Torklift C3215A Installation Instructions Manual

Truck bed and camper protection
Hide thumbs

Advertisement

Quick Links

Download this manual
IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS
C3215A

Advertisement

loading
Need help?

Need help?

Do you have a question about the C3215A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Torklift C3215A

Summary of Contents for Torklift C3215A

  • Page 1 IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS C3215A...
  • Page 2 Minor movement or settling can occur in some incidental harsh driving conditions (on or off-road). A rubber bed mat is recommended to protect the truck bed and camper, but is not a requirement to maintain the Torklift legendary lifetime warranty.
  • Page 3 Part Inventory Image Description Quanity Tie Down Receiver Tie Down Insert Tie Down Clamp Strap 1/2"-13 x 1.5" Hex Bolt Grade 5 1/2" Washer USS Grade 5 1/2" Lock Washer High Alloy 1/2"-13 Hex Nut Grade 1/2" Star Washer 1"(2.54cm) x 2"(5cm) Plate Washer 7/16"-14 x 1-1/2”...
  • Page 4 Note: On long bed trucks, the C3215 will sit to the rear of the spring perch bracket. On short bed trucks, the C3215 will sit to the front of the spring perch bracket. Long Bed Truck: Driver Side Rear Tie Down Receiver Short Bed Truck: Passenger Side Rear Tie...
  • Page 5 Starting with the Passenger Side Note: If the passenger side Tie Down Receiver has clearance issues with the exhaust it may be necessary to adjust the Exhaust U-Bracket down to open in order to gain additional clearance. Exhaust U-Bracket to bend open. Step 1 Starting on the passenger side, locate the rear leaf spring perch.
  • Page 6 Step 2 Fish the Bolt assembly as one into the large opening on the backside of the spring perch and through the outside bottom hole on the spring perch. See Photo 2.1 and 2.2. Note: This bolt fisher assembly will not fish through the hole if each fastener is done individually.

  • Page 7: Tie Down Receiver

    Step 3 Lift the passenger side Tie Down Receiver up to the factory hitch so the 7/16"-14 x 1-1/2” Grade 8 Bolt protrudes down from the spring perch and through the slotted hole. See Photo 3.1 for reference. Photo 3.1 Step 4 Secure the Tie Down Receiver to the spring perch by fastening one 1"(2.54cm) x 2"(5cm) Plate Washer followed by one 7/16"...

  • Page 8: Tie Down Clamp Strap

    If you are installing this Tie Down on a Long Bed Truck, proceed to Step 5 and 6. If you are installing this Tie Down on a Short Bed Truck, Proceed to Step 7 and 8. Long Bed Short Bed Holes Holes Step 5 - Long Bed...

  • Page 9: X 1.5" Hex Bolt

    Step 6 - Long Bed Install one 1/2"-13 x 1.5" Hex Bolt Grade 5 with one 1/2" Washer USS Grade 5 through each of the two holes that are lined up between the Tie Down Clamp Strap and the Tie Down Receiver. Proceed to Step 10 If Long Bed Truck...

  • Page 10: Grade

    Step 7 - Short Bed Take one Tie Down Clamp Strap and install one 1/2"-13 x 1.5" Hex Bolt Grade 5 with one 1/2" Washer USS Grade 5 through the Center hole. Slide it inside the factory hitch at a 45° so the bolt head is angled toward the inside of the truck until the 1/2"-13 x 1.5"...

  • Page 11: Washer Uss

    Step 10 Secure these two 1/2"-13 x 1.5" Hex Bolts Grade 5 with one 1/2" Washer USS Grade 5, followed by one 1/2" Lock Washer High Alloy, and one 1/2"-13 Hex Nut Grade 5 onto each 1/2"-13 x 1.5" Hex Bolt Grade 5.
  • Page 12 Step 13 Install the Tie Down Inserts into the Tie Down Receivers. The plate on the end of the Tie Down Inserts should be offset towards the rear of the vehicle, with the mounting holes on the plate located above the tube.
  • Page 13 TD FINISHING KIT: Generic Aluminum Tie Down picture is used for illustration purposes. Aluminum Tie Down design may vary. TD Finishing Kit 1-3/4” x 1-3/4” X 2” Foam Backing Plug 2” x 2” x 1-1/2” Receiver Step 1 Insert one 1-3/4” x 1-3/4” x 2” Foam Backing Plug into the back of the Aluminum Tie Down Receiver opening.
  • Page 14 Step 2 Insert one 2” x 2” x 1-1/2” Receiver Cap over the end of the Aluminum Tie Down Receiver. (if the 2” x 2” x 1-1/2” Receiver Cap does not fit over the receiver, you will need to notch it out using a box knife or similar) See Photo 2.1 Photo 2.1...
  • Page 15 Due to the extreme, harsh, undercar environment that your Torklift products live in, (consistently sprayed with corrosive road chemicals such as salt, and road debris), Torklift does not warranty the power coated finish. To minimize corrosion from these factors on powder coated steel...
