IMPORTANT   O WNER-­‐OPERATOR   I NSTALLATION
INSTRUCTIONS
A7706R / A7708R - A7711R / A7712R
A7706RS / A7708RS - A7711RS / A7712RS
Warning!!
This
b attery   b
ox   i s   m ade   o f   a luminum   a nd   i s
Conductive!   D o   n ot   a llow   t he   b attery   t erminals   t o   t ouch   t he   a luminum
Battery   b ox.   B e   c areful   n ot   t o   t ouch   t he   b attery   b ox   w ith   a   w rench   w hile
tightening   t he   b attery   t erminals,   a s   t his   c ould   c ause   a   s hort!

Advertisement

loading
Need help?

Need help?

Do you have a question about the A7708R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Torklift A7708R

  • Page 1 IMPORTANT   O WNER-­‐OPERATOR   I NSTALLATION   INSTRUCTIONS   A7706R / A7708R - A7711R / A7712R A7706RS / A7708RS - A7711RS / A7712RS Warning!! This   b attery   b ox   i s   m ade   o f   a luminum   a nd   i s  ...
  • Page 2 Warning!! Improper installation of Solar Equipped Power Armors may result in battery over-charging! Solar Installation Option 1: If   y ou   p lan   t o   u se   t wo   b atteries   w ith   a   single  ...
  • Page 3   PN:   A 7716-­‐         A 7706R(S)/A7708R(S)   B attery   M ats   PN:   A 7718-­‐         A 7711R(S)/A7712R(S)   B attery   M ats  ...
  • Page 4 Inventory List A7706R / A7708R - A7711R / A7712R A7706RS / A7708RS - A7711RS / A7712RS Item: Quantity: Power Armor Battery Box Power Armor Lid Angle Extension Battery Mat 26” (A7706R / A7708R - A7706RS / A7708RS) Battery Mat 23.5”...
  • Page 5: Power Armor Battery Box

    Step 1: Remove the Power Armor Lid by sliding the lid away from the side with the lock, then lifting the front edge and unhooking the lid from the tabs on the rear of the box. The Power Armor Battery Box has four slots cut into the bottom of the box.
  • Page 6: Angle Extension

    Step 3: The 2” hole in the front/back panel of the Power Armor Battery Box is used to allow the battery cables to enter the battery box. It can be mounted to either the front or rear of the trailer as long as there is sufficient room to open and remove the Power Armor Lid.
  • Page 7 Step 3: Option 1 Place the Power Armor Battery Box on top of the trailer A-frame. Mark each corner of the box where it will screw down into the trailer A-frame, and drill a 3/16” pilot hole. Use the 1/4" x 1” Self-Drilling Screws and 1/4"...
  • Page 8: X 1" Ss Hex Bolt

    Step 3: Option 2 Measure the mounting width required for the rear of the Power Armor Battery Box. Insert one 1/4"-20 x 1” SS Hex Bolt with one 1/4" SS USS Washer into two of the “Long Side Holes” on each side of the battery box. (see figure 0.1) Secure the Angle Extension Brackets to the box with one 1/4"...
  • Page 9 Side View- Figure 3.2 Drill a 3/16” pilot hole and use the 1/4" x 1” Self-Drill Screws to secure the outside of each Angle Extension Bracket to the A-frame of the trailer. To keep the Power Armor Battery Box level, use two 1/4" SS USS Flat Washers as a shim under each of the front corners of the Power Armor Battery Box.
  • Page 10: X 1" Self-Drilling Screw

    Step 3: Option 3 Place the Power Armor Battery Box between the factory battery support rails. Drill a 3/16” Pilot hole in each corner of the Power Armor Battery Box and through the battery support rails. The existing holes in the battery box can be used if they are placed appropriately for your application.
  • Page 11: X 2" Hex Bolt

    Step 3: Option 4 Begin by drilling two 1/4” holes in each of the battery support straps. For A7706/A7708 Battery Boxes, the holes should be 25-1/4” apart. For A7711/A7712 Battery Boxes, the holes should be 22-3/4” apart. (see dimension “X” in figure 3.5) X  ...
  • Page 12: Ss Uss Flat Washer

    Figure 3.6 Insert one 1/4"-20x 1” SS Hex Bolt with one 1/4" SS USS Flat Washer into all four “Short Side Holes” on the Power Armor Battery Box. Place one 1/4"x 5/8”x 1/4” Nylon Spacer between the battery box and Angle Extension Brackets.
  • Page 13 Figure 3.7...
  • Page 14 Step 4 Reinstall the Battery Mat and Batteries. To prevent any possible contact between the battery terminals and lock, the battery terminals should be oriented towards the side of the box with the 2” hole. Tightly secure the batteries with the battery straps. Step 5 The Power Armor and Power Armor Solar battery boxes are capable of supporting multiple battery configurations.
  • Page 15 Step 5: Option 1 Insert the positive and negative battery cables into the box through the 2” hole. Connect the positive battery cable to the positive terminal on the battery. Connect the negative battery cable to the negative terminal on the battery.
  • Page 16 Solar Models Only: Attach the supplied fuse holder to the positive wire on the SAE connector. Connect the positive and negative wires from the SAE connector as shown in figure 5.1 Power   A rmor   S olar   O nly   Figure 5.1 Step 5: Option 3 Insert the positive and negative battery cables into the box through the 2”...
  • Page 17 Solar Models Only: Attach the supplied fuse holder to the positive wire on the SAE connector. Connect the positive and negative wires from the SAE connector as shown in figure 5.2 Power   A rmor   S olar   O nly   Figure 5.2 Step 6 To attach the Battery Box Lid to the Power Armor Solar Battery Box,...
  • Page 18 Figure 6.1 Step 7 Slide the Battery Box Lid away from the lock and lower it down over the front of the Power Armor Solar Battery Box. Once the Power Armor Lid is sitting flat, slide it towards the lock so the Locking tabs on the lid slide into the Power Armor Solar Battery Box as seen in figure 7.1 Locking  ...
  • Page 19 After the Battery Box Lid has slid into place, lock the key cylinder as seen in figure 7.2. Solar Models Only: Connect the SAE connector from the Solar Panel into the SAE connector on the side of the Power Armor Solar Battery Box. Figure 7.2...
  • Page 20 (on or off road). A rubber bed mat is not a requirement to maintain the lifetime warranty on a Torklift system, but a strong recommendation simply as a safety precaution to protect the truck bed, the bottom of the camper and to give the camper additional support.
  • Page 21 Torklift tie downs are not universal ‘one size fits all’ therefore all the problems with correct fit for each particular application have been  ...
