1. HANGING BRACKET: with 2 knobs on both sides to fasten the unit and a mounting hole to fix a
mounting hook.
2. LASER OUTPUT: This is where the laser beams exit the
enclosure, make sure to NEVER look inside the unit through this
opening while the laser effect is switched on!
3. LED EFFECT LENSES: output of the colored led effect. Don't
expose to direct sunlight !
4. STROBE EFFECT LENSES: output of the white led effect. Don't
expose to direct sunlight !
5. CONTROL PANEL:
a. DISPLAY: shows the various menus and the selected
functions.
b. LEDS:
DMX
AUTO
SLAVE
SOUND
c. BUTTONS:
FUNC
UP
DOWN
ENTER
6. INTERNAL MICROPHONE: The built-in microphone is used to synchronize the show to the beat of the
music.
7. SENSITIVITY KNOB: The unit works to rhythm of the beat when used in standalone or master/slave
mode. With this knob you can set the input sensitivity of the build-in microphone.
8. DMX OUTPUT: 3pin female XLR-connector used to connect the LASER with the next unit in the DMX
chain.
9. DMX INPUT: 3pin male XLR-connector used to connect universal DMX-cables. This input receives
instructions from a DMX-controller.
10. ON/OFF KEY ACTIVATED SWITCH: used to switch the unit on/off. Use the keys to make sure only a
skilled operator is able to switch the laser on.
11. INTERLOCK input: used to connect the optional emergency stop switch (see
picture). When you push this switch the laser beam will disappear immediately.
IMPORTANT! For your own safety we strongly recommend to connect this
THERE WILL BE NO LASER OUTPUT WHEN THE INTERLOCK INPUT IS NOT
Temporary solution: install the spare connector on the laser. (see picture)
12. SAFETY EYEBOLT: used to attach a safety cable when the unit is rigged (see paragraph "overhead
rigging"
13. MAINS INPUT: with IEC socket and integrated fuse holder; connect the supplied mains cable here.
14. MAINS OUTPUT: you can use our "combi cables" and this IEC output to easily daisy-chain the next unit
15. M-DMX INPUT: Please note that this USB-connector is NOT used for updates or to
connect the unit to a PC! Instead this USB-connector makes it very easy to add
wireless DMX to the unit! Just add the (optional) WTR-DMX DONGLE from
BRITEQ ® and you will get wireless DMX! Moreover, you will be able to connect
other DMX-controlled equipment to the DMX-output so you can share the wireless
DMX function with all connected units! No extra settings to be made in the setup
menu, just follow the procedure in the user manual supplied with the WTR-DMX
DONGLE from BRITEQ
WWW.BRITEQ-LIGHTING.COM (order code: 4645)
JB SYSTEMS®
On DMX input present
On Master mode
On Slave mode
Flashing Sound activation
To select the program functions
To go forward in the selected functions or to increase a value
To go backward in the selected functions or to decrease a value
To confirm the selected functions
optional switch!
USED!
®
. The separate WTR-DMX DONGLE is available from
