- Page 1 IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS Part #A7729 E-Series Hidden Power REVISED version 3 BY: DK 11/23/15 TECH SUPPORT (800) 246-8132...
-
Page 2: Parts Inventory
Parts Inventory A7729 Frame Plate A7729 Battery Tray Group 24-31 Battery Hook Brackets 1/4" x 1-3/8” Bail Pin 3/8”-16 x 2-1/2” Grade 5 Hex Bolt 3/8”-16 x 1-1/4” Grade 5 Hex Bolt 3/8”-16 Hex Nut 3/8”-16 Flanged Nylock 1/2"-13 x 4” Grade 5 Hex Bolt 1/2"... - Page 3 1/4" -20 x 3/4” Grade 5 Hex Bolt Parts Inventory Continued 1/4" Lock Washer 1/4” Fender Washer 1/4" -20 Grade 5 Hex Nylon Strap 50Amp Connectors Step 1: If you are installing the Hidden Power onto an E250, install the 3/8” -16 x 2-1/2”...
- Page 4 Figure 1.1 If you are installing the Hidden Power onto an E350, thread the 3/8”-16 Grade 5 Hex Nuts onto the 3/8”-16 x 1-1/4” Grade 5 Hex Bolts. Thread the nuts down onto the bolt, leaving about 3/8” of thread sticking out past the nut.
- Page 5 Figure 1.2 Step 2: Locate an empty space on the outside of the driver side frame rail. Hold the A7729 Frame Plate up to the frame to make sure that it is going to sit...
- Page 6 flush against the frame. There is a slot in the middle of the A7729 Frame Plate which can be used to bolts protruding from the frame. Once you have located a spot where you would like to install the Hidden Power, slide the two 1/2"-14 x 4”...
- Page 7 Figure 4.1 Step 5: Loosely install a 3/8” Lock Washer and 3/8”-16 Grade 5 Nut onto the bottom of each frame plate stud located on the bottom of the A7729 Frame Plate. Be sure to leave at least 1/4” of space between the 3/8” Lock Washer and the bottom of the A7729 Frame Plate.
- Page 8 Tray from sliding back. Tighten the 3/8”-16 Flanged Nylock Nut on A7729 frame plate studs until just snug. See figure 6.1. Position the Group 24-31 Battery Box so that it is not touching any part of the vehicle. While positioned, use a marker to transfer the location of the holes in the Battery Tray to the Group 24-31 Battery Box.
- Page 9 1/4" -20 x 3/4” Grade 5 Hex Bolts with a 1/4" USS Washer, a 1/4" Lock Washer, and a 1/4" -20 Grade 5 Nut. Torque to 7 ft-lbs. See figure 7.1 Figure 7.1 Step 8: Install the battery into the Group 24-31 Battery Box. Connect the battery leads to their appropriate terminals (wiring not included).
- Page 10 *For all questions regarding connecting your battery to your vehicle or camper, call your local RV service center. Slide the non-buckle end of the Nylon Strap down through the slotted hole in the Battery Tray (see figure 7.1). Using the Nylon Strap, secure the lid to the battery box.
- Page 11 NOTE: Wire color is going to vary from manufacturer to manufacturer which is why you should always wire by function and use a Volt Meter or a 12V test light when wiring. There is no official industry standard for wire color. If you are trying to wire by matching colors, there is a very good chance that it will be wired incorrectly.
- Page 14 (on or off road). A rubber bed mat is not a requirement to maintain the lifetime warranty on a Torklift system, but a strong recommendation simply as a safety precaution to protect the truck bed, the bottom of the camper and to give the camper additional support.
- Page 15 They are designed for each make and model to fit tight to the frame so as not to compromise ground clearance. Torklift tie downs are not universal ‘one size fits all’ therefore all the problems with correct fit for each particular application have been eliminated.
- Page 16 Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. Any damage to Torklift products as a result of misuse, abuse, neglect, accident, improper installation or any use violative of instructions furnished by Torklift or WHEN USED IN ANY COMMERCIAL APPLICATION WILL VOID THE WARRANTY.
- Page 17 International gift. To Fax: Send copies of the questionnaire, warranty card and receipt to 253-854-8003 To E-mail: Send copies of the questionnaire, warranty card and receipt to warranty@torklift.com To Mail: Send to Torklift International 322 N Railroad Ave. Kent, WA 98032...
- Page 18 OFFICIAL WARRANTY REGISTRATION CARD PLEASE FILL OUT THIS FORM COMPLETELY AND RETURN TO TORKLIFT WITHIN 30 DAYS OF PURCHASE ACCOMPANIED BY A COPY OF YOUR ORIGINAL RECEIPT...
