2.3 Illustration for front and top views
Description of main items (shown in Figure 2-3):
1、Mounting plate for lifting ring
2、Display panel (with LED indication and LCD Display)
3、Operation keys (Up, Down, Left, Right, ESC, ENT)
4、Emergency switch button
5、Switch on DC side
6、Lock
7、Switch on AC side
Figure 2-3 Appearance sketch
Chapter 2 Overview
1
2
3
4
5
6
7
5
