Zonelines are packaged room air conditioners that provide cooling and heating for residential and
commercial properties. Available in 7,000, 9,000, 12,000 and 15,000 BTU models. Accessories are available to
duct conditioned air into an adjoining room.
The newly designed Zonelines are dimensionally the same size as older models and will t into existing wall
cases.
Operation is similar to previous models, but with a totally new electrical and mechanical design.
Features
Example of features of a AZ65H09DAM with Make-up Air Module:
• Make-up Air: Supplies 35 CFM of continuous, conditioned fresh make-up air
• Cooling Capacity: 9,100 BTU @ 230 volts – 8,800 BTU @ 208 volts
• Energy E ciency: 11.0 EER, on average over 8
• Dehumidi cation: Conditions incoming air above 55% relative humidity
• Reverse Cycle Heat: 8,300 BTU @ 230 volts – 8,100 BTU @ 208 volts
• Heat Pump E ciency: 3.7 COPS
• Quiet Operation: Baked on mastic, cross ow blower and two DC fan motors
• Heat and Freeze Sentinels: Prevents room from overheating or freezing
• Boost Heat Option: Provides supplemental resistance heat during heat pump mode
• Electronic Temperature Limiting: Prevents over cooling or over heating of room
• Electronic Touch Controls: Tactile buttons with LED display

Introduction

more e cient than other brands
