1 CHANNEL DMX-CONFIGURATION OF THE UNIT:
DMX-value
000-029 OFF
030-049 White LEDs Full ON
050-069 White LEDs Strobe
070-089 Slow Auto Chase Laser
090-109 Slow Auto Chase RGBWA
110-129 Slow Auto Chase Laser + RGBWA
130-149 Sound Chase White LEDs
150-169 Sound Chase Laser
170-189 Sound Chase RGBWA
190-209 Sound Chase RGBWA + White LEDs
210-229 Sound Chase Laser + White LEDs
230-249 Sound Chase Laser + RGBWA
250-255 Sound Chase Laser + RGBWA + White LEDs
9 CHANNEL DMX-CONFIGURATION OF THE UNIT:
IMPORTANT REMARK: DMX Channel1 is used to set the different working modes of the unit.
• To use the unit in full manual mode, channel 1 must be set to value 221 or higher.
Channel
CH1 Mode
CH2 RGBWA
JB SYSTEMS®
function
Value
000-009 Blackout
010-024 AUTO 0
025-039 AUTO 1
040-054 AUTO 2
055-069 AUTO 3
070-084 AUTO 4
085-099 AUTO 5
100-114 AUTO 6
115-129 SOUND 0
130-144 SOUND 1
145-159 SOUND 2
160-174 SOUND 3
175-189 SOUND 4
190-204 SOUND 5
205-220 SOUND 6
221-255 DMX MODE
000-009 Blackout
010-014 Red
015-019 Green
020-024 Blue
025-029 Amber
