Theory of
Operation—
DC
501
THEORY
OF OPERATION
Introduction
This section
of the
manual contains an
electrical
description
of
the circuits in
the
DC
501 100
MHz
Counter.
A
block
diagram
is
shown
in
Fig. 2-1,
and
complete schematics
are given
on pullout pages
in
the
Servicing
Information section.
BLOCK DIAGRAM DESCRIPTION
Signals to
be counted are
applied
via
the
EXT
INPUT
connector or via pin
16A
at
the rear interface,
attenuators,
and
a
coupling capacitor to the
signal-shaping circuit.
This
circuit
conditions the input signal
and produces an output
suitable to
drive
the
first
decade counter.
The
time-base circuit
generates the
signals
which
deter-
mine
when
the counter
is
allowed to
count
(GATE), when
the
readout display
is
updated
(LA TCH),
a
nd
when
th e
counter
is
cleared or reset
(CLEAR,
CLEAR,
or
RESET).
The
generation
and the
time
relationship
between these
signals
are
determined
by
the front-panel
MEASUREMENT
INTERVAL, DISPLAY TIME,
Manual Gate
START/STOP,
and
RESET
controls.
The decade counter units receive
the
shaped input
signal
when
the gate
is
"open". Each
DCU
corresponds to
one
of
the display
LED's. Immediately
upon closure of the
GATE,
the
LATCH
locks the
sample taken into the storage register.
If
the
sample
taken exceeds the seven
available
display
digits,
the excessive
count
spills
over and
is
indicated
by the
OVERFLOW LED
on the front panel.
Before
a
new
sample
of the input
signal
is
taken, the time-base circuit sends
in a
CLEAR
pulse to
reset
all
the
DCU's
to zero.
The
multiplexing circuit
scans the latches of the storage
register at a
2-kilohertz
rate,
enabling
each
latch
and
its
corresponding display
LED
sequentially
on
a
time-shared
basis.
The
BCD
output of the storage register
is
decoded
and
the correct
combination of
LED
segments
is
lightfed
to display
any
digit
between 0 and
9.
Also, the
decoder and
display-multiplexing circuit
provides
leading-zero suppres-
sion
if
the display
is
within the
display-register capacity.
Decimal point location
is
a
function of the
MEASURE-
MENT INTERVAL
switch.
CIRCUIT DESCRIPTION
Input Circuit
Signals to
be counted
are
applied via
front-panel
INPUT
connector J100, or
via
the internal
input at
pin
16A
at
the
rear
interface,
to
the attenuators.
The
attenuators are
frequency-compensated
voltage dividers consisting of
resis-
tors
R102-R107
and capacitors
C102-C107.
Switches
S100A
and
S100B allow front-panel
selection of
XI, X5,
X10,
or
X50
attenuation
of the
input
signal.
Cl 10 provides
AC
coupling.
FET
source follower
Q115
and
emitter follower
Q122
present
a
high
impedance
to
the input
signal.
The diodes
in
the base circuit
of E. F.
Q128
form
a series-limiter
and
clamping network,
which
reduces the input signal
to
limits
suitable for
driving
the shaping
circuits.
The clamping
diodes limit
the voltage at
the emitter of
Q128
to a
dynamic range of
about
1.2 volts.
U150B, an
OR
gate integrated circuit
with
push-pull
outputs,
is
connected
as a
Schmitt
trigger.
It
shapes the
input signal
into a
square wave.
Its
"hysteresis
window"
is
a
width of
about
200
mV. The
output changes
states
when
the
signal
voltage passes
through the upper threshold,
then
reverts to
its
original state
when
the signal
voltage passes
through the lower threshold.
For
this
reason,
an
input
signal
smaller
in
amplitude than the width of the hysteresis
window
cannot
activate
the counting
circuits.
The
quiescent
level
at
the input of
U150B
can be
adjusted to
overcome some
of the triggering difficulties
arising
from various input-signal
shapes and frequencies.
Integrated
-circuit
operational amplifier
U135 and
its
associ-
ated
discrete
components
are
connected
as a
voltage
follower.
TRIGGER LEVEL
potentiometer
R135
selects a
voltage
between ground and about
—2
volts
and
applies
it
to
pin
3
of U135. This
level
is
then
established at
pin
2,
and
hence, the input of
U150B, through the action of the
operational amplifier.
The output of
U150B
is
applied to
U150A, whose
push-pull
outputs drive
Q160
and Q162, which
are
con-
nected as a differential pair.
This
circuit
provides
a level
shift
to
TTL
level,
and further
shapes the
signal
to be
counted.
A
waveform
with
fast rising
and
falling
edges
is
produced
at
the collector
of
Q160.
CR165
limits
the
amplitude
of the
count
signal
to 5
volts,
clamping the
2-2
