESTROY THIS MANUAL
(13 & 14.5 SEER
MODELS IN CERTAIN
MATCHED SYSTEMS)
BEFORE
R-410
r e f r i g e r a n t
92-21354-78-01
SUPERSEDES 92-21354-78-00
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls 13 SEER SERIES
Summary of Contents for Johnson Controls 13 SEER SERIES
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS 13 & 14.5 SEER SERIES CONDENSING UNITS ⁄ - 5 TONS FEATURING EARTH-FRIENDLY R-410A REFRIGERANT R-410 r e f r i g e r a n t NOTE: Appearance of unit may vary. RECOGNIZE THIS SYMBOL AS AN INDICATION OF IMPORTANT SAFETY INFORMATION! WARNING THESE INSTRUCTIONS ARE INTENDED AS AN AID TO QUALIFIED, LICENSED SERVICE PERSONNEL FOR PROPER... -
