Torklift C2205 Important Owner-Operator Installation Instructions

True frame mounted camper tie downs

Advertisement

Quick Links

IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS
C2205
REVISED vers7 BY JL 08/5/15
TECH SUPPORT (800) 246-8132
AFTER INSTALL, PLEASE GIVE
THIS BOOKLET TO YOUR CUSTOMER
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the C2205 and is the answer not in the manual?

Questions and answers

Summary of Contents for Torklift C2205

  • Page 1 IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS C2205 REVISED vers7 BY JL 08/5/15 TECH SUPPORT (800) 246-8132 AFTER INSTALL, PLEASE GIVE THIS BOOKLET TO YOUR CUSTOMER...
  • Page 2 Warnings Truck Bed and Camper Protection Torklift does not recommend installing your camper on top of a plastic bed liner (or other compressible material such as foam). These materials can act as a spring, causing increased vertical truck camper movement independent of the vehicle. Plastic bed liners can slide on the truck bed surface, and the truck camper can slide on top of the bed liner.
  • Page 3: Installation Diagram

    INSTALLATION DIAGRAM UPPER SUPPORT STRAP TRUCK FRAME CLAMP STRAP WELDED BOLTS FRAME MOUNTED TIEDOWN RECIEVER PLATE...
  • Page 4: Installation

    FASTENERS BEFORE BREAKING THEM LOOSE. INSTALLATION There is enough room to install the C2205 Tie Down between the frame and the gas tank, but if the tank is closer than normal, you may choose to loosen the straps for the tank and move it away from the frame while performing the installation.
  • Page 5 NOTE: THE LONG TAPERED END OF THE CLAMP STRAP SHOULD POINT TOWARD THE FRONT OF THE TRUCK AND SHOULD FACE DOWN. NOTE: This is a no-drill application and the threaded bolts will not go through any holes in the frame! If you feel that you need to drill the frame, please call our tech support line as you may be installing wrong or you may have the wrong tie down for your application.
  • Page 6: Illustrated Diagrams

    You should have at least 1” clearance between the insert and the lip of the bed or after market accessory. DIAGRAMS ILLUSTRATED PHOTO A PHOTO B...
  • Page 7 PHOTO C (PASSENGER SIDE)
  • Page 8 PHOTO D (DRIVER SIDE)
  • Page 9 PHOTO E E-BRAKE CABLE RUNS BELOW THE CAMPER TIE DOWN...
  • Page 10 TORKLIFT’S BOLT FISHING GUIDE Your guide to understanding the installation of our frame mounted tie downs. Note: The hardware may vary as to what is being fished along with the -Coiled End of Bolt Fisher- bolt. In this instance a 1” X 2” plate washer is being fished along with the hex bolt.
  • Page 11 On one end of each of your tie down inserts is a triangular plate referred to by Torklift as a bullet plate. Your tie down inserts should be installed with the shorter side of the bullet plate facing away from each other, i.e.. The shorter side of the front insert should point to the front of the truck and the shorter side of the rear insert should point towards the rear of the truck.
  • Page 12 Due to the extreme, harsh, undercar environment that your Torklift products live in, (consistently sprayed with corrosive road chemicals such as salt, and road debris), Torklift does not warranty the power coated finish.
  • Page 13 Warranty Information 322 Railroad Ave North, Kent, WA 98032 Torklift will require proof of purchase to register, with pictures of any defective product before issuing a replacement. Torklift will not register any product without proof of purchase, which can be faxed, scanned, emailed, or mailed to the information provided below.
  • Page 14 Thank you for making TorkLift your choice for truck, camper packages and accessories for your vehicle. By choosing TorkLift products, you have chosen a company that has been serving the RV industry for nearly 40 years and whose name has become synonymous with strength, quality and advanced design and installation.
  • Page 15 They are designed for each make and model to fit tight to the frame so as not to compromise ground clearance. TorkLift tie downs are not universal ‘one size fits all’ therefore all the problems with correct fit for each particular application have been eliminated.
  • Page 16 OFFICIAL WARRANTY REGISTRATION CARD PLEASE FILL OUT THIS FORM COMPLETELY AND RETURN TO TORKLIFT WITHIN 30 DAYS OF PURCHASE ACCOMPANIED BY A COPY OF YOUR ORIGINAL RECEIPT TODAY’S DATE: _________________________ 1. PART(S) PURCHASED PART#: ___________________ PART#: _______________________ PART#: ___________________ PART#: _______________________ 2.
